Prodigy FlyPipe

Installation Guide

Part Number: 8006M2100 Rev: G

Released: 2021-06

To view a list of ETCtrademarks and patents, go to etcconnect.com/ip. All other trademarks, both marked

and not marked, are the property of their respective owners.

ETC intends this document, whether printed or electronic, to be provided in its entirety.

Table of Contents

Table of Contents i

Introduction 1

Document Conventions 1

Help from ETC Technical Services 2

Overview 3

Safety and Warnings 3

Working Load Limit (WLL) 4

Hoist Specifications 4

Interface with Building 4

Physical Dimensions 4

Electrical Specifications 5

Lifting Specifications 5

Control and Feedback 5

Hoist Local Controls 5

Begin Hoist Installation 6

Tools Needed 6

Prepare the Installation Location 6

Unpack the Hoist 7

Install Coupler in Span Sections 7

Assemble the Hoist Sections 7

Attach TwinLine Clamps 9

Begin Cable Management Installation 10

Swag Cable Management 10

Helix Cable Management 10

Unpack and Prepare 10

Hang Helix from Upper Attachment Points 11

Run and Verify Hoist Electrics and Data 12

Run Power and Data 12

Emergency Stop Termination 13

Verify Proper Wiring 14

Verify Hoist Is Not On Overtravel Limit 14

Verify Hoist Motor Orientation 14

Terminate Lift Lines to the Drum 15

Step 1:Verify the Drum is At Top Dead Center 15

Step 2: Thread Lift Lines Through SafeStop and Drum 15

Step 3: Attach Stop Sleeves to Lift Lines 16

Step 4: Finalize Lift Line Termination 17

Finalize Hoist and Cable Management Installation18

Attach the Platter to the Hoist 19

Attach Cable Assembly to Platter 20

Ensure SafeStop Devices are Open 21

Float the Hoist 22

Level the Hoist and Test Movement 22

Test Hoist Movement 22

Install Slack Line Sensor Kit 22

Adjust Timing of the Hoist 23

Test and Adjust 24

Adjust SafeStop Device Position for Fleet Angle 24

Configure and Test Hoist Operation 26

Verify Hoist Function 26

Travel Limits 27

Set and Test your Limits 28

ii Prodigy FlyPipe Installation Guide

To Set and Test the Lower Limits 28

To Set and Test the Upper Limits 29

Verify Hoist Address 29

Examine the System 30

Table of Contents iii

1 Prodigy FlyPipe Installation Guide

Introduction

Welcome to the Prodigy FlyPipe Installation Guide. This document provides details on how to

install, test, and manually operate a FlyPipe hoist.

Document Conventions

This document uses the following conventions to draw your attention to important information.

Note:

Notes are helpful hints and information that is supplemental to the main text.

CAUTION:

A Caution statement indicates situations where there may be

undefined or unwanted consequences of an action, potential for data loss or

an equipment problem.

WARNING: A Warning statement indicates situations where damage may

occur, people may be harmed, or there are serious or dangerous

consequences of an action.

WARNING: RISK OF ELECTRIC SHOCK! This warning statement indicates

situations where there is a risk of electric shock.

All ETC documents are available for free download from our website: etcconnect.com.

Please email comments about this manual to: TechComm@etcconnect.com.

Introduction 2

Help from ETC Technical Services

If you are having difficulties and your problem is not addressed by this document, try the ETC

support website at support.etcconnect.com or the main ETC website at etcconnect.com. If none

of these resources are sufficient, contact ETC Technical Services directly at one of the offices

identified below. Emergency service is available from all ETC offices outside of normal business

hours.

When calling for help, take these steps first:

•

Prepare a detailed description of the problem

•

Go near the equipment for troubleshooting

•

Find your notification number if you have called in previously

Please have the following information handy:

•

Product model and serial number (located on motor box)

•

Other components in your system (Foundation, QuickTouch, etc.)

