FUJITSU Storage

ETERNUS DX

Configuration Guide -Server Connection-

(SAS) ETERNUS DX80 S2/DX90 S2 Disk Storage System Settings

P3AM-5352-11ENZ0

This page is intentionally left blank.

Preface

This manual briefly explains the operations that need to be performed by the user in order to connect an

ETERNUS DX to a server running Solaris OS, Windows®, Linux, or VMware ESX via a SAS interface.

This manual should be used in conjunction with any other applicable user manuals, such as those for the

ETERNUS DX, OS, SAS cards, and drivers.

Refer to "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- Notations" for the notations

used in this manual such as product trademarks and product names.

This manual references the following documents:

•ETERNUS Web GUI User's Guide

This manual is designed for use with the following ETERNUS DX storage systems:

•ETERNUS DX80 S2/DX90 S2 Disk storage system

11th Edition

December 2014

The Contents and Structure of this Manual

This manual is composed of the following two chapters.

•"Chapter 1 Workflow" (page 6)

This chapter describes the workflow when setting up an ETERNUS DX.

•"Chapter 2 Setting Up the ETERNUS DX" (page 8)

This chapter describes how to set up an ETERNUS DX.

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5352-11ENZ0

Table of Contents

Chapter 1 Workflow 6

Chapter 2 Setting Up the ETERNUS DX 8

2.1 Common Settings ........................................................................................................................... 8

2.1.1 Setting the To-server Connection Type (Setting the SAS Port Parameters)............................................................8

2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)...................................................................8

2.1.3 Setting the Host Responses ..................................................................................................................................9

2.1.4 Setting the CA Port Groups....................................................................................................................................9

2.1.5 Registering the SAS Addresses of the Accessing SAS Cards (Setting SAS Host) ....................................................10

2.1.6 Allocating LUN Groups (Setting the Host Affinity)...............................................................................................10

2.2 Specific Settings ........................................................................................................................... 11

2.2.1 Setting the CA Reset Groups................................................................................................................................11

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5352-11ENZ0

List of Tables

Table 2.1 SAS port parameter settings.......................................................................................................................8

Table 2.2 Host response settings ...............................................................................................................................9

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5352-11ENZ0

Chapter 1

Workflow

This manual is used when performing the setup procedures described in the "Setting Up the ETERNUS DX"

section of the "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (SAS)" for each OS.

Required Documents

•ETERNUS Web GUI User's Guide

Workflow

Setting the SAS Port Parameters

Set the to-server connection type.

•"2.1.1 Setting the To-server Connection Type (Setting the SAS Port Parameters)" (page 8)

Setting the LUN Groups

Set the server accessible LUN groups.

•"2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)" (page 8)

Setting the Host Responses

Set the host responses to match the connection configuration.

•"2.1.3 Setting the Host Responses" (page 9)

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5352-11ENZ0

Setting the CA Port Groups

Create a group of ports for each CA type.

•"2.1.4 Setting the CA Port Groups" (page 9)

Setting the SAS Host

•"2.1.5 Registering the SAS Addresses of the Accessing SAS Cards (Setting SAS Host)" (page 10)

Setting the Host Affinity

Define the relationship between the SAS host, the CA port group, and the LUN group.

•"2.1.6 Allocating LUN Groups (Setting the Host Affinity)" (page 10)

After completing all the required procedures in this manual, follow the procedures in "FUJITSU Storage

ETERNUS DX Configuration Guide -Server Connection- (SAS)" for each OS.

Chapter 1 Workflow

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5352-11ENZ0

Chapter 2

Setting Up the ETERNUS DX

2.1 Common Settings

This section explains the settings required for all server OSes, regardless of the connection configuration.

See the "ETERNUS Web GUI User's Guide" for details of how to set up and operate ETERNUS Web GUI.

2.1.1 Setting the To-server Connection Type (Setting the SAS Port Parameters)

For each connection configuration, set the indicated items only. All other parameters should be left on their

default values.

