FLIR Extech Instruments EN300 Manuel utilisateur

User's Guide

5 in 1 Environmental Meter

Model: EN300

Anemometer

Humidity Meter

Light Meter

Thermometer

Sound Level Meter

99 Washington Street

Melrose, MA 02176

Phone 781-665-1400

Toll Free 1-800-517-8431

Visit us at www.TestEquipmentDepot.com

EN300-EU-EN-V1.1.doc 6/11

Introduction

Congratulations on your purchase of this Extech Meter. The EN300 is five professional meters

built into one convenient package. This meter ships fully tested and calibrated and, with proper

use, should provide many years of reliable service.

Features

This 5-in-1 professional measuring instrument provides the following functions:

1. Anemometer uses a low-friction ball bearing mounted wheel design for high accuracy.

2. Humidity meter uses a high precision humidity sensor for fast response time.

3. Light meter uses a photo diode and color correction filter light sensor; spectrum meets C.I.E.

photopic.

4. Type K thermometer uses standard type K (NiCr-NiAl) thermocouple input jack suitable for

diverse application type K probes.

5. The sound level meter meets IEC 61672 class 2 with "A" frequency weighting and "Fast"

time response.

Common Features:

•Built-in microprocessor circuit assures excellent performance and accuracy.

•Concise and compact button arrangement for ease of operation.

•Record / recall maximum and minimum values.

•Hold function freezes the current reading value.

•Front panel °C / °F selection button.

•Front panel Lux/Foot-candle selection button.

•Five (5) air velocity measurement units, selected by a front panel button.

•Dual display with simultaneous display of relative humidity and temperature or air velocity

and temperature.

•Zero button for light meter.

•Robust housing suitable for one hand operation

EN300-EU-EN-V1.1.doc 6/11

Safety

International Safety Symbols

This symbol, adjacent to another symbol or terminal, indicates the user must refer to the

manual for further information.

Double insulation

Cautions

•Improper use of this meter can cause damage, shock, injury or death. Read and understand

this user manual before operating the meter.

•Inspect the condition of the probe and the meter itself for any damage before operating the

meter. Repair or replace any damage before use.

•If the equipment is used in a manner not specified by the manufacturer, the protection provided

by the equipment may be impaired.

•This device is not a toy and must not reach children’s hands. It contains hazardous objects as

well as small parts that the children could swallow. In case a child swallows any of them,

please contact a physician immediately

•Do not leave batteries and packing material lying around unattended; they can be dangerous

for children if they use them as toys

•In case the device is going to be unused for an extended period of time, remove the batteries

to prevent them from draining

•Expired or damaged batteries can cause cauterization on contact with the skin. Always,

therefore, use suitable hand gloves in such cases

•See that the batteries are not short-circuited. Do not throw batteries into the fire.

EN300-EU-EN-V1.1.doc 6/11

Meter Description

1. Microphone

2. Light Sensor

3. LCD display

4. Hold Button

5. Power Button

6. Unit / Zero Button

7. Air Speed Sensor

8. Thermocouple Input Socket l

9. RS-232 Output Terminal

10. AC power adaptor socket

11. Max. / Min. Button

12. Function Button

13. °C/°F Button/Lux/Ft-cd Button

14. On rear: Battery Compartment, Tripod mount,

Stand

EN300-EU-EN-V1.1.doc 6/11

Operation

Powering the meter

1. Press the Power button to turn the instrument ON

2. If the meter does not turn on or if the " " low battery symbol appears in the display,

replace the batteries.

3. Press the Function button to select the measurement needed.

Note: The display orientation rotates, depending on the function selected.

Microphone up: Sound, Light, Temperature

Air speed sensor up: Airspeed + Temperature, Humidity + Temperature

Anemometer Air Velocity Measurement

1. Select the Anemometer function by pressing "Function Button" until the display indicates

Anemometer units (ft/min, m/s, km/h, MPH, or knots).

2. Press the "Unit/Zero Button" to select unit desired

3. Press the “°C/°F Button” to select the temperature unit.

4. Face the air velocity sensor into the source of wind.

5. The display will show the air velocity and the ambient temperature.

6. Allow time for the reading to stabilize and note the values indicated. Air velocity may fluctuate

slightly.

