GPS NAVIGATOR GP-80

Operator's Guide

The purpose of this operator's guide is to provide the basic operating procedures for this equip-

ment. For detailed information, refer to the operator's manual.

Selecting Display Mode

Press [DISPLAY SEL].

Plotter 1/Plotter 2

Highway

Navigation

Data

Enlarging/Shrinking the

Display

Enlarging: Press [ZOOM IN].

Shrinking: Press [ZOOM OUT].

Shifting the Cursor

1) Press [CURSOR ON/OFF] to turn on the

cursor.

2) Operate the cursor keys to shift the cursor.

Shifting the Display

1) Press [CURSOR ON/OFF] to turn off the

cursor.

2) Operate the cursor keys to shift the display.

Centering Cursor Position

1) Press [CURSOR ON/OFF] to turn on the

cursor.

2) Operate the cursor keys to position the cur-

sor where desired.

3) Press [CENTER].

Entering/Erasing Marks

1) Press [CURSOR ON/OFF] to turn on the

cursor.

2) Operate the cursor keys to position the cur-

sor where desired.

3) Press [MARK].

To erase any mark (except MOB), place the

cursor on the mark and press [CLEAR].

234°

DGPS 3D

34° 23.456´ N 135° 45.678´ E

BRG

345°

BRG To +

11.5

RNG To +

123°

CSE

001

2nm

234°

DGPS 3D

34°23.456´N 135°45.678´E

BRG

345°

RNG

123

12.3

SPD

CSE

001

002

1.0 1.0 nm

12.3

DGPS 3D

SPD

10.3

123

RNG

789

TRIP

VTD

BRG

23:45'

17H 45M

TO;

012

0.1nm 0.1nm

63°

123°

CSE

ETA TTG

Graphic display

of steering data

3D view of ship's

track overlaid on

intended course

Ship's track and

data

Comprehensive

navigation data

display

SEP 12, 1995 23:59'59" U DGPS 3D

12° 23.456' N

123° 23.456' E

POSITION

RNG

31.23nm

SPD

12.3 kt

BRG

223.4°

CSE

123.4°

TO : 001

MARINE

POINT1

NEXT : 002

MARINE

POINT2

Does not appear

on Plotter 2 display.

Registering Routes

1) Press [WPT RTE].

2) Press [5] to select Route Planning.

3) Press ▲ or ▼ to select route number.

4) Press s.

5) Enter waypoint number (three digits).

6) Press ▼to enter next waypoint number.

7) Repeat steps 6 and 7 to complete the route.

8) Press [NU/CU ENT].

Setting/Cancelling

Destination

Destination can be set four ways. Below is the

method for setting destination by the cursor.

1) Press [GOTO].

2) Press [1] to select Cursor.

3) Place the cursor on position to set as desti-

nation.

4) Press [NU/CU ENT] twice.

To cancel destination, press [GOTO] [5]

[NU/CU ENT].

Setting the Arrival Alarm

1) Press [MENU ESC] [4].

2) Press ▲ or ▼ to select Arrival/Anchor.

3) Press t to select Arr.

4) Press ▼to select Alarm Range.

5) Enter arrival alarm range.

6) Press [NU/CU ENT].

7) Press [MENU ESC].

The buzzer may be silenced by pressing

[CLEAR].

Selecting Mark Shape/Line

Type

1) Press [MENU ESC] [2].

2) Press ▲ or ▼ to select Mark Shape (or

Mark Line).

3) Press t or s to select mark shape (or

mark line) desired.

4) Press [NU/CU ENT].

5) Press [MENU ESC].

Entering Event Mark

Press [EVENT MOB].

Entering MOB Mark

Press [EVENT MOB] until "Save MOB posi-

tion" appears (about three seconds).

Stopping/Starting Plotting

and Recording of Track

Press [PLOT ON/OFF]. "

" appears when

recording is off.

Registering Waypoints

A waypoint can be entered four ways. Below

is the procedure for entry by the cursor.

1) Press [WPT RTE].

2) Press [1] to select Cursor.

3) Operate the cursor keys to place cursor on

position desired for waypoint.

4) Press [NU/CU ENT].

5) Press ▼.

6) Press t or s to select mark shape.

7) Press [NU/CU ENT].

8) Enter comment (maximum 12 alphanu-

meric characters).

9) Press [NU/CU ENT].

950950KO PUB.NO.OSE-43740-A

(0000,TATA) GP-80
