699 Keypad Deskstand

Description

The 699 Keypad Deskstand is a mounting stand congured for all DMP LCD keypad models. The 699 is constructed

of smoked plexiglass or metal and provides a sturdy keypad mounting option for any location. Designed to provide

access to all DMP keypad wiring headers allows quick and easy keypad wire connections.

What is Included

• 699 Keypad Deskstand

• Wiring Block

• Wire Harness 4 ft.

• Four round head self-tapping Phillips mounting screws

Note: When using the 7760 Clear Touch Keypad a 778 Keypad Backplate is needed to enhance the keypad display.

Mounting Keypads

Standard Keypad Mounting

Use the round head self-tapping Phillips screws to mount the keypad base to the 699 Deskstand. Refer to Figure 1 as

needed.

1. Refer to the keypad installation guide and remove the cover from the keypad base.

2. Align the keypad base to the four keypad mounting holes on the 699 Deskstand.

3. Insert the screws through the keypad base and 699 Deskstand.

4. Use a Phillips head screwdriver to tighten the four screws into place. Do not overtighten.

5. Replace the keypad cover.

Wire Harness wire tie

strain relief mounting

holes located in

Deskstand base.

Premounted feet (4 places)

Deskstand Front View

Deskstand Side View

Thin Keypad

on 699 Deskstand

Optional Wire

Harness wire

tie strain relief

mounting hole.

690 and 790 Series

Keypad mounting holes.

Use self-tapping Phillips

head screws.

Keypad wiring

harness

openings

Clear Touch

Keypad

mounting hole. Clear

Touch

Keypad

mounting

hole.

Clear Touch Keypad wiring harness opening.

778 Backplate ush mounting holes.

Figure 1: 699 Keypad Deskstand

InstallatIon GuIde

Clear Touch Keypad Mounting

The 778 Backplate comes with four at head screws and nuts and two round Phillips head screws and nuts. Use the

four at head screws and nuts to ush mount the 778 Backplate to the 699 Deskstand. Use the two round Phillips

head screws and nuts to mount the keypad base. When mounting is complete the Clear Touch Keypad legs rest on the

lower ush mounted screws. Refer to Figure 2 as needed.

1. Align the 778 Backplate to the ush mounting holes and insert the ush mount screws through the backplate

and 699 Deskstand.

2. Place a nut on the end of each ush mount screw, hold the nut in place, and use a at head screwdriver to

tighten the four screws in place.

3. Refer to the glass keypad installation guide and remove the cover from the keypad.

4. Align the keypad base to the two keypad mounting holes on the 778 Backplate.

5. Insert the round Phillips head screws through the keypad base, 778 Backplate, and 699 Deskstand.

6. Place a nut on the end of each screw, hold the nut in place, and use a Phillips head screwdriver to tighten the

keypad base in place.

7. Replace the keypad cover.

Clear Touch

Keypad

mounting hole.

Premounted feet (4 places)

Clear Touch Keypad wiring harness opening.

778 Backplate

side view.

Deskstand and 778 Backplate Front View

Deskstand and 778 Backplate Side View

Clear

Touch

Keypad

mounting

hole.

Flush mounting holes.

Wire Harness wire tie

strain relief mounting

holes located in

Deskstand base.

Figure 2: 699 Keypad Deskstand with 778 Backplate Installed

Wiring

Panel to Wiring Block Connections

The wiring block can be mounted on a wall near the baseboard, or

other unobtrusive location.

1. Insert a at head screwdriver into the slot on each side of the

wiring block to remove the cover.

2. Remove the Phillips head screws from inside the wiring block.

Use either the provided Phillips head screws or square of double

stick tape to mount the wiring block.

3. Connect the Red, Yellow, Green, and Black wires from Panel

Terminals 7, 8, 9, and 10 to the wiring block as shown in

Figure 3.

4. Snap the wiring block cover back into place.

5. Plug the modular plug end of the 4 ft. wire harness into the

wiring block modular receptacle.

To Panel Terminal 7 - Red

To Panel Terminal 8 - Yellow

To Panel Terminal 9 - Green

To Panel Terminal 10 - Black

Black Yellow

Red Green

Modular

Receptacle

Mounting

holes

(2 places)

Cover

Removal

Slot

(2 places)

Figure 3: Wiring Detail

Digital Monitoring Products 699 Installation Guide

Wiring Block to Keypad Connections

As needed, refer to the specic keypad installation guide. Plug the terminal end of the 4 ft. wire harness onto the

4-pin header in the back of the keypad through the back of the 699 Deskstand.

RED YEL GRN BLK

7 8 9 10

XT30/XT50

XR100/XR500

Panel

Terminals 7-10

Thin Keypad on

699 Deskstand

Black Yellow

Red Green

Mounting

holes

(2 places)

Wiring

Block

Modular

Receptacle

Figure 4: Panel to Keypad Wiring

Keypad Rear Connections

Figure 5 shows the 699 Backplate rear view with the 4-wire connector plugged into the 4-pin header. Run a tie wrap

through the back or base of the 699 Deskstand. Roll the excess length of the 4 ft. Wire Harness into a loop and use

the tie wrap to hold it in place.

Wire Harness with wire

tie strain relief in place.

4-wire

connector

plugged

into keypad

4-pin header.

Deskstand Rear View

RED

To Wiring Block

Optional 4-wire

connector locations

depending on the

specific keypad installed.

Optional Wire

Harness wire

tie strain relief

mounting hole.

4 ft. Wire Harness wire tie strain relief

mounting holes located in Deskstand base.

Figure 5: 699 Backplate Rear View

699 Installation Guide Digital Monitoring Products

800-641-4282

      

www.dmp.com 2500 North Partnership Boulevard



 

12175

Specications

Dimensions 6.8" W x 5.25" H x 5" D

Ordering Information: 699 Plexiglass

699-W Metal

Compatibility

The 699 Keypad Deskstand is compatible with all

DMP LCD Keypad models.

Accessories

778 Keypad Backplate

Dimensions 6.57" W x 4.57" H

Wiring Specications

When planning a keypad bus installation, keep in mind the following specications:

1. DMP recommends using 18 or 22-gauge unshielded wire for all keypad and LX-Bus circuits. Do Not use

twisted pair or shielded wire for LX-Bus and keypad bus data circuits. To maintain auxiliary power integrity

when using 22-gauge wire do not exceed 500 feet. When using 18-gauge wire do not exceed 1,000 feet.

Install an additional power supply to increase the wire length or add devices.

2. Maximum distance for any one circuit (length of wire) is 2,500 feet regardless of the wire gauge. This

distance can be in the form of one long wire run or multiple branches with all wiring totaling no more than

2,500 feet. As wire distance from the panel increases, DC voltage on the wire decreases.

3. Maximum number of devices per 2,500 feet circuit is 40.

Note: Each panel allows a specic number of supervised keypads. Add additional keypads in the unsupervised

mode. Refer to the panel installation guide for the specic number of supervised keypads allowed.

4. Maximum voltage drop between the panel (or auxiliary power supply) and any device is 2.0 VDC. If the

voltage at any device is less than the required level, add an auxiliary power supply at the end of the circuit.

When voltage is too low, the devices cannot operate properly.

Refer to the LX-Bus/Keypad Bus Wiring Application Note (LT-2031). Also see the 710 Module Installation Sheet

(LT-0310) for more information.
