Freescale Semiconductor FRDMSTBC-A8471 Guide de référence

3-Axis Sensor Toolbox Development Board

FXLS8471Q 3-axis linear accelerometer

Quick Reference Card

Get Started

FREESCALE FREEDOM PLATFORM

documentation under

Jump-Start Your Design

at freescale.com/

sensortoolbox

Download tools and

FRDMSTBC-A8471

FRDM

STBC-

A8471

For more information,

visit freescale.com/

sensortoolbox

Freescale and the Freescale logo are

trademarks of Freescale Semiconductor, Inc.,

Reg. U.S. Pat. & Tm. Off. All other

product or service names are the

property of their respective owners.

FRDMSTBCA8471QRC REV 1

920-28984 REV A

FRDM

STBC-

A8471

Verify package contents:

FRDMSTBC-A8471

development board

Connect the FRDMSTBC-A8471

development board to a Freescale

Freedom development board,

such as the FRDM-KL25Z (or any

Arduino R3 compatible board).

Refer to the Freescale Freedom

development board Quick Start

Guide for driver information.

Plug one end of a USB cable into

the SDA port on the assembly.

Plug the other end of the cable into

the USB port on the computer.

Download and install the

latest Sensor Toolbox software at:

freescale.com/sensortoolbox

Start the Sensor Toolbox software.

Test points (12 places)

Learn more at freescale.com/sensortoolbox

Get to Know the FRDMSTBC-A8471

FXLS8471Q 3-axis linear accelerometer

16 QFN (3 mm x 3 mm x 1 mm)

INT1 – 3

5 – I2C_SDA1

4 – VDD

I2C_SDA0 – 9

I2C_SCL0 – 10

6 – I2C_SCL1

3 – RST_MCU

INT2 -1

SA1/CS - 3

SDA/MOSI - 4

SA0/MISO - 5

SPI/I2C_CLK - 6

4 – RST_GPIO

Through hole pins (12 places)

6 – GND
