Fujitsu M3099EX Manuel utilisateur
C150-E066-03EN
Reference Guide
M3099EX/GX/EH/GH Image Scanner
CHAPTER
1
OPERATING INSTRUCTION
CHAPTER
2
CLEANING
CHAPTER
3
REPLACEMENT OF PARTS
CHAPTER
4
ADJUSTMENT
CHAPTER
5
TROUBLESHOOTING
TROUBLESHOOTING
ADJUSTMENT
REPLACEMENT
OF PARTS
CLEANING
OPERATING
INSTRUCTION
i
IMPORTANT NOTE TO USERS
READ CAREFULLY ALL OF THIS MANUAL BEFORE USING THIS PRODUCT.
IF NOT USED CORRECTLY, UNEXPECTED DAMAGES MAY BE CAUSED TO
THE USERS OR THE BYSTANDERS.
While all efforts have been made to ensure the accuracy of all information in this
manual, FUJITSU assumes no liability to any party for any damage caused by
errors or omissions or by statements of any kind in this manual, its updates or
supplements, whether such errors are omissions or statements resulting from
negligence, accidents, or any other cause. FUJITSU further assumes no liability
arising from the application or use of any product or system described herein; nor
any liability for incidental or consequential damages arising from the use of this
manual. FUJITSU disclaims all warranties regarding the information contained
herein, whether expressed, implied, or statutory.
FUJITSU reserves the right to make changes to any products herein, to improve
reliability, function, or design, without further notice and without obligation.
ii
Preface
This manual explains how to use the M3099EX/GX/EH/GH image
scanner.
This manual contains OPERATING INSTRUCTION, CLEANING,
REPLACEMENT OF PARTS, ADJUSTMENT and TROUBLESHOOT-
ING.
RefertoOperator’sGuideforthebasicinformationabouttheM3099EX/
GX/EH/GH.
The M3099EX/GX/EH/GH is very fast and highly functional image
scanner developed for volume filing, using charge-coupled device
(CCD)imagesensors. Thisscannerfeaturesduplexscanningandhigh
quality image, processing with an automatic document feeder (ADF).
iii
Conventions
Special information, such as warnings, cautions are indicated as follows:
WARNING
WARNING indicates that personal injury may result if you do not follow
procedure correctly.
CAUTION
CAUTION indicates that damage to the scanner may result if you do not follow
a procedure correctly.
The following symbols are used in this manual.
Used for general WARNING and CAUTION.
Be careful not to pinch your fingers or hands.
01 May,1996 First edition Revised contents
Date published
Edition
02 March,1999
Loading document and Parts replacement revised
This equiepment has been tested and found to comply with the limits for a Class
A digital device,pursuant to Part 15 of the FCC Rules. These limits are designed
toprovidereasonableprotectionagainstharmfulinterferencewhentheequipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communica-
tions. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
This digital apparatus does not exceed the Class A limit for radio noise emissions
from digital apparatus set out in the Radio interference Regulations of the
Canadian Department of Communications.
Le pésent appareil numérique n’ément pas de bruits radioélectriques dépassant
les limites applicables aux appareils numériques de la classe A prescridtes dans
leRéglesmentsurlebrouillageradioélectriquedictéparleministeredesCommu-
nications du Canada.
Maschinenlärmlnformationsverordnung3.GSGV,18.01.1991:Derarbeisplatzbe-
zogene Schalldruckpegel beträgt 70dB(A)oder weniger gemäß ISO 7779.
The contents of this manual may be revised without prior notice.
All Rights Reserved, Copyright © 1996, 1999 FUJITSU LIMITED.
Printed in Japan.
No part of this manual may be reproduced in any form without permission.
03 June,1999
Loading document and Parts replacement revised
Specification No. C150-E066-03EN
CONTENTS
v
CHAPTER 1 OPERATING INSTRUCTION .......................................................1-1
Units and Assemblies ...................................................................1-2
Loading Document........................................................................1-4
Inserting Document Manually........................................................1-6
Upper Transport Unit ....................................................................1-7
CHAPTER 2 CLEANING ...................................................................................2-1
Cleaning Tools and Roller Position ...............................................2-2
Rollers...........................................................................................2-3
Transport Paths and Glass Surface ............................................. 2-5
Sensors.........................................................................................2-6
Front-Side Lamp ...........................................................................2-8
CHAPTER 3 REPLACEMENT OF PARTS........................................................3-1
Back-Side Lamp............................................................................3-2
Front-Side Lamp ...........................................................................3-4
Separation Roller or Roller ASY....................................................3-6
Belt and Belt ASY .........................................................................3-9
Pick Rollers .................................................................................3-13
Pad .............................................................................................3-15
Print Head ...................................................................................3-17
CHAPTER 4 ADJUSTMENT .............................................................................4-1
Separation Pressure Adjustment ..................................................4-2
Print Head Adjustment ..................................................................4-4
CHAPTER 5 TROUBLESHOOTING..................................................................5-1
Paper JAM ....................................................................................5-2
Initial Checks.................................................................................5-4
Messages and Actions................................................................5-12
Problem Checklist .......................................................................5-14
Appendix .....................................................................................5-15
1-1
Thischapterdescribeshowtoloaddocument,howtoinsertdocument
manually and how to open/close the upper transport unit.
Units and Assemblies
Loading Document
Inserting Document Manually
UpperTransport Unit
OPERATING INSTRUCTION
CHAPTER
1
1-2
Units and Assemblies
This section shows the exterior view and assemblies of the scanner. This section also provides
names of each part and describes their functions.
■Units
wHopper rExtension yPaper guide iSide cover oPower switch !1 Power inlet
No. Function
qStacker.
wHopper.
eUsed to operate the scanner.
rUsed to prevent documents from hanging down.
tOpen here when adjusting the print head position or when replacing the print head.
yUsed to adjust the document size.
uScans while feeding documents.
iOpen here when replacing the back-side lamp.
oTurns on or off the power.
!0 Video and RS-232C (M3099EX/EH) or SCSI (M3099GX/GH) interface connectors.
!1 Connect the power cable from an AC power outlet here.
qStacker eOperator panel tEndorser cover uUpper transport unit !0 Interface connectors
1-3
■Assemblies
Sheet guide assembly
Lamp unit
Lamp (Back-side lamp)
Lamp socket covers
Lamp (Front-side lamp)
Pick rollers
Roller ASY
Guide plate
Pad
Belt ASY
Belt
Separation roller
