CS-175-275-575 Series

LCD User Guide

98/482/EC Declaration

(Applies to products that have CE mark attached)

This equipment has been approved in accordance with Council Decision 98/ 82/EC for Pan-European single

terminal connection to the public switched telephone network (PSTN). However, due to differences between

the individual PSTNs provided in different countries, the approval does not, of itself, give an unconditional

assurance of successful operation on every PSTN network termination point.

Aritech is an Interlogix company.

Interlogix B.V. reserves the right to change information without notice.

3CS-175-275-575 Series • LCD User Guide

Contents

LCD keypad ........................................................... 4

Preparing your syste .......................................... 6

Turning on your syste ......................................... 7

Turning off your syste ........................................ 8

Turning off your syste in case of alar .............. 9

Bypassing (excluding) one or ore zones............ 10

Life safety functions ............................................ 12

Resetting fire detectors ....................................... 13

Changing user codes........................................... 14

Deleting user codes............................................. 15

Setting the keypad tone ..................................... 16

Setting the syste clock ..................................... 17

Viewing zone status ........................................... 19

Viewing alar e ory ...................................... 20

Reading the event log ........................................ 21

Adjusting view/brightness

of the LCD (text display) ..................................... 22

Service essages display .................................... 23

Glossary of ter s ............................................... 26

CS-175-275-575 Series • LCD User Guide 4

LCD keypad

Power (green): When lit, the

system is connected to the mains

power.

Stay: Press to arm perimeter

protection when on the premises.

Bypass: Press to bypass (exclude) a

zone (or zones) in the event of a

zone fault.

Navigation: Press to scroll through

menu on LCD display.

Star: Used to enable certain

functions.

Ready (green): When lit, the

system is ready to be turned on.

ire (red): When lit, the fire zone

has been activated.

LCD display: Messages.

Away: Press to arm complete

system when leaving the premises.

Chime: Press to turn the chime on

and off.

5CS-175-275-575 Series • LCD User Guide

LCD keypad

aPower (green). The power light is on if the system is

connected to the mains and if the battery is okay. The

power light will flash if the system has a low battery condition

or when the battery is not connected. The power light is off if

the mains is cut.

bReady (green). The ready LED is on when the system is

ready to arm, and flashes when the system is ready to

force arm. If the LED is off, the system cannot be armed,

generally because there is a zone fault.

cFire (red). When the fire LED is lit, a fire zone has been

activated. A rapidly flashing fire LED means that there is a

problem with the fire zone.

gStay. This function key part arms your system. Pressing it

disarms all interior zones but leaves the perimeter

protected.

hAway. Press to arm all zones before leaving.

iBypass. Press to bypass (exclude) zones.

jkNavigation keys. These allow you to scroll

through lists and options on the LCD display.

lChime. Press to turn the chime on and off.

@Hash key. Used to access modules and locations.

$Star. Used to access tasks and enter data.

6CS-175-275-575 Series • LCD User Guide

Preparing your system

LCD Message: Your system is NOT ready to be turned on,

doors or windows might be open.

User Action: Use the up/down arrow.

LCD Message: Zone information.

User Action: Press the bypass key if you want to bypass (exclude)

a zone, so you can arm part of your system.

LCD Message: Zone information.

User Action: Press #.

LCD Message: Your system is ready to be turned on.

System Not Ready

For help, press

System Ready

Type code to arm

jor k S

i S

@ S

X Fault

Zone X

X Bypass

Zone X

X Fault Bypass

Zone X

X Okay

Zone X

7CS-175-275-575 Series • LCD User Guide

Turning on your system

LCD Message: Your system is ready to be turned on.

User Action: For stay mode, push the stay button,

for away mode push the away button.

LCD Message: Your system is either protected

partially or completely.

LCD Message: Your system is ready to be turned on.

User Action: Type your user code for arming.

LCD Message: Your system is turned on.

OPTION 1: Using the function keys (This feature must be programmed by the installer.)

e S

System Ready

Type code to arm

System Armed

All Zones Secure

System Ready

Type code to arm

OPTION 2: Typing your user code

g S h S

System Armed

Zone(s) Bypassed

System Armed

All Zones Secure

8CS-175-275-575 Series • LCD User Guide

Turning off your system

LCD Message:Your system is turned on.

User Action: Type your user code to turn off your system.

System Armed

All Zones Secure

e S

System Ready

Type code to arm LCD Message: Your system is ready to be turned on.

9CS-175-275-575 Series • LCD User Guide

Turning off your system in case of alarm

User Action: Type your user code to turn off your system.

LCD Message: The last alarm is shown on the LCD message

for verification.

User Action: Press #to leave this LCD message.

LCD Message: Your system is ready to be turned on.

X Alarm Mem.

Zone X

System Ready

Type code to arm

ALARM Zone X

e S

LCD Message: An alarm has occurred in zone X.

@ S

10CS-175-275-575 Series • LCD User Guide

Bypassing (excluding) one or more zones

LCD Message: Your system is NOT ready to be turned on.

User Action: Use the up/down arrow.

LCD Message: Shows the state of the first zone.

User Action: Use the up/down arrow.

LCD Message: Zone information.

User Action: Press the bypass key to toggle

between ‘Okay’ and ‘Bypass’.

or LCD Message: Zone information.

User Action: Press #to exit this menu. 

System Not Ready

For help, press

2 Bypass

Zone 2

@ S

2 Okay

Zone 2

jk S

i S

1 Okay

Zone 1

2 Okay

Zone 2

2 Bypass

Zone 2
