Model 7900

Installation Guide

DRAFT

Bitwriter®, Code Hopping™, Doubleguard®, ESP™, FailSafe®, Ghost Switch™, Learn Routine™, Nite-

Lite®, Nuisance Prevention® Circuitry, Revenger®, Silent Mode™, Soft Chirp®, Stinger®, Valet®,

Vehicle Recovery System®, VRS®, and Warn Away® are all Trademarks or Registered Trademarks of

Directed Electronics.

New Software Compatibility for

103T Keypad

This unit now has software that

allows arming with entry delay when

used in conjunction with the optional

103T Keypad. Refer to the 103T

Owner’s Guide for details.

The Bitwriter®(p/n 998T)

requires chip version 2.2 or

newer to program this unit.

DRAFT

table of contents

what is included. . . . . . . . . . . . . . . . . . . . . . . . . . .4

warning! safety first. . . . . . . . . . . . . . . . . . . . . . . .4

installation points to remember . . . . . . . . . . . . . . .5

before beginning the installation. . . . . . . . . . . . .5

after the installation . . . . . . . . . . . . . . . . . . . . .5

deciding on component locations . . . . . . . . . . . . . .6

locations for the siren . . . . . . . . . . . . . . . . . . . .6

locations for the control module . . . . . . . . . . . . .6

locations for stinger doubleguard shock sensor . . .7

mounting the antenna . . . . . . . . . . . . . . . . . . . .7

locations for valet/program switch . . . . . . . . . . . .8

locations for the status LED . . . . . . . . . . . . . . . . 8

finding the wires you need . . . . . . . . . . . . . . . . . . .9

locations for the optional starter kill relay . . . . . .9

locations for the relay satellite . . . . . . . . . . . . . .9

obtaining constant 12V . . . . . . . . . . . . . . . . . . .9

finding the 12V switched ignition wire . . . . . . . . 10

finding the starter wire . . . . . . . . . . . . . . . . . . 10

finding the tachometer wire . . . . . . . . . . . . . . . 11

finding the accessory wire . . . . . . . . . . . . . . . . 11

finding the wait-to-start bulb wire for diesels . . . 11

finding a (+) parking light wire . . . . . . . . . . . . . 12

finding the door pin switch circuit. . . . . . . . . . . 12

making your wiring connections . . . . . . . . . . . . . .13

primary harness (H1), 12-pin connector . . . . . . . .14

auxiliary harness (H2), 6-pin connector. . . . . . . . .14

door lock harness, 3-pin connector . . . . . . . . . . . .15

remote start ribbon harness, wiring diagram . . . . .15

heavy gauge inline connector key switch interface .16

remote start harness (H3), 5-pin connector . . . . . .16

horn, channel 6 (H4), 2-pin connector . . . . . . . . .16

relay satellite wire connection guide . . . . . . . . . . .23

remote start secondary harness (H3) wire . . . . . . . . .

connection guide . . . . . . . . . . . . . . . . . . . . . . . . .24

horn, channel 6 harness (H4) wire connection guide26

neutral safety switch interface . . . . . . . . . . . . . . .26

testing the neutral safety switch . . . . . . . . . . . . 27

bypassing GM vehicle anti-theft systems (VATS) . . .29

1995 and newer vehicle anti-theft systems . . . . . . . .