Americas United Kingdom

ETC, Inc. ETC Ltd

Technical Services Department Technical Services Department

3031 Pleasant View Road 26-28 Victoria Industrial Estate

Middleton, WI 53562 Victoria Road,

800-775-4382 (USA, toll-free) London W3 6UU England

+1-608 831-4116 +44 (0)20 8896 1000

service@etcconnect.com techservltd@etcconnect.com

Asia Germany

ETCAsia ETC GmbH

Technical Services Department Technical Services Department

Room 1801, 18/F Ohmstrasse 3

Tower 1, Phase 1 Enterprise Square 83607 Holzkirchen, Germany

9 Sheung Yuet Road +49 (80 24) 47 00-0

Kowloon Bay, Kowloon, Hong Kong techserv-germany@etcconnect.com

+852 2799 1220

techserv-asia@etcconnect.com

France

ETC France

Zone Urbaparc -

Bâtiment E

6 Boulevard de la Libération

Saint-Denis, 93200

+33 1 4243 3535

techservltd@etcconnect.com

3 Prodigy FlyPipe Installation Guide

Chapter 1

Overview

The Overview chapter provides safety information as well as various hoist specifications.

Safety and Warnings

Read this entire installation manual before installing equipment. Please note the following

safety notices before use:

WARNING: ETC Rigging systems must be installed under the supervision of

a person trained and certified in ETC Rigging Installation. If you are not an

ETC Rigging trained technician, do not attempt installation of this

equipment unless you are under the immediate supervision of an ETC

Rigging certified installer.

WARNING: Improper operation may cause serious injury or death.

AVERTISSEMENT : Un fonctionnement incorrect peut provoquer des

blessures graves, voire mortelles.

WARNING: Disconnect power before servicing this equipment.

AVERTISSEMENT : Déconnectez l'alimentation avant d'effectuer

l'entretien de cet équipement.

WARNING: ETC Prodigy hoists and QuickTouch and Foundation control

equipment should not be operated by a user until installation is complete

and the system has been commissioned by an ETC Rigging trained and

certified installer. Only ETC Rigging trained and certified installers are

authorized to operate equipment during the installation and configuration

process.

WARNING: ETC Prodigy hoists and QuickTouch and Foundation control

equipment are designed for the raising and lowering of loads within the

approved hoist capacity only. This equipment is not designed to lift or

automate personnel and such use is strictly prohibited.

WARNING: ETC Prodigy hoists must only be used to move a maximum load

equal to or less than the capacity of your specific hoist. Overloading the

hoist may result in damage to the system or serious injury.

Overview 4

AVERTISSEMENT : Les porteuse de Prodigy doivent uniquement être

utilisés pour déplacer une charge maximale équivalente ou inférieure à sa

capacité nominale. Une surcharge de l'appareil peut entraîner

l'endommagement du système et d'autres biens, des blessures graves, voire

la mort.

Working Load Limit (WLL)

The Working Load Limit (WLL) of any hoist is the maximum load capacity that a user may apply

to a hoist or a hoist system.

All Prodigy hoists have a Working Load Limit. This is identified on the product label on the side

of the motor box. All Prodigy FlyPipe hoists have a Working Load Limit of 225 kg (500 lb).

Prodigy Working Load Limits include a design-safety factor.

WARNING: NEVERexceed the Working Load Limit for any hoist.

Hoist Specifications

The FlyPipe hoist is made up of three different types of sections. Each hoist consists of Drive and

End sections and up to four Span sections. The self-climbing hoist provides strut channel on the

underside of the hoist body from which you can hang fixtures, curtains, or other equipment.

CAUTION:

Using channel hardware with springs can cause severe damage to

Prodigy FlyPipe. Only use channel nuts without springs.

Drive section Span section End section

Motor box

TwinLine

Limit switches

TwinLine clamp

SafeStop device

Splice plate

and cover

Interface with Building

•

Strut channel (i.e. Unistrut® - provided by others) attaches directly to the building

structure

•

Each pair of lift lines (TwinLine) terminate to an adjustable tension beam clamp (TwinLine

clamp), which attaches to the strut channel

Physical Dimensions

•

Drive Section: 3.4 m (11 ft)

•

Span Section: 3.05 m (10 ft)

•

End Section: 2.13 m (7 ft)

•

Motor Box:

1HP Motor: 527 mm (21 in) H x 357 mm (14 in) W x 357 mm (14 in) L

1.5HP Motor: 686 mm (27 in) H x 457 mm (18 in) W x 357 mm (14 in) L

5 Prodigy FlyPipe Installation Guide

Electrical Specifications

•

FlyPipe 120/208 V, three-phase, three-wire + ground power, 60 Hz, 3.8 A, Motor 1 HP

•

FlyPipe 277/480 V, three-phase, three-wire + ground power, 60 Hz, 1.8 A, Motor 1 HP