Temperature Measurement (Thermocouple)

1. Plug a type K thermocouple probe into the "Thermocouple Input Socket".

2. Select the temperature function by pressing "Function Button" unit the display shows

temperature units (°C or °F).

3. Contact the Thermocouple Sensor Head with object to be measured

4. The temperature value will be displayed on the LCD display.

Note: Verify the polarity when plugging a thermocouple probe into the temperature input socket.

Any temperature difference between thermocouple probe and thermometer can result in

inaccurate measurement result. Therefore, allow time for thermal equalization between probe

plug and meter input socket. The thermal equalization procedure takes few minutes and

should be applied only when the probe has been exposed to ambient temperature different

from the meter

EN300-EU-EN-V1.1.doc 6/11

Hygrometer Humidity & Ambient Temperature Measurement

1. Select the Relative Humidity function by pressing "Function Button" until the display indicates

%RH.

2. The humidity and temperature readings will be displayed on the LCD.

3. When the meter is placed into a new environment, a few minutes are required to reach a stable

condition.

Light Measurement

1. Select the Light Measurement function by pressing the "Function Button" until a light unit (Lux

or Ft-cd) is displayed.

2. Press the "Lux/Ft-cd Button" to switch between "Lux" or "Ft-cd".

3. The Display will show the light value

Zero Offset calibration of Light Function:

For best results, zero the light sensor prior to use in a dark environment. To accomplish this,

completely cover the light sensor and then press the "Unit/Zero Button".

The zero point can drift due to environment temperature and battery power change. It is

recommended that the zero be checked frequently using the above procedure.

Sound Level Measurement

1. Select the Sound Level function by pressing the "Function Button" until the Sound level unit

(dB) is displayed.

2. Hold the instrument in one hand and point the microphone towards the noise source. The

sound level value (dB) will be displayed on the LCD.

EN300-EU-EN-V1.1.doc 6/11

Changing °C / °F units

During temperature measurements, press the °C / °F button once to change the temperature units

from "°C" to "°F".

Hold Function

Press the "Hold Button" to freeze the current reading value, "HOLD" symbol appears on the display.

Press the button again to continue normal operation.

Data Record Function

1. The Data Record function records & displays the maximum and minimum reading values. Start

the Data Record function by pressing the "Max/Min Button" once. The "REC" symbol appears

on the display.

2. With the REC symbol on the display :

(a) Press the "Max/Min Button" once and the "Max" symbol along with the maximum value

will appear on the display.

(b) Press the "Max/Min Button" again; the "Min" symbol along with the minimum value will

appear on the display.

seconds. The display will revert to the current reading.

(d) Clear the Max/Min value recorded by pressing the "Hold Button" once. Previous recorded

Max/Min values will be erased and then return to REC function and continue recording.

Auto Power-off

To prolong the life of the batteries, the instrument has an "Auto Power-off" function. The meter will

automatically switch off if there are no button presses in any 10-minute period.

RS232 port

The RS232 port is used to send measurement data to a PC.

Battery Replacement

1. When the LCD display shows " " symbol, it is necessary to replace the battery. However,

measurement may still be made for several hours after the low battery indicator appears.

2. Remove the two battery cover screws and remove the battery cover.

3. Install fresh batteries DC 1.5 V battery, UM4/AAA x 6 PCs, and reinstall the cover.

You, as the end user, are legally bound (Battery ordinance) to return all used batteries

and accumulators; disposal in the household garbage is prohibited!

You can hand over your used batteries / accumulators at collection points in your

community or wherever batteries / accumulators are sold

Disposal: Follow the valid legal stipulations in respect of the disposal of the device at the

end of its lifecycle

EN300-EU-EN-V1.1.doc 6/11

Specifications

General Specifications

Display LCD display, LCD size: 41.5 x 31.5 mm.

Measurement 5 in 1 :

Anemometer (Air velocity + Temperature)

Humidity (%RH + Temperature)

Light

Thermometer ( type K )

Sound level

Operating Humidity 80%RH Max.

Operating Temperature 0 to 50°C (32 to 122°F)

Over Input Display Indication of "- - - - "

Data Output RS 232/USB PC serial interface

Power Supply 1.5 DC V battery ( UM4, AAA ) x 6 PCs,

9V DC adapter input. (AC power adapter is optional).

Power Consumption Anemometer: Approx. DC 11 mA

Other functions: Approx. DC 7.5 mA

Weight 335 g/0.74 lb (battery included).