(immobilizers). . . . . . . . . . . . . . . . . . . . . . . . . . .30

passlock I and passlock II (PL-1 and PL-2) . . . . . 30

passkey III (PK-3), transponder-based systems . . 30

plug-in LED and valet/program switch . . . . . . . . . .31

programmer interface, 3-pin black plug . . . . . . . . .31

shock sensor harness, 4-pin connector. . . . . . . . . .32

tach learning . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

programming jumpers. . . . . . . . . . . . . . . . . . . . . .33

tach threshold on/off. . . . . . . . . . . . . . . . . . . . 33

light flash (+)/(-) . . . . . . . . . . . . . . . . . . . . . . 33

transmitter/receiver learn routine™. . . . . . . . . . . .34

standard configuration . . . . . . . . . . . . . . . . . . . 36

remote control diagram. . . . . . . . . . . . . . . . . . . . .37

standard mode configuration. . . . . . . . . . . . . . . . .38

multi-level security arming . . . . . . . . . . . . . . . . . .39

system features learn routine . . . . . . . . . . . . . . . .40

feature menus . . . . . . . . . . . . . . . . . . . . . . . . . . .42

menu #1 - basic features . . . . . . . . . . . . . . . . . 42

menu #2 - advanced features. . . . . . . . . . . . . . . 43

menu #3 - remote start options . . . . . . . . . . . . . 44

feature descriptions . . . . . . . . . . . . . . . . . . . . . . .45

menu #1 - basic features . . . . . . . . . . . . . . . . . 45

menu #2 - advanced features. . . . . . . . . . . . . . . 46

menu #3 - remote start options . . . . . . . . . . . . . 49

valet mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

rear defogger control . . . . . . . . . . . . . . . . . . . . . .51

timer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

table of zones . . . . . . . . . . . . . . . . . . . . . . . . . . .53

shutdown diagnostics . . . . . . . . . . . . . . . . . . . . . .53

to perform shutdown diagnostics . . . . . . . . . . . . 53

long term event history . . . . . . . . . . . . . . . . . . . .54

safety check . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .55

alarm troubleshooting . . . . . . . . . . . . . . . . . . . 55

remote start troubleshooting. . . . . . . . . . . . . . . 56

wiring quick reference guide. . . . . . . . . . . . . . . . .58

relay satellite wiring quick reference guide . . . . . .59

DRAFT

what is included

■ The control module ■ The plug-in status LED

■ A Responder receiver/antenna ■ The plug-in Valet/Program switch

■ One 2-way Color Remote Control P/N 7541V ■ A hood pinswitch

■ A Stinger Doubleguard shock sensor ■ A toggle (override) switch

■ A 514N Neosiren ■ One Remote Control car charger

warning! safety first

The following safety warnings must be observed at all times:

■Due to the complexity of this system, installation of this product must only be performed by an authorized

Directed Electronics dealer.

■When properly installed, this system can start the vehicle via a command signal from the remote control

transmitter. Therefore, never operate the system in an area that does not have adequate ventilation. The

following precautions are the sole responsibility of the user; however, authorized Directed Electronics dealers

should make the following recommendations to all users of this system:

1. Never operate the system in an enclosed or partially enclosed area without ventilation (such as a

garage).

2. When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote

start system must be disabled using the installed toggle switch.

3. It is the user's sole responsibility to properly handle and keep out of reach from children all remote

control transmitters to assure that the system does not unintentionally remote start the vehicle.

4. THE USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT

TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY

ENCLOSED VEHICLE STORAGE AREA MUST AT ALL TIMES REMAIN CLOSED.

■Use of this product in a manner contrary to its intended mode of operation may result in property damage,

personal injury, or death. Except when performing the Safety Check outlined in this installation guide, (1)

Never remotely start the vehicle with the vehicle in gear, and (2) Never remotely start the vehicle with the

keys in the ignition. The user will be responsible for having the neutral safety feature of the vehicle periodi-

cally checked, wherein the vehicle must not remotely start while the car is in gear. This testing should be

performed by an authorized Directed Electronics dealer in accordance with the Safety Check outlined in this

product installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult

with the user to fix the problem immediately.

DRAFT

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2) This device must accept any interference received,

including interference that may cause undesirable operation.

Changes or modifications not expressly approved by the party responsible for compliance could void the user's

authority to operate this device.

caution

This product is designed for fuel injected, automatic transmission vehicles only. Use of this product in a standard

transmission vehicle is dangerous and contrary the product's intended use.

DRAFT

■After the remote start module has been installed, test the remote start module in accordance with the

Safety Check outlined in this installation guide. If the vehicle starts when performing the Neutral Safety

Shutdown Circuit test, the remote start unit has not been properly installed. The remote start module must

be removed or properly reinstalled so that the vehicle does not start in gear. All installations must be per-

formed by an authorized Directed Electronics dealer. OPERATION OF THE REMOTE START MODULE IF THE

VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPERATING THE REMOTE

START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY.

IMMEDIATELY CEASE THE USE OF THE UNIT AND REPAIR OR DISCONNECT THE INSTALLED REMOTE START

MODULE. DIRECTED ELECTRONICS, INC. WILL NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR

REINSTALLATION COSTS.

installation points to remember

IMPORTANT! This product is designed for fuel-injected, automatic transmission vehicles only.

Installing it in a standard transmission vehicle is dangerous and is contrary to its intended use.

before beginning the installation

■Please read this entire installation guide before beginning the installation. The installation of this remote

start system requires interfacing with many of the vehicle’s systems. Many new vehicles use low-voltage or

multiplexed systems that can be damaged by low resistance testing devices, such as test lights and logic

probes (computer safe test lights). Test all circuits with a high quality digital multi-meter before making con-

nections.

■Do not disconnect the battery if the vehicle has an anti-theft-coded radio. If equipped with an air bag,

avoid disconnecting the battery if possible. Many airbag systems will display a diagnostic code through their

warning lights after they lose power. Disconnecting the battery requires this code to be erased, which can

require a trip to the dealer.

