F&F FW-R2D Manuel utilisateur

F&F Filipowski L.P.

Konstantynowska 79/81, 95-200 Pabianice, PL

phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71

www.fif.com.pl; e-mail: biuro@fif.com.pl

Do not dispose of this device to thrash with other unsorted waste! In accordance

with the Waste Electrical and Electronic Equipment Act any household electro-waste

can be turned in free of charge and in any quan� ty to a collec� on point established for

this purpose, as well as to the store in the event of purchasing new equipment (as per

the old for new rule, regardless of brand). Electro-waste thrown in the trash or aban-

doned in the bosom of nature pose a threat to the environment and human health.

- 1 -

Description of the system

F&Wave is a family of wireless devices controlled by radio with a range of up to 100

meters*. The receivers are available in either a DIN-rail mounting version (housing

1S) or a ø60 flush-mounted version. The transmitters are available as handheld remo-

te controllers or as a flush-mounted version. The receivers relay control signals. The

device that receives a control signal from the transmitter will automatically send it

forward, which allows to increase the range of the remote control.

* Range of up to 100 meters in open space without any interfering factors. In building conditions and in the presence of

interference sources (power lines, transmitters, etc.) the actual range may be smaller.

FW-R2D

Dual bistable relay

- 2 -

Installation of this device should be carried out by a qualified installer after re-

ading this manual. Dismantling the casing of the device will automatically void

the warranty. Before starting the assembly, make sure that the connecting

wires are not live. Conditions of storage, transport and use affect the proper

operation of the device.

Features of the module

Dual bistable relay;

Cooperation with remote control transmitters of the F&Wave system;

The ability to control from up to 8 transmitters;

2 local control inputs - the ability to directly control the relay using any monostable

buttons (for example: bell buttons);

2 independently separated output contact NO with load capacity of 16 A (AC-1);

Compact enclosure - takes only one field in the switchboard;

Retransmission of commands from the transmitter - the ability to increase the

range of the remote control;

Low power consumption - low operating cost;

Built-in electronic thermal protection to prevent damage in case of excessive load

of the relay.

Description of the device

- 3 -

Wiring diagram

1 - L power supply

3 - N power supply

4 - control input triggered with level L

or N - channel 1

6 - control input triggered with level L

or N - channel 2

7/9 - NO contact - channel 1

10/12 - NO contact - channel 2

Control inputs do not cooperate

with backlighted buttons.

Load capacity

2× 16 A/250 V (AC-1)

The actual maximum load depends on the

nature and design of the receiver.

For more information visit: www.fif.com.pl.

Pairing

Each channel of the receiver is independently paired.

①

After proper connection, press and hold the PROG

button until the circuit of the first channel will switch

on and the communication LED will go off.

To select a second channel for pairing, hold the pro-

gramming button again until the circuit of the se-

cond channel switches on.

- 4 -

②Press the selected button on a remote control or in

a flush-mounted transmitter.

③Correct pairing will be confirmed by temporary switching off of the output

circuit and the LED will turn on again.

Each channel of the receiver can be paired with eight different transmitters

(remote buttons). Pairing with more buttons will remove the first entries

made.

Unpairing

To clear the list of transmitters cooperating with the receiver, press the PROG button and hold it

down for at least 10 seconds. Fast flashing of communication LED will indicate that the memory

of the controller has been cleared.

Local buttons

Short press of a button switches the relay in to the opposite state.

Long press of a button (longer than 5 second) activates the relay regardless of the state, in which

the relay was previously in. This feature can be used for synchronizing a group of receivers con-

nected to the same local button. Releasing the button sets the relay in the on position.

Remote buttons

The FW-RC4, FW-RC10 transmitters operate on the principle of a bistable switch: one

press of a button activates the relay; the second press of button deactivates the relay.

The FW-RC5 transmitter also has separate inputs ON (always ON) and OFF (always

OFF).

Due to the nature of transmission and retransmission do not use the same

button in transmitter more often than every 2 seconds. Switching of the re-

ceiver may be carried out with a short delay.

- 5 -

We do not recommend the use of remote bistable transmitters to control a group of

receivers due to the possibility of desynchronization of the activation state (especially

when operating on larger distances and/or simultaneous use of local buttons on the

receivers).

Activation of the thermal protection is indicated by a steady pulsing of communication

LED, switching off of the output circuit and the lack of its reactivation possibility. After

lowering the temperature to a safe value the output circuit will remain switched off

until restarted.

Devices of the F&Wave system

Battery transmitters

Type Product

Flood sensor FW-FS1

Remote control FW-KEY, FW-RC4, FW-RC10

Wall button

FW-WS1, FW-WS2, FW-WS3

FW-WSO1, FW-WSO2, FW-WSO4

Flush-mounted box ø60 FW-RC5

AC transmitters

Type Product

Flush-mounted box ø60

FW-GS1, FW-GS2, FW-GS4

FW-RC4-AC

- 6 -

Devices of the F&Wave system cont.

Receivers

Function Flush-mounted box ø60 DIN rail

Correct operation of LED light bulbs

with devices of the FW-...-NN series FW-BYPASS-NN ---

Universal dimmer FW-D1P FW-D1D

2-channel LED controller FW-LED2P FW-LED2D

Single relay FW-R1P FW-R1D

Single multifunction relay FW-R1P-P,

FW-R1-P-NN FW-R1D-P

Double relay FW-R2P FW-R2D

Double multifunction relay FW-R2P-P,

FW-R2P-NN FW-R2D-P

Roller blind controller FW-STR1P FW-STR1D

Roller blind multifunction controller FW-STR1P-P FW-STR1D-P

Technical data

power supply 85÷265 V AC/DC

control input 85÷265 V AC/DC; <1 mA

power consumption

operating mode 1.00 W

standby 0.25 W

output load capacity (AC-1) 2× 16 A/250 V

radio frequency 868 MHz

maximum emitted frequency power 10 mW

working temperature -25÷65°C

terminal 2.5 mm² screw terminals

tightening torque (max) 0.4 Nm

mounting on TH-35 rail

dimensions 1 module (18 mm)

ingress protection IP20

- 7 -

Warranty

F&F products are covered by a 24 month warranty from the date of purchase.

The warranty is effective only with a proof of purchase.

Contact your dealer or directly with us.

CE declaration

F&F Filipowski L.P. declares that the device is in conformity with the essential require-

ments of Directive 2014/53/EU of the European Parliament and of the Council of 16

April 2014 on the harmonisation of the laws of the Member States relating to the ma-

king available on the market of radio equipment and repealing Directive 1999/5/EC.

The CE Declaration of Conformity, along with the references to the standards in rela-

tion to which conformity is declared, can be found at www.fif.com.pl on the product

page.

Compliance with the standards

PN-EN 55024:2011

PN-EN 60669-1:2006

PN-EN 60669-2-2:2008

PN-EN 62368-1:2015-03

PN-ETSI EN 300 220-1 V3.1.1:2017-08

PN-ETSI EN 300 220-2 V3.1.1:2017-08

PN-ETSI EN 301 489-1 V2.1.1:2017-08

PN-ETSI EN 301 489-3 V1.6.1:2014-03

E230929