•

FlyPipe-XL 120/208 V, three-phase, three-wire + ground power, 60 Hz, 4.2 A,

Motor1.5HP

•

FlyPipe-XL 277/480 V, three-phase, three-wire + ground power, 60 Hz, 2.1 A,

Motor1.5HP

•

Power and data control cables plug into Drive section

Lifting Specifications

•

Motor lifting capacity of 225 kg (500 lb)

•

Up to 15 m (50 ft) of vertical travel

•

Hoist is a zero fleet angle self-climber

•

Each section of the hoist contains one pair of lift lines, with spacing between each pair at

3.05 m (10 ft)

•

At minimum, there must be 11 kg (25 lb) of load on each TwinLine pair of lift lines to

avoid a slack line condition

Control and Feedback

•

FlyPipe hoists can be controlled using QuickTouch or Foundation control systems

•

Roller lever limit switches provide mechanical upper and lower travel and overtravel limits

•

Incremental position encoder provides configurable soft travel limit control

•

Hoists trigger automatic shutdown in the event of overload or overcurrent conditions

•

SafeStop System provides secondary fall arrest at each lifting point

Hoist Local Controls

You can find the hoist local controls on the front of the motor box. These controls should be used

for initial operation and testing during installation.

The hoist ships with a cover over the local controls. To access the controls, loosen but do not

remove the three screws securing the cover and then slide the cover to the right.

•

Address dials: Used

to set individual

addresses for each

hoist

•

Indicator LEDs:

Provide general

information for the

hoist

•

Status LEDs: Provides

status when a specific

travel limit has been

reached

•

Override buttons:

Allows you to move

the hoist off of travel

limits that have been

reached

•

Control switch:

Activates manual

hoist movement

Autres manuels pour Prodigy FlyPipe Studio

Table des matières

Autres manuels ETC Équipement d'éclairage

ETC

ETC Halcyon Gold Manuel utilisateur

ETC

ETC ColorSource Spot jr v2.0 Manuel utilisateur

ETC

ETC Express 24/48 Manuel utilisateur

ETC

ETC SolarFrame 750 Manuel utilisateur

ETC

ETC XDLT Manuel utilisateur

ETC

ETC Source Four LED series Manuel utilisateur

ETC

ETC Selador CE Series Manuel utilisateur

ETC

ETC Source Four Revolution Rotating Wheel Module Manuel utilisateur

ETC

ETC Source Four LED Series Manuel utilisateur

ETC

ETC ArcSystem Pro D1 Series Manuel utilisateur

ETC

ETC Source Four CE 405 Manuel utilisateur

ETC

ETC Source Four HID jr Manuel utilisateur

ETC

ETC fos/4 Fresnel Manuel utilisateur

ETC

ETC Selador Series Manuel utilisateur

ETC

ETC D22 Desire series Manuel utilisateur

ETC

ETC Echo Manuel utilisateur

ETC

ETC Source Four Mini CE Manuel utilisateur

ETC

ETC Source Four LED 3 Series Manuel utilisateur

ETC

ETC microVision FX Manuel utilisateur

ETC

ETC Source Four LED Series Manuel utilisateur

ETC

ETC ELTS2 Manuel utilisateur

ETC

ETC Source Four LED Series Guide d'installation

ETC

ETC High End Systems SolaPix 7 Manuel utilisateur

ETC

ETC Source Four Revolution Scroller Cartridge Manuel utilisateur

Manuels Équipement d'éclairage populaires d'autres marques

Brizo

Brizo 8SP-MU-4 Manuel utilisateur

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Manuel utilisateur

IKEA

IKEA BJÖRKSPIREA Manuel utilisateur

Laserworld

Laserworld Evolution Series ES-400RGB Manuel utilisateur

Alien

Alien RG STAR Manuel utilisateur

EuroLite

EuroLite LED B-40 Manuel utilisateur

Qazqa

Qazqa Suplux SL 3 Black 103062 Manuel utilisateur

Commercial Electric

Commercial Electric 54568141 Manuel utilisateur

CREE LIGHTING

CREE LIGHTING 304 Series Manuel utilisateur

Goobay

Goobay 49867 Manuel utilisateur

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Manuel utilisateur

Alkalite

Alkalite Krypton KT-81 Manuel utilisateur

Clas Ohlson

Clas Ohlson GU10 Manuel utilisateur

DTS

DTS DELTA 10 F Manuel utilisateur

ring

ring Solar Steplight Manuel utilisateur

One Stop Gardens

One Stop Gardens 57696 Instructions de montage

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Manuel utilisateur

SIREM

SIREM Swimeo A2 Manuel utilisateur