■Check with the customer on status LED location.

■Remove the domelight fuse. This prevents accidentally draining the battery.

■Roll down a window to avoid being locked out of the car.

after the installation

■Test all functions. The “Using Your System” section of the Owner's Guide is very helpful when testing.

■When testing, don’t forget that this system is equipped with Nuisance Prevention® Circuitry (NPC). NPC can

bypass trigger zones, making them appear to stop working. See the Nuisance Prevention® Circuitry section.

■Review and complete the Safety Check section of this guide prior to the vehicle reassembly.

DRAFT

deciding on component locations

locations for the siren

Some things to remember about mounting the siren:

■Keep it away from heat sources, such as radiators, exhaust manifolds, turbochargers, and heat shields.

■Mount it where a thief cannot easily disconnect it, whether the hood is open or shut. Both the siren and its

wires should be difficult to find. This usually involves disguising the wire to look like a factory harness.

■We recommend against grounding the siren to its mounting screws. Instead, we recommend running both

the red and black wires into the passenger compartment and grounding to one common point for all devices.

After all, both wires are the same length and come already bonded together. Whenever possible, conceal your

wires in the factory harnesses or in the same style loom as the factory.

■When possible, place the siren on the same side of the vehicle as the control module, where its wires will

reach the control module’s wires without extending them. Always run the wires through the center of a

grommet, never through bare metal!

■Point the siren down so water does not collect in it.

locations for the control module

Some things to remember about where to mount the control module:

■Never put the control module in the engine compartment!

■The first step in hot-wiring a vehicle is removing the driver's side under-dash panel to access the starter

and ignition wires. If the control module is placed just behind the driver's side dash it can easily be discon-

nected.

■When mounting the control module, try to find a secure location that will not require you to extend the har-

nesses’ wires (they are 1.5 meters long). Keep it away from the heater core (or any other heat sources) and

any obvious leaks.

■Some good control module locations are: Above the glove box, inside the center console, above the under-

DRAFT

dash fuse box, or above the radio.

mounting the antenna

The antenna position should be discussed with the vehicle’s owner prior to installation, since the antenna may

be visible to the vehicle’s operator. The best location for the antenna is centered high on either the front or

rear windshield. For optimal range, the antenna should be mounted horizontally. It can be mounted vertically

but range will be diminished. Metallic window tint can also affect range, so this should be a consideration when

determining the mounting location.

After determining the best mounting location, follow these steps:

1. Clean the mounting area with a quality glass cleaner or alcohol to remove any dirt or residue.

3. Mount the antenna using the supplied double-sided tape.

4. Route the antenna cable to the control module and plug it into the antenna connector.

IMPORTANT! To achieve the best possible range, DO NOT leave the antenna cable bundled under the

dash. Always extend the cable full length during installation, regardless of the antenna mounting

location.

locations for stinger doubleguard shock sensor

Some things to remember about where to mount the shock sensor:

■Never put the Stinger®in the engine compartment!

■Find a spot close to the control module so that the wires do not need to be extended. Keep it away from the

heater core (or any other heat sources) and any obvious leaks.

How the Stinger®is mounted is the most important factor in its performance. We recommend two meth-

ods:

■Using double-sided tape or hook-and-loop fastener to mount to a trim panel or an air duct,

■Wire-tying to a wire harness.

If mounting the sensor where it cannot be easily reached for adjustment, hook-and-loop fastening tape (such as

Velcro) is recommended for ease of removal for future adjustments.

NOTE: In many vehicles, tying the sensor to a steering column or screwing it to metal will result in

poor sensitivity, especially at the rear of the vehicle.

DRAFT

locations for valet/program switch

IMPORTANT! When the vehicle is delivered, please show the user where this switch is located and

how to disarm the system with it.

Ensure that the location you pick for the switch has sufficient clearance to the rear. The switch should be well

hidden. It should be placed so passengers or stored items (such as in a glove box or center console) cannot

accidentally hit it. The switch fits into a 9/32-inch hole.

This system has Remote Valet. The user can enter and exit Valet Mode without having to reach the Valet/Program

switch. This feature was introduced so that switch location was less critical in day-to-day use. As long as the

Valet/Program switch can be reached to disarm without a transmitter, easy access is not important.

locations for the status LED

Things to remember when positioning the Status LED:

■It should be visible from both sides and the rear of the vehicle, if possible.

■It needs at least 1/2-inch clearance to the rear.

■It is easiest to remove a small panel, such as a switch blank or a dash bezel, before drilling a 9/32-inch

hole.

