GE RM94906 Manuel utilisateur

Universal

Remote Control

RM94906

INSTRUCTION

MANUAL

94906 Revised Size 1/21/02 2/25/02 4:20 PM Page 1

Table Of Contents

Button Description . . . . . . . . . . . . . . . . . . 1-2

Battery Installation. . . . . . . . . . . . . . . . . . . . 2

Programming for TV. . . . . . . . . . . . . . . . . . . 4

Programming for VCR . . . . . . . . . . . . . . . . . 5

Programming for Cable Box or Satellite . . . 6

DVD or AUX Button . . . . . . . . . . . . . . . . . . . 7

Code Search. . . . . . . . . . . . . . . . . . . . . . . . . 8

Retrieving Codes . . . . . . . . . . . . . . . . . . . . . 9

Television Menu Function . . . . . . . . . . . 10-11

DBS Menu Function . . . . . . . . . . . . . . . 12-13

Sleep Feature. . . . . . . . . . . . . . . . . . . . . . . 14

Trouble Shooting . . . . . . . . . . . . . . . . . 15-16

Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Instructions in Spanish . . . . . . . . . . . . . 17-31

Device Codes. . . . . . . . . . . . . . . . . . . . . 32-36

Button Description

INDIC ATOR LIGHT

The Indicator Light flashes to show that the remote

is working.

ON•OFF

The ON•OFF button operates the same as your

original remote (note: some RCA, GE and ProScan

models require you to press the device key to turn

the device on and the ON•OFF key to turn the

device off).

CODE SEARCH

Used to program the remote or to search through

codes.

TV, VCR, D VD•A UX, CBL•S AT

TheTV,VCR, DVD•AUX and CBL•SAT buttons are

used to select the device you want to control.

REVERSE, PLA Y, FOR WARD , REC ORD , STOP,

PAUSE

The REVERSE, PLAY, FORWARD, RECORD, STOP

and PAUSE buttons operate the same as on your

originalVCR remote.You must press the RECORD

button twice to begin recording. Buttons also con-

trol similiar functions for DVD and CD Player.

94906 Revised Size 1/21/02 2/25/02 4:20 PM Page 2

TV•V CR

The TV•VCR button operates the TV•VCR function of

yourVCR.

ENTER

The ENTER button is used to complete channel

selection for some brands of TV. It is also used to

complete the code entry process.

VOL & CHAN

TheVOL (Volume) and CH (Channel) buttons

increase or decrease the channel numbers or vol-

ume. The Channel buttons also control DVD SKIP

functions.

MUTE

To MUTE the volume on the TV.

PREV CH

PREV CH allows you to go to the previous channel

you selected. Operates the same as Last Channel,

Go Back or Recall button on your original remote.

0-9

The number buttons operate the same as on your

original remote, and are used for entering device

codes or channel numbers.

The MENU button calls up the TV, DBS and DVD set

up menus.

SLEEP

The SLEEP button allows you to set a time to turn

off the TV automatically.

Battery Installation

Your Universal Remote requires two (2) new

AAA alkaline batteries.To install the batteries:

1. On the back of the remote, push and slide

the cover off.

2.Match the batteries to the + and - marks

inside the battery case, then insert the bat-

teries.

94906 Revised Size 1/21/02 2/25/02 4:20 PM Page 3

3. Press and slide the battery cover back into

place.

Note: Programmed codes will remain in

memory for a short period of time allowing

for battery replacement. If batteries have

been dead for a prolonged period of time,

reprogramming may be required.

Button Description

94906 Revised Size 1/21/02 2/25/02 4:20 PM Page 4

Programming For TV

1. Manually turn on the TV.

2. Press and hold the

SETUP button until

the INDICATOR LIGHT

lights, then release

the SETUP button.

3. Press and release the

TV button (the

INDICATOR LIGHT

will blink then

remain lit).

4. Find the three digit

code for your TV in

the TV code list, and

enter it using the

Number Buttons.

After your code is

entered, the

INDICATOR LIGHT

will turn off.

5. Aim the remote at your

TV and press the

ON•OFF button.Your

TV should turn off.

Note: If your TV does not

respond, try all the codes

for your brand. If the codes

do not work, or your brand

is not listed, try the Code

Search method on page 7.

6. With your TV on, press

CH+. If the TV responds,

no further program-

ming is required.

7. Enter your code here

for easy reference.

BLINK

INDICATOR

LIGHT

TV CODE

OFF

SETUP

94906 Revised Size 1/21/02 2/25/02 4:20 PM Page 5

Programming For VCR

1. Manually turn

on the VCR.

2. Press and hold

the SETUP button

until the INDICATOR

LIGHT lights, then

release the SETUP

button.

3. Press and release

theVCR button (the

INDICATOR LIGHT

will blink then

remain lit).

4. Find the three digit

code for your VCR

in the code list and

enter it using the

Number Buttons.

After your code is

entered, the INDICATOR

LIGHT will turn off.

5. Aim the remote at

yourVCR and press

the ON•OFF button.

