USER GUIDE

GPU WATER BLOCK

EK-Quantum

Vector² Trio RTX 4090 D-RGB ABP Set

Please note the installation of the product is intended to be undertaken

by an adequately trained and experienced person. You are installing the

product at your own risk. If you are not properly trained or experienced

or feel unsure about the installation procedure, please refrain from

installing the product yourself and contact our tech support for

assistance. We disclaim our liability for any damages to the product as

well as incidental, consequential, or indirect damages incurred due to

improper or inappropriate installation.

Before you start using this product, please follow these basic guidelines:

Remove your graphics card from the computer for the safest

mounting process to prevent any possible damage to your

GPU or its circuit board (PCB).

The EK Fittings require only a small amount of force to screw

them ﬁrmly in place since the liquid seal is ensured by the

rubber O-ring gaskets.

The use of corrosion-inhibiting coolants is always

recommended for liquid cooling systems and mandatory for

nickel-plated water blocks!

Do not use pure distilled water!

For best results, EK recommends the use of EK-CryoFuel

coolants! To reach optimal performance, make sure to

thoroughly bleed the air out of your water block!

- 3 -

TABLE OF CONTENTS

BOX CONTENTS 4

WATER BLOCK DIMENSIONS 5

TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS 6

NICKEL PLEXI 6

PREPARING THE GRAPHICS CARD 7

REMOVING THE STOCK COOLER 7

MSI GeForce RTX 4090 Suprim X 24G 7

PREPARING THE WATER BLOCK FOR INSTALLATION 8

CUTTING AND PLACING THERMAL PADS 10

APPLYING THERMAL COMPOUND 11

ATTACHING THE WATER BLOCK 11

ATTACHING THE AC TIVE BACKPLATE 13

FITTINGS AND TUBING 15

INSERTING THE GRAPHICS CARD INTO THE CHASSIS 15

CONNECTING THE D-RGB LED STRIP 16

TESTING THE LOOP 16

WARRANTY 17

SUPPORT AND SERVICE 18

SOCIAL MEDIA 18

- 4 -

Thermal Grease (1 pc)

BOX CONTENTS

4 mm

8 mm

10 mm

EK-Loop Multi Allen Key (1 pc)

Allen Key 2 mm (1 pc)

Allen Key 2.5 mm (1 pc)

M2.5x8 AX1 Screw (1 pc)

M3x10 AX1 Screw (1 pc)

EK-Quantum Vector2Trio RTX

4090 D-RGB ABP Set

M2.5x4 AX1 Screw (9 pcs)

Polyamid Washer M2.5 0.5mm (9 pcs)

Standoff Ø4.5/2.5 (1 pc)

Quantum Plug (2 pcs)

EK-Plug Out Spludger Tool (1 pc)

Standoff M2.5-M3 x 6.6mm (1 pc)

Nut M2.5 (2 pcs)

Terminal OR - Vector

14x1 mm (2 pcs)

EAN: 106080

EAN: 106046

Thermal Pad F 1.0 mm (9 pcs)

(3830046996732)

Thermal Pad G 2.0 mm (2 pcs)

(3830046996794)

120 mm

16 mm

120 mm

24 mm

- 5 -

WATER BLOCK DIMENSIONS

307 mm

95.5 mm

123.5 mm

133 mm

142.5 mm

155 mm

41 mm

35.5 mm

- 6 -

TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS

NICKEL PLEXI

- Dimensions: (L x H x W): 307 x 155 x 41 mm

- D-RGB LED count: 30

- D-RGB cable length: 2 x 50 cm

- D-RGB connector 3-pin 5V digital LED header

(Pinout: +5V | Data | Blocked | Ground)

