Foxconn 720MX-K Manuel utilisateur
720MX/M78MX Series
Motherboard
User’s Manual
Statement:
This manual is the intellectual property of Foxconn, Inc. Although the information
in this manual may be changed or modied at any time, Foxconn does not obligate
itself to inform the user of these changes.
Trademark:
All trademarks are the property of their respective owners.
Version:
User’s Manual V1.0 for 720MX/M78MX Series motherboard.
P/N: 3A220UG00-000-G
Symbol description:
Caution : refers to important information that can help you to use motherboard
better, and tells you how to avoid problems.
Warning : indicating a potential risk of hardware damage or physical injury
may exist.
WEEE:
The use of this symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could other-
wise be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city ofce, your
household waste disposal service or the shop where you purchased this product.
More information:
If you want more information about our products, please visit Foxconn’s
website: http://www.foxconnchannel.com
CAUTION
!
W
A
R
N
I
N
G
!
© All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
All images are for reference only, please refer to the physical motherboard for specic features.
Declaration of conformity
HON HAI PRECISION INDUSTRY COMPANY LTD
66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,
TAIPEI HSIEN, TAIWAN, R.O.C.
declares that the product
Motherboard 720MX/720MX-K/M78MX
is in conformity with
(reference to the specication under which conformity is declared in
accordance with 89/336 EEC-EMC Directive)
■ EN 55022:1998/A2: 2003 Limits and methods of measurements of radio
disturbance characteristics of information technology
equipment
■ EN 61000-3-2/:2000 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits for harmonic current emissions
(equipment input current <= 16A per phase)
■ EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits of voltage uctuations and icker in low
voltage supply systems for equipment with rated current
<= 16A
■ EN 55024/A2:2003 Information technology equipment-Immunity
characteristics limits and methods of measurement
Signature : Place / Date : TAIPEI/2008
Printed Name : James Liang
Declaration of conformity
Trade Name: FOXCONN
Model Name: 720MX/720MX-K/M78MX
Responsible Party: PCE Industry Inc.
Address: 458 E. Lambert Rd.
Fullerton, CA 92835
Telephone: 714-738-8868
Facsimile: 714-738-8838
Equipment Classication: FCC Class B Subassembly
Type of Product: Motherboard
Manufacturer: HON HAI PRECISION INDUSTRY
COMPANY LTD
Address: 66 , CHUNG SHAN RD., TU-CHENG
INDUSTRIAL DISTRICT, TAIPEI HSIEN,
TAIWAN, R.O.C.
Supplementary Information:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions : (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Tested to comply with FCC standards.
Signature : Date : 2008
Installation Precautions
Please carefully read the following procedures to install your computer :
■ It is suggested to select high-quality, certied fans in order to avoid damage
to the motherboard and CPU due to high temperature. Never turn on the
computer if the CPU fan is not properly installed.
■ We cannot guarantee that your system can operate normally when your
CPU is overclocked. Normal operation depends on the overclocking capac-
ity of your device.
■ If there is any, when connecting USB, audio, RS232 COM, IrDA or S/PDIF
cables to the internal connectors on the motherboard, make sure their
pinouts are matching with the connectors on the motherboard. Incorrect con-
nections might damage the motherboard.
■ When handling the motherboard, avoid touching any metal leads or connec-
tors.
■ If there is a PCI Express x16 graphics card installed in your system, we
recommend using a 24-pin ATX power supply to get the best performance.
■ Before turning on the power, please make sure the power supply AC input
voltage setting has been congured to the local standard.
■ To prevent damage to the motherboard, do not allow screws to come in contact
with the motherboard circuit or its components. Also, make sure there are no
leftover screws or metal components placed on the motherboard or within the
computer casing.
■ If you are uncertain about any installation steps or have a problem related to
the use of the product, please consult a certied computer technician.
CAUTION
!
■ Electrostatic discharge (ESD) is the sudden and momentary electric current
that ows between two objects at different electrical potentials. Normally it
comes out as a spark which will quickly damage your electronic equipment.