■Use quick-disconnects near the LED wires if the panel is removable. This lets mechanics or other installers

remove the panel without cutting the wires.

DRAFT

locations for the optional starter kill relay

If optional starter kill relay or its connections are immediately visible upon removal of the under-dash panel, they

can easily be bypassed. Always make the relay and its connections difficult to discern from the factory wiring!

Exposed yellow butt connectors do not look like factory parts, and will not fool anyone! For this reason, routing

the optional starter kill wires away from the steering column is recommended.

locations for the relay satellite

The relay satellite wiring carries large amounts of current. The wires should not be extended and should be cut

to the minimum length necessary. Since the relay satellite is functioning as the ignition switch in the vehicle, it

is often convenient to mount the relay satellite close to the main ignition switch harness.

finding the wires you need

Now that you have decided where each component will be located, you’re going to find the wires in the car that

the security system will be connected to.

IMPORTANT! Do not use a 12V test light or logic probe (computer safe test light) to find these

wires! Use a digital multimeter for all testing.

obtaining constant 12V

We recommend two possible sources for 12V constant: the (+) terminal of the battery, or the constant supply to

the ignition switch. Always install a fuse within 12 inches of this connection. If the fuse also will be powering

other circuits such as door locks, fuse accordingly.

IMPORTANT! Do not remove the fuse holder on the red wire. It ensures that the control module

has its own fuse, of the proper value, regardless of how many accessories are added to the main power

feed.

DRAFT

Autres manuels pour 7900

Table des matières

Autres manuels Directed Electronics Alarme de voiture

Directed Electronics

Directed Electronics Clifford 12.2X Manuel utilisateur

Directed Electronics

Directed Electronics Automate 640M Manuel utilisateur

Directed Electronics

Directed Electronics 411R Series Manuel utilisateur

Directed Electronics

Directed Electronics Hurricane 3 Manuel utilisateur

Directed Electronics

Directed Electronics Concept 650 Manuel utilisateur

Directed Electronics

Directed Electronics Python 450 ESP Manuel utilisateur

Directed Electronics

Directed Electronics 100 ESP Manuel utilisateur

Directed Electronics

Directed Electronics 200 Manuel utilisateur

Directed Electronics

Directed Electronics 381 Series Manuel utilisateur

Directed Electronics

Directed Electronics Python 323 Manuel utilisateur

Directed Electronics

Directed Electronics 554R Manuel utilisateur

Directed Electronics

Directed Electronics Vehicle Security System 3901V Manuel utilisateur

Directed Electronics

Directed Electronics Python 990 Manuel utilisateur

Directed Electronics

Directed Electronics 1000 Manuel utilisateur

Directed Electronics

Directed Electronics AM1 Manuel utilisateur

Directed Electronics

Directed Electronics Python 500 Manuel utilisateur

Directed Electronics

Directed Electronics Concept 550 Manuel utilisateur

Directed Electronics

Directed Electronics 791XV Manuel utilisateur

Directed Electronics

Directed Electronics 436 Series Manuel utilisateur

Directed Electronics

Directed Electronics Clifford 2.2 Manuel utilisateur

Directed Electronics

Directed Electronics VIPER 1000 Manuel utilisateur

Directed Electronics

Directed Electronics Valet 561T Manuel utilisateur

Directed Electronics

Directed Electronics 417 Manuel utilisateur

Directed Electronics

Directed Electronics AutoCommand 20095 Manuel utilisateur

Manuels Alarme de voiture populaires d'autres marques

Clifford

Clifford 3606X Manuel utilisateur

Ultra Start

Ultra Start 2500M SERIES Manuel utilisateur

Ultra Start

Ultra Start 650 Series Manuel utilisateur

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuel utilisateur

Sparkrite

Sparkrite SRA8 Manuel utilisateur

Viper

Viper 4708V Manuel utilisateur

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuel

Falcon

Falcon Predator XL3 Guide de l'utilisateur

Audiovox

Audiovox Auto Security XR91 Mode d'emploi

Clifford

Clifford Sabre II Manuel utilisateur

CrimeStopper

CrimeStopper CS-8717 Guide de démarrage rapide

Ultra Start

Ultra Start 450 SERIES Manuel utilisateur

Scytek electronic

Scytek electronic Vectra X3 Manuel utilisateur

Excalibur

Excalibur AL-1860-EDPB Manuel utilisateur

Clifford

Clifford CYBER 2 Manuel utilisateur

Gemini

Gemini 7057 Manuel utilisateur

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuel utilisateur

Magicar

Magicar FAI-440 Manuel utilisateur
