Emerson Micro Motion 4200 Manuel utilisateur
Installation Manual
MMI-20058013, Rev AF
November2023
Micro Motion™ 4200 2-Wire Transmitter
Safety messages
Safety messages are provided throughout this manual to protect personnel and equipment. Read each safety
message carefully before proceeding to the next step.
Safety and approval information
This Micro Motion product complies with all applicable European directives when properly installed in accordance
with the instructions in this manual. Refer to the EU Declaration of Conformity for directives that apply to this
product. The following are available: the EU Declaration of Conformity, with all applicable European directives, and the
complete ATEX installation drawings and instructions. In addition, the IECEx installation instructions for installations
outside of the European Union and the CSA installation instructions for installations in North America are available at
Emerson.com or through your local Micro Motion support center.
Other information
Troubleshooting information can be found in the appropriate Configuration and Use Manual. Product data sheets and
manuals are available from the Micro Motion website at Emerson.com.
Return policy
Follow Emerson procedures when returning equipment. These procedures ensure legal compliance with government
transportation agencies and help provide a safe working environment for Emerson employees. If you fail to follow
Emerson procedures, then Emerson will not accept your returned equipment.
Return procedures and forms are available on our web support site at Emerson.com, or by calling the Micro Motion
Customer Service department.
2
Contents
Chapter 1 Planning..................................................................................................................................... 5
1.1 About this document.................................................................................................................. 5
1.2 Related documentation.............................................................................................................. 5
1.3 Meter components......................................................................................................................5
1.4 Installation types......................................................................................................................... 5
1.5 Installation checklist....................................................................................................................8
1.6 Maximum cable lengths between sensor and transmitter..................................................10
Chapter 2 Mounting and sensor wiring................................................................................................. 11
2.1 Mounting and sensor wiring for integral-mount transmitters........................................... 11
2.2 Mount the transmitter to a wall or instrument pole.............................................................11
2.3 Wire the 9-wire remote-mount transmitter to the sensor...................................................16
2.4 Ground the meter components...............................................................................................18
2.5 Rotating the transmitter on the sensor (optional)................................................................19
2.6 Rotating the display orientation..............................................................................................20
2.7 Rotate the sensor wiring junction box on a remote-mount transmitter (optional)..........21
Chapter 3 Wiring the channels................................................................................................................23
3.1 Installation types for the 4200 transmitter............................................................................23
3.2 Available channels.....................................................................................................................24
3.3 Barriers verified by Micro Motion........................................................................................... 25
3.4 Channel power requirements .................................................................................................25
3.5 Access the wiring channels...................................................................................................... 30
3.6 Wire the Channel A mA HART output..................................................................................... 31
3.7 Wire the Channel B mA output................................................................................................32
3.8 Wire Frequency/Discrete output (Channel B)........................................................................ 32
3.9 Wire the mA/SIL output............................................................................................................ 33
Chapter 4 Powering up the transmitter.................................................................................................35
Chapter 5 Configuring the transmitter with Guided Setup.................................................................37
Chapter 6 Using the display controls..................................................................................................... 39
6.1 Configure the display backlight...............................................................................................40
Chapter 7 Communicating with the transmitter..................................................................................41
Installation Manual Contents
MMI-20058013 November2023
Installation Manual 3
Contents Installation Manual
November2023 MMI-20058013
4 Micro Motion 4200 2-Wire Transmitter
1 Planning
1.1 About this document
This manual provides information on planning, mounting, wiring, and initial setup
of the Micro Motion transmitter. For information on full configuration, maintenance,
troubleshooting, or service of the transmitter, see the Micro Motion 4200 Transmitters
Configuration and Use Manual.
The information in this document assumes that users understand basic transmitter and
sensor installation, configuration, and maintenance concepts and procedures.
