Gefen HDMI-341 Manuel utilisateur
3x1 HDMI
Switcher
USER MANUAL
www.gefen.com
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday through Friday.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff St.
Chatsworth, CA 91311
www.gefen.com
support.gefen.com
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
3x1 HDMI Switcher is a trademark of Gefen Inc.
HDMI is a trademark of hdmi.org
© 2007 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE
TABLE OF CONTENTS
Introduction
Features
Panel Descriptions
Connecting and Operating the 3x1 HDMI Switcher
RMT3-IR Installation
IR Code Conflicts
IR Extender Installation
Specifications
Warranty
1
2
3
4
5
6
7
8
9
Congratulations on your purchase of the 3x1 HDMI Switcher. Your complete satisfaction
is very important to us.
Gefen’s line of HDTV switches, extenders, and splitters are designed to make yourA/V
equipment use more comfortable, more productive and less expensive.
The 3x1 HDMI Switcher allows access to three HDTV devices, using one HDTV display.
The line offers solutions for Home Theater, A/V installation, data center, information dis-
tribution, conference room presentation, school and corporate training environments.
Our Commitment
Gefen will always offer the finest quality product at the best possible price. Included in
that price is a lifetime support from a team of outstanding engineers.
The 3x1 HDMI Switcher allows three HDTV HDMI devices to be switched easily in to
one HDTV HDMI compatible monitor or projector. Simply connect your HDTV display to
the Switcher’s display output. The 3x1 HDMI Switcher can also be placed at the end of
a long HDMI cable to regenerate the HDMI signal.
INTRODUCTION
1
FEATURES
Features
• Switches easily between any three HDMI sources
• Maintains 480p, 720p, 1080i, and 1080p resolutions
• Maintains highest HDMI single link video resolution
• Maintains highest HDMI digital audio signal
• Supports HDCP compliant devices
• HDMI or DVI to HDMI cables are used to connect the inputs and switcher output
• Inputs can be switched with the IR remote control
• Installs in seconds
• Fully HDMI 1.3 compliant
Includes:
(1) 3x1 HDMI Switcher
(3) 6’ HDMI cables (M-M)
(1) 5V DC Power Supply
(1) RMT3-IR
(1) Users Manual
2
PANEL DESCRIPTIONS
3
Indicator LEDs
IR Eye
Power LED
Input 2 Input 3 Output
Input 1
External IR Port Power Connector
CONNECTING AND OPERATING THE 3X1 HDMI SWITCHER
How to Connect the 3x1 HDMI Switcher to your devices
1 Connect the supplied cables from the HDTV HDMI sources into the 3x1 HDMI Switcher
inputs.
2Connect the cables from your display (monitor or projector) into the HDMI out of the
3x1 HDMI Switcher.
3 Plug the 5VDC power supply into the 3x1 HDMI Switcher.
How to Control the 3x1 HDMI Switcher
Use the RMT4-IR remote control to toggle between sources.
4
5
RMT3-IR INSTALLATION
1. Remove battery cover from the back of the RMT3-IR remote.
2. Verify that dip switches 1 & 2 are in the down (OFF) position.
3. Insert the battery, hold the battery so that you can see the positive side facing up. The
side that is not marked must be facing down.
4. Test the RMT3-IR remote by pressing ONLY one button at a time. The indicator light
on the remote will flash once each time you press a button. WARNING: Do not press
multiple buttons simultaneously and do NOT press buttons rapidly. These actions will
cause the remote to reset and steps 1-4 will have to be repeated.
Note: The RMT3-IR ships with two batteries. One battery is required for operation, the
second battery is complimentary.
The optional IR extender allows you to
relocate your HDMI Switcher and still have
IR control of the HDMI Switcher
IR CODE CONFLICTS
How to Resolve IR Code Conflicts
There are matching pairs of dip switches underneath the Switcher unit and under the
remote battery cover. Switch 1 & 2 on the Remote and Switch 1 & 2 underneath the unit
are the matching switches. These switches need to be matched for the remote to
communicate with the switcher. There are 4 possible sets of IR codes and at least one of
these sets should be able to resolve any IR conflicts with other home theater devices.
6
12
Remote Channel 1:
12
Remote Channel 2:
12
Remote Channel 3:
12
Remote Channel 4:
Remote
Switcher
IR EXTENDER INSTALLATION
How to Connect the IR Extender
1 Plug the IR extender into the Remote port on the front of the Switcher Unit
2Flip the Dip Switch 1 underneath the unit to the ON position
7
