Download Feiyu ON App
Please download Feiyu ON at your smartphone App Store or scan the QR code as below.
iOS Version Android Version
* System requirement: iOS 9.0 or above, Android 6.0 or above
Suggestion
AK4500 includes below information, please read the information before using the
gimbal.
The tutorial videos can be watched at FeiyuTech official website
http://www.feiyu-tech.com/play/
or scan the QR code at the right side.
1. Quick start guide
2. Online instruction
3. Tutorial
AK4500 is a professional 3-axis gimbal specially designed by Feiyutech for DSLR and
mirrorless cameras, which is compatible with most pupular cameras in the market. It is
designed with detachable versatile arm handle, supporting single hand and low angle
shooting, and can be mounted on tripod and other accessories.
AK4500 is designed with function buttons and LCD touch screen, which can switch the
gimbal working mode, control the rotation and parameters setting with one hand. The
camera shutter cable as equipped can be used to directly control the photography, video
recording and follow focus on gimbal.
1. 4500 Overview
Extension Rod
X1
Charger
X1
18650 Li-ion Battery
X4
Tripod
X1
Multifunctional Bracket
X1
Hyperlink
Remote Controller
X1
Versatile Arm
X1
AK Series Brushless
follow focus（AKF2)
X1
Panasonic Lumix
Shutter Cable
X1
Micro USB Cable
X1
USB 2.0 to Micro
(A01)
X1
USB 3.0 to Micro 3.0
(A02)
X1
USB 2.0 to Mini
(B01)
X1
USB 2.0 to Type C
(C01)
X1
Standard Kit Additional Accessories
Accessories
* This product does not include the camera.
01
www.feiyu-tech.com
Sliding arm
lock screw
Quick release plate
safety lock
Cross arm
lock screw
Pan axis
Pan axis
positioning lock
Lens supporting
frame
Secondary
quick release
plate safety
lock
Cross
arm
Shortcut
button
Versatile
arm
Sliding arm
Screw
Anti- column
of quick release
plate
Roll axis
Vertical arm
Multifunction
knob
Handle
Roll axis
positioning lock
Screw
Secondary
quick release
plate
Capturing
button
1/4 inch
thread hole
1/4 inch
thread hole
Tilt axis
Tilt axis
positioning
lock
Function
button
Anti-drop
column Quick
release
plate
Recording button
Power button
Vertical arm
lock screw
Joystick
Fixed plate
Touch screen
Mode button
Camera Control Cable
*Please fully charge the batteries before power on the gimbal for the first time.
Charge the batteries with charger.
Micro USB
Cable
（not included）
5V / 3A
Balanced Lock status Stored Lock status
Each of the three rotating axis has one positioning lock for convenient lock to
balance and storage. Be sure to unlock them before using the gimbal.
2. Start to Use
!
(1) Please install the camera before power on the gimbal.
(2) When the battery is low, please charge the battery.
(3) When not in use, turn off the gimbal and then remove the batteries.
TIPS
2.2 Battery Charging
2.1 Positioning Lock
02
www.feiyu-tech.com
Remove the tail cap, open the batteries cover, and install the batteries correctly.
Align the handle positioning screw with the corresponding positioning holes
under the pan axis machine and then tighten the fixing ring.
Positioning screw
Positioning hole
Stylus
When installing or removing handle, please keep gimbal in vertical position.
Do not move left or right, to prevent the stylus from damage.
18650 Li-ion Battery x4
1
3
2
!
!The four positioning screws must be aligned with the corresponding positioning holes
and then tighten the fixing ring.
Tight
Loose
Alignment
Alignment
2.3 Battery Installation
2.4 Handle Installation
03
www.feiyu-tech.com
Please properly check the
cathode and anode of
batery before put the battery
on,the gibmal can't be
turned on with wrong
battery mounted.
04
www.feiyu-tech.com
2.5 Versatile Arm Installation
Loose
Tighten
Tighten
Loose
Place the display and
function button of the
remote outwards
Tighten the bottom
of the handle
DO NOT turn around
remoter control's handle
Versatile Arm
X1
Fixed Screw
X2
Screw
X1
Accessories needed:
After installation, you can use
versatile arm for low angle shots.
(1)
(2)
Install versatile arm as picture shown, tighten the screws at left and right side
after aligning it's thread hole with Gimbal handle's one.
Tighten Hyperlink remote control (comes with standard version of AK4500) to
the versatile arm tail. Or you can also tighten tripod at it's tail directly for an
option.
Use longer screw to fix the bottom of the remote handle when mounting remote
control or other accessories with 1/4 inch threaded hole .
05
www.feiyu-tech.com
(4) Install the lens support frame to hold the lens firmly.
2.6 Camera Installation
(3) Insert the secondary quick release plate tiltly and press down. The secondary
quick release plate safety lock automatically locks and be firmly tighten.
!
(1) Install the quick release plate to the fixed plate
and take out the secondary quick release plate.
Secondary quick
release plate
!
(2) Tighten the secondary quick release plate to the
bottom of the camera.
Please follow the direction of the icon
on the back of the secondary to mount the camera.
Make sure the battery and memory card are loaded before installation.
Insert the secondary
quick release plate
06
www.feiyu-tech.com
2.7.1 Balance Adjustment of the Tilting Axis
Before balance the gimbal, lock the gimbal with 3 axis positioning lock at first,
unlock each axis positioning lock in stages during the balance process.
For ideal smooth footage, balance the gimbal is necessary, and the gimbal with
perfect balance has longer battery gives longer battery life.
1
2
3
(1) Before balance the gimbal, the lens cover should be removed from the camera and
the memory card needs to be inserted to the camera to complete all the connections to
ensure that the camera is ready for shooting.
(2) During balance the gimbal, make sure the camera is power off and the gimbal is turned off.
(3) If add accessories after the balance is completed, need to re-balance.
1
!TIPS
2.7 Gimbal Balance
a. Unlock the tilt axis positioning lock , place the camera lens vertically upwards,
check the camera's center of gravity.
b. Loosen the sliding arm lock screw , slide the sliding arm to balance the
camera position.
c. Tighten the sliding arm lock screw , if the camera lens can stay vertically
upwards that means balanced.
(1)
1
2
2
3
(2) a. Place the camera lens vertically upwards, check the camera's center of gravity.
b. Unlock the quick release plate safety lock , balance the camera position .
c. Tighten the quick release plate safety lock and tilt the camera up or down, if it
stays stable, it means balanced.
1
1
07
www.feiyu-tech.com
2.7.2 Balance Adjustment of the Rolling Axis
2.7.3 Balance Adjustment of the Panning Axis
1
2
4
3
2
1
3
4
a. Tighten the tilt axis positioning lock , release the roll axis positioning lock , and
check the camera tilt state.
b. Loosen the cross arm lock screw , slide the cross arm to balance the camera position.
c. Tighten the cross arm lock screw and tilt the camera to the left or right, if it stays
stable, it means balanced.
12
4
3
3
a. Tighten the pan axis positioning lock , loosen the pan axis positioning lock , keep
the handle part of the gimbal parallel to the ground and the vertical arm parallel to
the ground, and check the camera rotation after the releasing.
b. Loosen the vertical arm lock screw , slide the vertical arm to balance the camera position.
c. Tighten the vertical arm lock screw to rotate the pan axis to any angle, if it stays stable, it
means balanced.
12
4
3
3