Please wear an electrostatic discharge (ESD) wrist strap when handling
components such as a motherboard, CPU or memory.
■ Ensure that the DC power supply is turned off before installing or removing
CPU, memory, expansion cards or other peripherals. It is recommended to
unplug the AC power cord from the power supply outlet. Failure to unplug
the power supply cord may result in serious damage to your system.
W
A
R
N
I
N
G
!
TABLE OF CONTENTS
Chapter 1 Product Introduction
Product Specications..................................................................2
Layout...........................................................................................4
Back Panel Connectors................................................................ 5
Chapter 2 Hardware Install
Install the CPU and CPU Cooler ..................................................8
Install the Memory ...................................................................... 10
Install an Expansion Card ..........................................................12
Install other Internal Connectors ................................................ 13
Jumpers......................................................................................17
Chapter 3 BIOS Setup
Enter BIOS Setup....................................................................... 19
Main Menu..................................................................................19
System Information .................................................................... 21
Fox Central Control Unit............................................................. 23
Advanced BIOS Features...........................................................28
Advanced Chipset Features ....................................................... 29
Integrated Peripherals ................................................................30
Power Management Setup......................................................... 36
PC Health Status........................................................................ 38
Load Optimized Defaults ...........................................................39
Set Supervisor Password ........................................................... 39
Set User Password.....................................................................39
Save & Exit Setup ......................................................................39
Exit Without Saving ....................................................................39
Chapter 4 CD Instruction
Utility CD content........................................................................41
Install driver and utility................................................................ 42
FOX ONE
Main Page............................................................................. 44
CPU Control.......................................................................... 48
Frequency Control ................................................................ 50
Limit Setting ..........................................................................51
Voltage Control ..................................................................... 53
Fan Control ...........................................................................54
FOX LiveUpdate
Local Update......................................................................... 55
Online Update .......................................................................57
Congure .............................................................................60
About & Help......................................................................... 62
FOX LOGO.................................................................................63
FOX DMI .................................................................................... 64
Chapter 5 RAID Conguration
RAID Conguration Introduction................................................. 67
NVIDIA MediaShield Driver ........................................................ 69
Create two RAID Driver Diskettes .............................................. 71
RAID Enable in BIOS .................................................................73
Select a RAID Array for Use.......................................................73
Install a New Windows XP..........................................................89
Setting Up a Non-Bootable RAID Array...................................... 96
Technical Support :
Website :
http://www.foxconnchannel.com
Support Website :
http://www.foxconnsupport.com
Worldwide online contact Support :
http://www.foxconnchannel.com/support/online.aspx
CPU, Memory, VGA Compatibility Supporting Website :
http://www.foxconnchannel.com/product/Motherboards/compatibility.aspx
Support
Thank you for buying Foxconn 720MX/M78MX Series motherboard.
Foxconn products are engineered to maximize computing power,
providing only what you need for break-through performance.
With advanced overclocking capability and a range of connectivity
features for today multi-media computing requirements, 720MX/
720MX-K/M78MX enables you to unleash more power from your
computer.
