Cleaning Instructions for

fi-5650C Scanner

It is recommended that these items be

cleaned EVERY 10,000 SCANS

Consumables Part Number

Consumable Kit CON-3338-008A

Cleaning Kit SC-CLE-LV

Using cleaning paper moistened with F1 Cleaner



Brake Roller

Open the brake roller holder and remove the brake roller before cleaning





Turn the Scanner OFF while cleaning the following locations

ADF Glass Surfaces x 2

Located on the ADF cover and opposite side. Clean lightly.

Pick Roller

Clean lightly taking care not to scratch the surface.

P.T.O.



Plastic Rollers x 4

Clean lightly while rotating with your finger. Take care not to roughen the surface.

BEFORE CLEANING

Open the ADF while pressing

the cover open button

ADF Cover

Paper

Chute

Cover Open

Buttons









Plastic Rollers

Feed Rollers

Glass

Brake Roller





Eject Rollers

(hidden)

Pick Roller



Feed Rollers x 2

Clean lightly taking care not to roughen the surface.

For further information please refer to the

fi-5650C Scanner Operators Guide

which can be found on our Website:

http://www.fujitsu.com/emea/products/

January 2010

Using cleaning paper moistened with F1 Cleaner

Turn the Scanner ON while cleaning the following locations

PFU Imaging Solutions Europe Ltd Cleaning Instructions for fi-5650C Scanner



Eject Rollers x 2

Clean lightly taking care not to roughen the surface.

To rotate the Feed and Eject Rollers, press the POWER button while holding down the SCAN

button.

As a guideline, seven presses of the POWER button make the rollers rotate one full turn.









Plastic Rollers

Feed Rollers

Glass

Brake Roller





Eject Rollers

(hidden)

Pick Roller

While holding down the SCAN button 

Press the POWER button 

Each press of the POWER button will cause the

rollers to rotate