Position EAN Description Quantity

1106062 Coldplate (Ni) 1

2106063 Top plate (Plexi) 1

3106069 LED Cover (N. Elox) 2

4103964 Mylar sticker 2

5100663 EK - Badge 2

68208 Screw M3 x 8 7991DIN 2

7104106 Terminal OR - 14 x 1 mm 4

8103942 Terminal Badge 1

9103988 Standoff M4-M2.5 x 3 mm 4

10 103987 Standoff M3.5-M2.5 x 3 mm 4

11 103986 Standoff M3.5-M2.5 x 11.3 mm 7

12 9024 Screw M4 x 10 DIN7984 15

13 106077 Main OR 160 x 2 mm 1

14 103962 Plexi insert 1

15 104099 Stand out (Acetal) 1

16 104395 Terminal Plate (Ni) 1

17 104414 OR 53 x 2 mm 1

18 105163 Disc magnet 3 x 2 4

19 104086 Backplate Terminal Badge 1

20 8311 Screw M4 x 20 DIN7984 6

21 8201 Screw M3 x 10 DIN7991 2

22 104393 FC Terminal (Acetal) 1

23 106076 Sideplate (B. Elox) 1

24 106072 Top plate ABP (Plexi) 1

25 106071 Coldplate ABP (Ni) 1

26 104093 Standoff M2.5-M3 x 6.6 (Ni) 8

27 104105 Screw AX1 M3 x 10 mm 8

28 9013 Screw M4 x 8 DIN7984 14

29 106078 Main OR ABP 165 x 2 mm 1

30 106081 PCB cardboard 1

31 101556 LED D-RGB strip 500/300 mm 2

- 7 -

Important! Before starting, make sure to have a clean, ﬂat

surface to work on. It is recommended to put foam or soft

material to lay the graphics card on.

REMOVING THE STOCK COOLER

MSI GeForce RTX 4090 Suprim X 24G

STEP 1

First, remove twelve (12) screws

from thebackside ofthe Stock cooler

(using a Phillips head screwdriver)

and detach the backplate. After

removing the backplate, additional

(4) blue-marked screws must be

removed to detach the retention

bracket.

PREPARING THE GRAPHICS CARD

STEP 2

Five (5) screws must be removed to detach the I/O Bracket. Save the

I/O Bracket and marked screw for later use.

Lastly, one (1) blue-marked screw must be removed. Unplug the

connectors and remove the stock cover from the GPU PCB.

STEP 1

STEP 2

Phillips Head Screwdriver

For this step, you will need:

Phillips Head Screwdriver

For this step, you will need:

SAVE FOR LATER STEPS

RETENTION BRACKET

I/O BRACKET

- 8 -

PREPARING THE WATER BLOCK FOR INSTALLATION

Allen Key 2.5mm

TERMINAL

BADGE

STEP 1

First, remove the terminal badge which is attached to the terminal with

two magnets. Under the badge, unscrew three (3) screws M4 x 20

DIN7984. Additional eight (8) screws M3 x 10 AX1 need to be removed

(as shown in the image). Save the removed parts for later use.

DO NOT REMOVE THE UPPER TERMINAL BADGE!

STEP 1

For this step, you will need:

Phillips Head Screwdriver

M3 x 10 AX1 SCREW

M4 x 20 DIN7984 SCREW

UPPER TERMINAL BADGE

- 9 -

STEP 3

Unscrew eight (8) M2.5-M3 x 6.6 standoffs with the provided

tool (EK-Plug out Spludger Tool). Make sure not to unscrew the

M3.5-M2.5 x 11.3 standoffs! In case the M3.5-M2.5 x 11.3 standoffs

unscrew, carefully tighten it back with the 4 mm wrench. After

removing the standoffs, the PCB cardboard needs to be removed.

Save the removed standoffs for later use.

M2.5-M3x6.6 STANDOFF

M3.5-M2.5x11.3 STANDOFF

STEP 2

Carefully remove the complete active backplate with the terminal.

Additional two (2) O-rings 14 x 1 mm needs to be removed.

ACTIVE BACKPLATE

TERMINAL

O-RING 14x1 mm

For this step, you will need:

EK-Plug Out Spludger Tool

PCB CARDBOARD

- 10 -

CUTTING AND PLACING THERMAL PADS

STEP 1

The GPU water block comes with thermal pads that have to be cut

into smaller pieces to cover all the VRM components, such as COILs,

MOSFETs, and drivers.

Remove the protective foil from both sides of the thermal

pad before installation.

Replacement thermal pads:

Thermal Pad F 1.0 mm – (120 x 16 mm) EAN: 3830046996732

Thermal Pad G 2.0 mm – (120 x 24 mm) EAN: 3830046996794

STEP 2

Once cut to the size, Thermal Pads should be placed on the PCB, as

shown in the picture

STEP 2

Thermal Pad - 120 x 16 x 1.0 mm

STEP 1

Thermal Pad F – 1.0 mm (120 x 16 mm)

120 mm

16 mm

1 mm

Thermal Pad G – 2.0 mm (120 x 24 mm)

120 mm

24 mm

2 mm