This chapter includes the following information:
■ Product Specications
■ Layout
■ Back Panel Connectors
1
2
1-1 Product Specications
CPU Support AMD socket AM2+ PhenomTM series processors:
Support AMD socket AM2 series processors:
AthlonTM 64X2 Dual-Core / AthlonTM X2 Dual-Core / AthlonTM 64 /
SempronTM
HyperTransport 2000/1600MT/s for AM2 CPU
Up to 5200MT/S (HT3.0) for AM2+ CPU
Chipset NVIDIA nForce 720a (720MX Series)
NVIDIA GeForce 8200 (M78MX Series)
Memory 2 x 240-pin DDR2 DIMM sockets
Support up to 4GB of system memory
Dual channel DDR2 1066*/800/667/533MHz architecture
*DDR2 1066 is only supported by some AM2+ CPU
Audio Realtek 6-channel audio chip (720MX-K)
Realtek 8-channel audio chip (720MX/M78MX)
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
Support Jack-Sensing function
LAN Realtek Gigabit LAN chip
Expansion Slots 1 x PCI Express x16 slot
1 x PCI Express x1 slot
2 x PCI slots
Onboard Serial ATA 4 x SATA connectors
300MB/s data transfer rate
Support hot plug and NCQ (Native Command Queuing )
USB Support hot plug
Support up to 12 x USB 2.0 ports (4 rear panel ports, 4 onboard USB
headers supporting 8 extra ports)
Support USB 2.0 protocol up to 480Mb/s
Internal Connectors 1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
1 x Floppy disk drive connector
1 x IDE connector
4 x SATA connectors
4 x USB 2.0 connectors (supporting 8 x USB devices)
1 x CPU fan header (4-pin)
1 x System fan header (4-pin)
1 x Front panel connector
1 x CD_IN connector
1 x Front Audio connector
1 x COM1 connector
1 x COM2 connector
1 x IrDA connector
1
3
1 x Chassis intrusion alarm header (INTR)
1 x S/PDIF_OUT connector
1 x Buzzer (or Speaker connector)
Back Panel 1 x PS/2 keyboard port
Connectors 1 x PS/2 mouse port
1 x VGA port
1 x Parallel port
1 x DVI-D port
4 x USB 2.0 ports
1 x RJ-45 LAN port
7.1-channel Audio ports (720MX/M78MX)
5.1-channel Audio ports (720MX-K)
Hardware Monitor System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU/System overheating warning
CPU/System fan speed control
PCI Express x1 Support 250MB/s (500MB/s concurrent) bandwidth
Low power consumption and power management features
PCI Express x16 Support 4GB/s (8GB/s concurrent) bandwidth
Low power consumption and power management features
Green Function Support ACPI (Advanced Conguration and Power Interface)
Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4
(suspend to disk), and S5 (soft - off)
Bundled Software FOX ONE
FOX LiveUpdate
FOX LOGO
FOX DMI
Operating System Support for Microsoft®Windows®Vista/XP only
Form Factor Micro ATX Form Factor, 9.6 inches x 8.6 inches (24.4cm x 21.8cm)
The chipset driver of this motherboard does not support Windows® 2000.
CAUTION
!
Ce manuel convient aux modèles suivants
2
Table des matières
Autres manuels Foxconn Carte mère
Foxconn
Foxconn H61S Series Manuel utilisateur
Foxconn
Foxconn M61PML Series Manuel utilisateur
Foxconn
Foxconn T70S Series Manuel utilisateur
Foxconn
Foxconn H67M Series Manuel utilisateur
Foxconn
Foxconn WinFast 748K7AA Manuel utilisateur
Foxconn
Foxconn Q77M Series Manuel utilisateur
Foxconn
Foxconn 760GXK8MB series Manuel utilisateur
Foxconn
Foxconn G31 MX series Instructions d'utilisation d'origine
Foxconn
Foxconn P31A-S Manuel utilisateur
Foxconn
Foxconn 600A01 series Manuel utilisateur
Foxconn
Foxconn Destroyer Manuel utilisateur
Foxconn
Foxconn G31MX 2.0 Series Manuel utilisateur
Foxconn
Foxconn 720AL Series Manuel utilisateur
Foxconn
Foxconn 760GXK8MB series Manuel utilisateur
Foxconn
Foxconn MARS Manuel utilisateur
Foxconn
Foxconn K8T890M2AB Instructions d'utilisation
Foxconn
Foxconn A6VMX Series Instructions d'utilisation d'origine
Foxconn
Foxconn G41S Series Manuel utilisateur
Foxconn
Foxconn A88GMV Series Manuel utilisateur
Foxconn
Foxconn H67A Series Manuel utilisateur
Manuels Carte mère populaires d'autres marques
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuel utilisateur
Gigabyte
Gigabyte GA-9IVDT Manuel utilisateur
Texas Instruments
Texas Instruments ADS8372EVM Manuel utilisateur
Commell
Commell MS-C73 Manuel utilisateur
IBT Technologies
IBT Technologies MB860 Manuel utilisateur
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur
