FIC AM35 Manuel utilisateur

AM35

MAINBOARD

MANUAL

DOC No.: M01902

Rev. :A0

Date : 4, 2002

Part No. : 25-11635 -00

1 - 1

Overview

Chapter 1

The new 1stMainboard®AM35is an Micro ATX sized motherboard sup-

porting the latest generation of AMD®processors at industry leading speeds.

By utilizing DDR ( Double Data Rate ) transfer rate the 100/133 MHz system

bus effectively reaches Front Side Bus speeds of 200/266 MHz. The board

provides users with anATA133 data transaction for hard drives and allows up

to2 GB memory totallyby 2 PC1600/PC2100 DIMMsockets.

The AM35 is based around the high performance V-link VIA ProSavageDDR

KM266corechipwithVIAVT8233AasaSouthBridge.TheAGP(2X/4X)

functions supported by KM266 provides you with a photo-realistic 3D expe-

rience suitable for the most robust 3D games and software environments.

AC97 Codec that embedded in VT8233A, ensures high quality sound effect.

The mainboard also comes equipped with the new NOVUS®range of innova-

tive features that assist in the installation and maintenance. The features in-

clude Easy Key, which provides instant keyboard access to the BIOS for

adjustments to Clock and Default settings and LogoGenie, which allows you

to create your own customized logo to be displayed during system boot up.

The BIOS Guardian is an Anti Virus utility that prevents viruses from damag-

ing your system BIOS and rendering your system inoperative.

Expansion is provided by 1 AGP(2X/4X) and 3 PCI slots. In addition, the

1stMainboard is equipped standard I/O connections include 2 serial ports (1

bypinheader), 1 parallelport,1 VGA port,1 PS/2 mouse andkeyboard connec-

tor, 4 USB ports (2 by pinheader), 1 IR port by pinheader, and 1 media connec-

tor (Line-In, Line-Out, Mic-In, 1 front audio, 1 game port).

1 - 2

AM35MainboardManual

Package Checklist

If you discover any item below was damaged or lost, please contact your

vendor.

The mainboard This user manual

OneFDDcable  CD software

OneATA100 cable

IMPORTANT:AMDCPUHEATSINKINSTALLATION

Be ware finish heat sink install. Before you boot system, please

check the heat sink is complete contact with die of CPU.

The poor contact will bring about over heat, it may damage your

processor.

Itis stronglyrecommendedthat atleast a 250-wattATXpower pupply

be used for this motherboard. Make sure that your ATX power sup-

ply can supply at least 20 amperes on teh +5-Volt lead and 10mA

on the +5-Volt standby lead (+5VSB). Your system may become

unstable / unreliable and may experience difficulty in powering up if

your power supply is inadequate.

NOTE: CD Pro that contains patch files, onboard video/audio chip

drivers, related online help and other useful information can be

found in your mainboard package.

Please install it right after your Windows operating system installa-

tion is done.Place your CD Pro in the drive, an operating menu will

appears in your monitor. Please select Auto Installation. It will auto-

matically detect which software tools (patch files, drivers) that the

mainboard needs. Press OK button to go through the whole instal-

lation procedure in a very straight forward and easy way. It also

provides you with a custom way to select wanted patch files and

software drivers that for onboard chips use. The top menu of the

CD Pro lists all the functions that allowed by this board.

1 - 3

Overview

The AM35 Mainboard

1 - 4

AM35MainboardManual

Main Features



Easy Installation

||BIOS with support for Plug and Play, auto detection of IDE hard drives,

||LS-120|drives, IDE ZIPdrives, Windows 98SE,Windows ME,Windows

||NT,Windows 2000, Windows XP, and OS/2.



Leading Edge Chipset

VIA KM266 is a single-chip North Bridge for AMD CPUs with 200/266

MHzFront SideBus with AGP and PCIplus advanced memory controller

that supports PC1600/PC2100 DDR SDRAM. VIA VT8233A is a Vlink

client highly integrated controller that supports PC99-compliant system.

The VT8233A also supports ATA133 protocol.



Versatile Main Memory Support

Acceptsup to 2 GB DRAMusing three DDR266DIMMs from 256 MB to

2GBwith support forlightenning-fast(PC1600/PC2100) DDR SDRAM .



EnhancedPCI Bus Master IDE Controllerwith UltraDMA/33/66/100/

133 Support

Integrated Enhanced PCI Bus Master IDE controller features two dual-

channel connectors that up to four Enhanced IDE devices, including CD-

ROM and Tape Backup Drives, as well as Hard Disk Drives supporting

the new UltraDMA/133 Mode 6 protocol, standard PIO Mode 3, PIO

Mode 4, DMA Mode 2, DMA Mode 4, UltraDMA/100 Mode 5 devices

are also supported.