1.2 Related documentation
See the approval documentation shipped with the transmitter, or download the
appropriate documentation from the Micro Motion web site ( www.emerson.com/
flowmeasurement):
•Micro Motion 4200 Transmitters Configuration and Use Manual
•Micro Motion 4200 2-Wire Transmitter Product Data Sheet
•Micro Motion 4200 2-Wire Safety Manual for Safety Instrumented Systems (SIS)
•ProLink III with ProcessViz Software User Manual
•Replacing the Junction Box for the 4200 Transmitter and the 5700 Transmitter
•Replacing the Sensor Cable for the 4200 Transmitter and the 5700 Transmitter
•Sensor installation manual, which is shipped with the sensor
•FMEDA report for Coriolis Flowmeter with 4200 Transmitter, Prepared for Emerson by
exida.com LLC
1.3 Meter components
A 4200 meter consists of the following components:
•A transmitter
•A sensor
1.4 Installation types
The 4200 transmitter was ordered and shipped for one of two installation types. The fifth
character of the transmitter number indicates the installation type.
Figure 1-1: Installation type indication for 4200 transmitters
The number is located on the device tag on the side of the transmitter.
Installation Manual Planning
MMI-20058013 November2023
Installation Manual 5
Table 1-1: Installation types for 4200 transmitters
Code Description
I Integral mount painted aluminum
C Remote mount painted aluminum
J Integral mount stainless steel
P Remote mount stainless steel
Figure 1-2: 4200 transmitter painted aluminum -- Integral mount
A. Conduit openings
B. Clamping ring
C. Sensor case
D. Transmitter housing cover (hidden from view)
The transmitter is installed directly on the sensor.
The connections between the transmitter and sensor are 9-wire, and do not require field
wiring on the integral mount version.
The I/O connections consist of two channels, each channel being 2-wire. Power must be
supplied to Channel A for the transmitter to operate, while Channel B connections are
optional.
Planning Installation Manual
November2023 MMI-20058013
6 Micro Motion 4200 2-Wire Transmitter
Figure 1-3: 4200 transmitter stainless steel -- Integral mount
A. Clamping ring
B. Junction box
The transmitter is installed remotely from the sensor. The 9-wire connection between the
sensor and transmitter must be field wired. Power supply and I/O must be field wired to
the transmitter. The sensor connection is in the junction box.
Installation Manual Planning
MMI-20058013 November2023
Installation Manual 7
1.5 Installation checklist
□Safety messages are provided throughout this content to protect personnel and
equipment. Read each safety message carefully before proceeding to the next step.
□When choosing a location for components, refer to the following guidelines:
—See the sensor installation manual for information on locating the sensor with
remote-mount or extended-mount electronics.
—Do not install a component in a location where its temperature, humidity, or
vibration limits will be exceeded.
—Maximum distance between components depends on the wire size, the wire type,
and the power supply. Ensure that sufficient power is supplied to the transmitter
terminals.
□If you plan to mount the transmitter in a hazardous area:
—Verify that the transmitter has the appropriate hazardous area approval. Each
transmitter has a hazardous area approval tag attached to the transmitter housing.
—Ensure that any cable used between the transmitter and the sensor meets the
hazardous area requirements.
—For ATEX/IECEx installations, you must strictly adhere to the safety instructions
documented in the ATEX/IECEx approvals documentation available on the
product documentation DVD shipped with the product or at www.emerson.com/
flowmeasurement.
□Verify that you have the appropriate cable and required cable installation parts for your
installation. For wiring between the transmitter and sensor, verify the maximum cable
length does not exceed 60 ft (20 m).
□The transmitter can be mounted in any orientation as long as the conduit openings do
not point upward.
CAUTION
Installing the transmitter with the conduit openings or transmitter display facing
upward risks condensation moisture entering the transmitter housing, which could
damage the transmitter.
□Any fittings, adapters, or blanking elements used on either conduit entries or threaded
joints that are a part of flame proof joints must comply with the requirements of EN/IEC
60079-1 & 60079-14 or CSA C22.2 No 30 & UL 1203 for Europe/International and North
America respectively.
Only qualified personnel can select and install these elements in accordance with
EN/IEC 60079-14 for ATEX/IECEx or to NEC/CEC for North America.