Dimension HWD 248 x 70 x 34 mm (9.8 x 2.8 x 1.3 inch).

Electrical Specifications

Anemometer (Air velocity/Temperature)

Units Range Res. Accuracy

ft/min 80 to 5910ft/min 1 ≤3900ft/min: ± 3% F.S., >3900ft/min:± 4% F.S.

m/s 0.4 to 30.0m/s 0.1 ≤20m/s : ± 3% F.S., > 20m/s : ± 4% F.S.

km/h 1.4 to 108.0km/h 0.1 ≤72km/h: ± 3% F.S., >72km/h:± 4% F.S.

MPH 0.9 to 67.0mile/h 0.1 ≤45mile/h: ± 3% F.S.,>45mile/h:± 4% F.S.

knots 0.8 to 58.3 knots 0.1 ≤39 knots: ± 3% F.S.,>39 knots:± 4% F.S.

°F 32 to 122°F 0.1 ± 2.5°F

°C 0 to 50°C 0.1 ± 1.2°C

Type K Thermocouple Thermometer

Units Range Resolution Accuracy

°F -148 to 2372 °F 0.1°F ± (1% rdg + 2°F)

°C -100 to 1300 °C 0.1°C ± (1% rdg + 1°C)

Note: The type K thermocouple probe is optional

EN300-EU-EN-V1.1.doc 6/11

Hygrometer (Humidity/Temperature)

Units Range Resolution Accuracy

%RH 10 to 95 %RH 0.1 %RH < 70 %RH :± 4 %RH

 70 %RH :± ( 4%rdg + 1.2 %RH )

°F 32 to 122°F 0.1°F ± 2.5°F

°C 0 to 50°C 0.1°C ± 1.2°C

Light

Units Range Resolution Accuracy

0 to 2,200 Lux 1 Lux

Lux 1,800 to 20,000 Lux 10 Lux

0 to 204.0 Fc 0.1 Ft-cd

Ft-cd 170 to 1,860 Fc 1 Ft-cd

± 5% rdg ± 8 digits

Sound Level

Microphone ½” Electret condenser microphone

Measurement Range 35 to 130 dB, Auto range

Resolution 0.1dB

Frequency response 31.5Hz to 8,000Hz

Weighting " A " frequency weighting network

Time Response "Fast"

Accuracy Meets IEC 61672 class 2,Aweight, Fast response

Note: Stated specification tests under the environment RF Field Strength less than 3 V/M &

frequency less than 30 MHz only

Note: Specification stated for 23± 5°C

Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com

Table des matières

Autres manuels FLIR Instrument de mesure

FLIR

FLIR MR277 Manuel utilisateur

FLIR

FLIR VS80C10-25RM Manuel utilisateur

FLIR

FLIR Imaging Moisture Meter Plus IGM MR176 Manuel utilisateur

FLIR

FLIR Extech Instruments 480823 Manuel utilisateur

FLIR

FLIR EM54 Manuel utilisateur

FLIR

FLIR CM174 C Manuel utilisateur

FLIR

FLIR Extech Instruments MA1500 Manuel utilisateur

FLIR

FLIR EXTECH INSTRUMENTS PQ3450 Manuel utilisateur

FLIR

FLIR Extech HDV-TX2 Manuel utilisateur

FLIR

FLIR TA72 Manuel utilisateur

FLIR

FLIR EXTECH HDV-WTX1 Manuel utilisateur

FLIR

FLIR MR7 Manuel utilisateur

FLIR

FLIR Extech Instruments HDV-WTX2 Manuel utilisateur

FLIR

FLIR VS80 KIT Manuel utilisateur

FLIR

FLIR Extech 380926 Manuel utilisateur

FLIR

FLIR Extech PQ3450-30 Manuel utilisateur

FLIR

FLIR CM72 Manuel utilisateur

FLIR

FLIR MSX MR277 Manuel utilisateur

FLIR

FLIR Extech 380947 Manuel utilisateur

FLIR

FLIR Extech Instruments Oyster-10 Manuel utilisateur

FLIR

FLIR MR55 Manuel utilisateur

FLIR

FLIR CM275 Manuel utilisateur

FLIR

FLIR VS80A2-45-1RM Manuel utilisateur

FLIR

FLIR CM72 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