Your VCR should turn off.

Note: If your VCR does

not respond, try all

the codes for your

brand. If the codes

do not work, or your

brand is not listed,

try the Code Search

method on page 7.

6. With your VCR on,

press CH+. If the

VCR responds,

no further

programming

is required.

7. Enter your code

here for easy reference.

BLINK

INDICATOR

LIGHT

VCR CODE

OFF

SETUP

94906 Revised Size 1/21/02 2/25/02 4:20 PM Page 6

Programming For Cable Box or

Satellite Receiver

The CAB • SAT button is defaulted to

RCA/GE/ProScan DBS systems, however other DBS

systems can be programmed to this button.

1. Manually turn on the cable

box or satellite receiver.

2. Press and hold the

SETUP button until

the INDICATOR LIGHT

lights, then release

the SETUP button.

3. Press and release

the CBL•SAT button

(the INDICATOR

LIGHT will blink

then remain lit).

4. Find the three digit

code for your Cable

Box or Satellite Receiver

in the code list

and enter it using

the Number Buttons.

After your code is

entered, the

INDICATOR LIGHT

will turn off.

5. Aim the remote at

your Cable Box and

press the ON•OFF

button.Your Cable Box

should turn off.

Note: If your Cable Box

does not respond, try all

the codes for your brand.

If the codes do not work,

or your brand is not

listed, try the Code

Search method on

page 7.

6. With your Cable Box

on, press CH+. If the

Cable Box responds,

no further program-

ming is required.

7. Enter your code here

for easy reference.

BLINK

INDICATOR

LIGHT

CBL or SAT CODE

OFF

SETUP

CBL•SAT

94906 Revised Size 1/21/02 2/25/02 4:20 PM Page 7

Programming for DVD•AUX

The DVD•AUX button can be used for a DVD play-

er. It can also be assigned to any other type of

device (another TV, VCR, DVD, CD Player, or audio

receiver).

1. Manually turn on the

the device you wish

to assign to the

DVD•AUX button

(TV, VCR or Cable

Box or DVD Player).

2. Press and hold the

SETUP button until

the INDICATOR LIGHT

lights, then release

the SETUP button.

3. Press and release the

DVD•AUX button. The

INDICATOR LIGHT

will blink.

4. Find the three digit code

for the device you wish

to program in the code list

Enter the code using the

Number Buttons.

After your code is

entered, the INDICATOR

LIGHT will turn off.

5. Aim the remote at your

device and press the

ON•OFF button.Your

device should turn off.

Note: If your device

does not respond, try

all the codes for your

brand. If the codes do

not work, or your brand

is not listed, try the

Code Search method

on page 7.

6. With your device on,

press CH+. If the

device responds,

no further program-

ming is required.

7. Enter your code here

for easy reference.

BLINK

INDICATOR

LIGHT

DVD or AUX CODE

OFF

SETUP

DVD•AUX

94906 Revised Size 1/21/02 2/25/02 4:20 PM Page 8

Programming With Code Search

If your TV, VCR, DVD Player, cable box or satel-

lite receiver does not respond after you have

tried all the codes for your brand, or if your

brand is not listed, try searching for your code

by following the steps below.

1. Turn on the device

you wish to program.

2. Press and hold SETUP

until the INDICATOR

LIGHT lights, then

release SETUP.

3. Press and release the

device button for the

device you are

programming.The

INDICATOR LIGHT

will blink once then

remain lit.

For Auxillary device,

press DVD•AUX then

the device button you

are assigning to AUX.

4. Press and release

ON•OFF until your

device turns off.

Important: You may

have to press ON•OFF

up to 200 times.

5. When your device

turns off, press the

ENTER button, the

INDICATOR LIGHT

will go off.

BLINK

INDICATOR

LIGHT

SETUP

DVD•AUX CBL•SAT

OFF

94906 Revised Size 1/21/02 2/25/02 4:20 PM Page 9

Retrieving Codes

If you need to find the three-digit code for your

TV, VCR, DVD Player, DBS Receiver, or Cable

Box after your device is set-up using Code

Search, use this procedure.

1. Press and hold SETUP

until the INDICATOR

LIGHT lights, then

release SETUP.

2. Press and release the

device button for the

device’s code you are

retrieving .The

INDICATOR LIGHT

will blink once then

remain lit. For

DVD•AUX, press

DVD•AUX then

the device button for

the code you are

retrieving.

3. Press and release

SETUP.The

INDICATOR LIGHT

will turn off.

4. Starting with 0 on the

keypad, press the

number buttons in

order (0-9) until the

INDICATOR LIGHT

blinks.

5. The number which

causes the INDICATOR

LIGHT to blink is the

first digit of your code.

6. Repeat step 4 until you

have retrieved all three

numbers in the code.

BLINK

INDICATOR

LIGHT

SETUP

DVD•AUX CBL•SAT

SETUP

OFF

.....

94906 Revised Size 1/21/02 2/25/02 4:20 PM Page 10