□To prevent conduit connectors from seizing in the threads of the conduit openings,
apply a conductive anti-galling compound to the threads, or wrap threads with PTFE
tape a minimum of two wraps per standard installation practices.
Wrap the tape in the opposite direction that the male threads will turn when inserted
into the female conduit opening.
□To maintain the Ingress protection thread sealant, a sealing washer, or O-ring must be
applied.
Planning Installation Manual
November2023 MMI-20058013
8 Micro Motion 4200 2-Wire Transmitter
—For Zone 1 applications thread sealant must also comply with the requirements of
EN/IEC 60079-14 and thus must be non-setting, non-metallic, non-combustible, and
maintain earthing between the equipment and conduit.
—For Class I, Groups A, B, C, and D applications thread sealant must also comply with
the requirements of UL 1203/CSA C22.2 No. 30.
□Minimize the amount of moisture or condensation inside the transmitter housing.
Moisture inside the transmitter housing can damage the transmitter and cause
measurement error or flow meter failure. To do this:
—Ensure the integrity of all gaskets and O-rings
—Install drip legs on conduit or cable
—Seal unused conduit openings
—Ensure that all covers are fully tightened
□Mount the meter in a location and orientation that satisfies the following conditions:
—Allows sufficient clearance to open the transmitter housing cover. Install with 8–10
inches (200–250 mm) clearance at the wiring access points.
—Provides clear access for installing cabling to the transmitter.
—Provides clear access to all wiring terminals for troubleshooting.
Installation Manual Planning
MMI-20058013 November2023
Installation Manual 9
1.6 Maximum cable lengths between sensor and
transmitter
The maximum cable length between the sensor and transmitter that are separately
installed is determined by cable type.
Cable type Wire gauge Maximum length
MicroMotion 9-wire remote
mount
Not applicable 60ft (18m)
Planning Installation Manual
November2023 MMI-20058013
10 Micro Motion 4200 2-Wire Transmitter
Autres manuels pour Micro Motion 4200
3
Table des matières
Autres manuels Emerson Émetteur
Emerson
Emerson Micro Motion 9739 MVD Guide rapide
Emerson
Emerson Rosemount 2051 Wireless Series Manuel utilisateur
Emerson
Emerson Rosemount 644 Manuel utilisateur
Emerson
Emerson Rosemount 148 Manuel utilisateur
Emerson
Emerson Rosemount 3051 Manuel utilisateur
Emerson
Emerson Rosemount 5081-T Manuel utilisateur
Emerson
Emerson Rosemount 2051 Manuel utilisateur
Emerson
Emerson Rosemount Wireless Permasense WT210 Manuel utilisateur
Emerson
Emerson MAS 2600 Manuel utilisateur
Emerson
Emerson Rosemount 3051 Manuel utilisateur
Emerson
Emerson Rosemount 2051 Manuel utilisateur
Emerson
Emerson Rosemount 8750W Manuel utilisateur
Emerson
Emerson Rosemount 3051HT Manuel utilisateur
Emerson
Emerson Rosemount 5408 Manuel utilisateur
Emerson
Emerson Rosemount 3144P Manuel utilisateur
Emerson
Emerson Rosemount 4600 Manuel utilisateur
Emerson
Emerson Rosemount 3308 Series Manuel utilisateur
Emerson
Emerson Rosemount 1057 Manuel utilisateur
Emerson
Emerson Liebert SL-31080 Manuel utilisateur
Emerson
Emerson Rosemount 3051HT Manuel utilisateur
Manuels Émetteur populaires d'autres marques
Dejero
Dejero EnGo 3x Manuel utilisateur
Rosemount
Rosemount 4600 Manuel utilisateur
Speaka Professional
Speaka Professional 2342740 Manuel utilisateur
trubomat
trubomat GAB 1000 Manuel utilisateur
Teledyne Analytical Instruments
Teledyne Analytical Instruments LXT-380 Manuel utilisateur
Rondish
Rondish UT-11 Manuel utilisateur