Table 2.1 SAS port parameter settings

Parameter Solaris OS, Windows®, Linux, VMware ESX

Reset Scope I_T_L (Default value)

Release Reservation if Chip is Reset Disable (Default value)

2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)

Create LUN groups (Affinity Group) for the server to access. Refer to "Connectivity (Basic Information)" in

"ETERNUS Web GUI User's Guide" for details, and set the LUN groups.

When the server OS is Windows®, Linux, or VMware ESX, assign SCSI LUN numbers starting from LUN0 in

ascending order.

The server cannot recognize the ETERNUS DX LUNs unless they are assigned in this order.

This restriction does not apply when the server is running a Solaris OS.

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5352-11ENZ0

2.1.3 Setting the Host Responses

The host response parameters for the ETERNUS DX must be set to match the way the server processes the

responses to requests from the ETERNUS DX. Setting of the host response must be done before connecting

the ETERNUS DX to the server.

Set the parameters that are described below for each OS.

Retain the default values for all of the parameters that are not described below.

Since "Windows EMPD", "Linux EMPD", "Solaris EMPD", or "Others" cannot be selected after applying the

latest firmware, select "Default" for the Host Response setting.

Note that these items are displayed as the existing setting, but do not need to be changed.

Table 2.2 Host response settings

OS Conditions Host response selec-

tion Parameter Setting value

Solaris When all of the following con-

ditions are met

•The OS standard Multipath

Driver (MPxIO) is used

•The Multipath Diagnostic

Program (or Enhanced Sup-

port Facility 5.1 or later) is

installed

None

(Create a new host re-

sponse)

Reservation Conflict Re-

sponse for Test Unit

Ready

Conflict

Sense Data Conversion 4/*/* g 6/*/*

B/*/* g 6/*/*

When MPxIO that is different

from the above is used

Solaris MPxIO – –

When the ETERNUS Multipath

Driver or Symantec Storage

Foundation is used

Default – –

Windows®

VMware ESX

– Default – –

Linux For SUSE Linux Enterprise

Server 10

None

(Create a new host re-

sponse)

Sense Data Conversion b/c1/01 g 6/c1/01

Other cases Default – –

2.1.4 Setting the CA Port Groups

Create new SAS port groups and register the ports as members of the groups. A SAS port group is a group of

SAS-CA type ports that are connected to the specified host group. Configure the host affinity setting for each

SAS port group.

Chapter 2 Setting Up the ETERNUS DX

2.1 Common Settings

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5352-11ENZ0

2.1.5 Registering the SAS Addresses of the Accessing SAS Cards (Setting SAS Host)

same time, set the host response registered in "2.1.3 Setting the Host Responses" (page 9) to accept these

SAS hosts (SAS addresses).

Registering the SAS hosts (SAS addresses) and setting up Host Affinities as described elsewhere, allows limits

to be set on which servers are allowed to access which ETERNUS DX storage systems.

When a server-side SAS card is replaced, the SAS address of the replacement SAS card must be re-regis-

tered to the ETERNUS DX.

1Connect the SAS card that is installed in the server to the ETERNUS DX with the SAS cable.

2Turn on the ETERNUS DX.

3Turn on the server, and start the OS.

4Acquire the SAS address of HBA from each port in the [SAS Host] screen of ETERNUS Web GUI.

5Register the Host Response in which the acquired SAS address is registered to the ETERNUS DX.

2.1.6 Allocating LUN Groups (Setting the Host Affinity)

Allocate the relationship between registered SAS hosts (SAS addresses), CA port groups, and LUN groups us-

ing the Host Affinity setting function to specify which LUNs to be accessed. This sets access restrictions to the

ETERNUS DX from each server.

Refer to "Connectivity (Basic Information)" in "ETERNUS Web GUI User's Guide" for details, and set the LUN

groups.

If the one-to-one relationship between the SAS addresses and SAS cards cannot be determined, the Host

Affinity may not be set correctly.

In this case, trying various settings may be necessary until the server is able to recognize the ETERNUS DX

logical disks.

Chapter 2 Setting Up the ETERNUS DX

2.1 Common Settings

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-

P3AM-5352-11ENZ0
