Gigabyte GH-ESB21-TH Manuel utilisateur

GH-ESB21-TH

REV.1001

Intel®Pentium®4 LGA775

Installation Guide

050916

- 2 -

GH-ESB21-TH

English

Table of Contents

Checklist.............................................................................................................3

Specification........................................................................................................4

Feature..............................................................................................................4

Precautions........................................................................................................5

Warranty Item.....................................................................................................5

Installation Instructions for P4 LGA775 & Cooler.................................................6

- 3 - GH-ESB21-TH

English

Checklist

(2) GH-ESB21-TH

Installation Guide x 1

(1) GH-ESB21-TH

Cooler x 1

(4) Screw x 4

(3) Grease x 1

- 4 -

GH-ESB21-TH

English

yFan Dimension : 92 x 92 x 38 mm

yHeat Sink Dimension : 86 x 123 x 71 mm

yMaterial : Extrusion Aluminum fin + Copper core

yFan Speed Control: PWM & Temperature Control

yConnector: 4 pin

yRated Voltage : 12V

ySupports Intel BTX Type I Cooler (Supports Intel BTX & Micro BTX System)

yLarge 5 cm copper core insert. Powerful thermal ability

yFully compliant with Intel PWM & Temperature Sensor Control thermal functions

yProvide quieter environment & higher performance than box cooler

yEasy and quick installation

yRated Current : 1.13Amp (max)

yAirflow : 91.71 CFM ( max )

yBearing type : Two Ball Bearing

yLife Expectancy : 70,000 hr

yTotal Weight : 1120 g

yApplication : Intel®Pentium®4 LGA775

Feature

Specification

Fan Speed Mode

Air Inlet Temperature 25OC25

OC25

OC35

PWM Duty Cycle < 20% 50% 100% < 20% 100%

Fan Speed (RPM) 900 2350 3500 900 4500

Noise (dBA) 19 35.2 45.9 19 51.2

- 5 - GH-ESB21-TH

English

Incorrect method of operation or use of product not for intended use.

Operational use beyond the advised standards (eg. overclocking).

Inability to install the product as a result of incompatibility with the motherboard used.

Damage of product as a result of other product components.

Any form of alteration to original product.

A faulty product that leads to harm or damage to other products.

Damage caused by natural disasters (eg. earthquake, fire, flood).

Products with a warranty sticker that is removed, torn or unreadable.

Due to the weight of the cooler exceeding normal standards, please remove the cooler before computer transport

to prevent damage to the cooler itself as well as prevent problems during installtion.

The cooler fan speed levels provided are for reference use only. Please refer to the motherboard BIOS to

verify actual fan speed levels.

Before use, please remove the bottom protective layer of the cooler.

Please make sure the computer is turned off and its power disconnected prior to installation.

Precautions

Warranty Item

- 6 -

GH-ESB21-TH

English

Installation Instructions for P4 LGA775 & Cooler

Fig.2

Install the motherboard in the chassis. Align the GH-ESB21-TH Cooler with the screw holes and

place it onto the motherboard.

Fig.4

Finally, please attach the power connector of the cooler to the CPU fan header located on the

motherboard.

Fig.3

Fasten the cooler with screws(Note). Assure that the cooler is securely attached to the

motherboard and chassis.

Fig.1

Apply an even layer of thermal paste on the surface of the installed CPU.

Before use, please remove the bottom protective layer of the cooler.

- 7 - GH-ESB21-TH

English

(Note) The four screws can be screwed as below:

Combination 1: A+C+D+F or Combination 2: B+C+E+F

DEF

- 8 -

GH-ESB21-TH

English