AMD Processors Support

Athlon: 700MHz to 1.4 GHzandup*at 200 MHzFSB/

1.0GHz to1.4GHzat266MHzFSB;

Athlon XP: 1500+to 2100+ andup* at 266 MHzFSB;

Duron: 800MHz to 1.3 GHzand up* at 200MHz FSB

(*: not tested yet)

1 - 5

Overview



AGP and PCI Expansion Slots

One AGP Bus and three PCI Bus expansion slots provided the room to

install a full range of add-on cards.



Compact Onboard Audio Subsystem

Embeded in VIA VT8233A, an integrated high bandwidth Vlink client

controller, direct soundAC97 audio subsystem. UltraDMAmaster mode

EIDEcontroller,USB controller,ACPIenhanced power management,and

PC99compliant.



Super Multi Input/Output (I/O) Support

Integrated Plug and Play multi-I/O chipset features two high-speed UART

16550 compatible serial ports, one EPP/ECP capable parallel port, one

VGA port, one IR port, one game port, and one FDD connector.



Convenient Rear Panel USB Connection Support

Two USB ports integrated in the rear I/O panel and two extra USB ports

for either front or rear panel connection allow convenient and high-speed

Plug and Play connections to the growing number of USB compliant

peripheral devices on the market.



Onboard Accelerated Graphics Port (AGP)

The motherboard is installed one 32-bit 1.5V AGP(2X/4X) bus with a

dedicated 66MHz/133MHz path from the graphics card to the system

memory offering much greater bandwidth than the 32-bit PCI bus does.

AGP enabled 3D graphics cards can directly access main memory across

this fast path instead of using local memory.

1 - 6

AM35MainboardManual



BIOSGuardian

BIOSGuardian bydefault isenabled.It mustbe disabled inorder to reflash

BIOS, thus effectively acts as a fire-wall against viruses that can attack

the BIOS while the system is running.

WARNING: While excute Step3 below, please do not turn off the

sytsem power in order to avoid BIOS damage.

BIOS Guardian can be disabled as follows:

1. Go to BIOS Set Up Menu. (Press Delkey while booting.)

2. Go to Advanced BIOS Features Set Up Submenu.

3. DisableBIOSGuardian.

4. Save the setting, and restart system.

FIC Unique Innovation for Users (NOVUS) -

Enhanced Mainboard Features and System Support



LogoGenie

AuserfriendlyGUI supportingWindows 95/98/98SE(notWindows2000/

NT/ME), LogoGenie allows you to customize, create or select a Logo

which will be displayed when the system is booting.

NOTE:

1. LogoGenie supports Award BIOS only.

2. If you create a Logo file (.bmp) by LogoGenie, the file size must

||||be 640 x 464 x 256 colors.

To enable this utility, please proceed as follows:

1. Insert CD Pro. Select LogoGenie from the Menu

and follow the installation instructions.

2. After LogoGenie has been installed, go to Windows Start Box.

In Programs Menu, select LogoGenie, then select LogoGenie.

3. Press F1 to read Help file to understand how to use this software if

it is new to you.

1 - 7

Overview



Easy Key

Instead of completing the multi-layered BIOS setup process these 3 Easy

Key functions provide direct access to Sub-Menu when completing BIOS

settings adjustments.

Easy-Keys are as follows:

Ctrl+c: To enter clock settings menu.

Ctrl+p: To load Performance Default settings and restart.

Ctrl+f: To load Fail-Safe Default settings and restart.

NOTE: However, if it is disabled and while boot the system, the

POST screen will be held and shows you the message to let you

know the current status of BIOS Guardian. To press G key will en-

able the BIOS Guardian again; or simply to press the space bar

will continue the booting process.

1 - 8

AM35MainboardManual

This Page Left Blank for Note

2 - 1

Installation Procedures

Chapter 2

Installation Procedures

The mainboard has several user-adjustable jumpers on the board that allow you to

configure your system to suit your requirements. This chapter contains information

on the various jumper settings on your mainboard.

To set up your computer, you must complete the following steps:



Step 1 - Set system jumpers



Step 2 - Install memory modules



Step 3 - Install the Central Processing Unit (CPU)



Step 4 - Install expansion cards



Step 5 - Connect ribbon cables, cabinet wires, and power supply



Step 6 - Set up BIOS software



Step 7 - Install supporting software tools

WARNING: Excessive torque may damage the mainboard. When

using an electric screwdriver on the mainboard, make sure that

the torque is set to the allowable range of 5.0 ~ 8.0kg/cm.

Mainboard components contain very delicate Integrated Circuit

(IC) chips. To prevent static electricity from harming any of the

sensitive components, you should follow the following precau-

tions whenever working on the computer:

1. Unplug the computer when working on the inside.

2. Hold components by the edges and try not to touch the IC

||||chips, leads, or circuitry.

3. Wear an anti-static wrist strap which fits around the wrist.

4. Place components on a grounded anti-static pad or on the bag

that came with the component whenever the components are

separated from the system.
