Intelliguard 950

OOwwnneerr’’ssGGuuiiddee

limited lifetime consumer warranty

Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or replace

with a comparable reconditioned model any Directed unit (hereafter the "unit"), excluding

without limitation the siren, the remote transmitters, the associated sensors and accessories,

which proves to be defective in workmanship or material under reasonable use during the life-

time of the vehicle provided the following conditions are met: the unit was professionally

installed and serviced by an authorised Directed dealer; the unit will be professionally rein-

stalled in the vehicle in which it was originally installed by an authorised Directed dealer; and

the unit is returned to Directed, shipping prepaid with a legible copy of the bill of sale or other

dated proof of purchase bearing the following information: consumer's name, telephone num-

ber and address; the authorised dealers name, telephone number and address; complete prod-

uct description, including accessories; the year, make and model of the vehicle; vehicle regis-

tration number and vehicle identification number. All components other than the unit, includ-

ing without limitation the siren, the remote transmitters and the associated sensors and acces-

sories, carry a one-year warranty from the date of purchase of the same. This warranty is non-

transferable and is automatically void if: the unit's date code or serial number is defaced, miss-

ing or altered; the unit has been modified or used in a manner contrary to its intended pur-

pose; the unit has been damaged by accident, unreasonable use, neglect, improper service,

installation or other causes not arising out of defects in materials or construction. The warran-

ty does not cover damage to the unit caused by installation or removal of the unit. Directed, in

its sole discretion, will determine what constitutes excessive damage and may refuse the return

of any unit with excessive damage. TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WAR-

RANTIES, INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WAR-

RANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE AND WARRANTY OF NON-

INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED NEI-

THER ASSUMES NOR AUTHORISES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY,

OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS. DIRECTED DISCLAIMS AND

HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS

AUTHORISED DEALERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS UNIT,

ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT OFFERING A GUARANTEE OR

INSURANCE AGAINST VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR

CONTENTS; AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUDING

WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM. THIS WARRAN-

TY DOES NOT COVER LABOUR COSTS FOR MAINTENANCE, REMOVAL OR REINSTALLATION OF

THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR

A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER VENUE SHALL BE SAN

DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE

FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER

ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE AUTHORISED DIRECTED

DEALER'S PURCHASE PRICE OF THE UNIT. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY

DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAM-

AGES, INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS, COM-

MERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE

ABOVE, THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR

THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on how

long an implied warranty will last or the exclusion or limitation of incidental or consequential

damages. This warranty gives you specific legal rights and you may also have other rights that

vary from State to State or Country to Country.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt and installation certificate, showing the following:

zDate of purchase

zYour full name and address

zAuthorised dealer's company name and address

zType of alarm installed

zYear, make, model and colour of the vehicle

zVehicle registration number

zVehicle identification number

zAll security options installed on the vehicle

trademarks and copyrights

Bitwriter®, Clifford®, Code-Hopping™, Directed®, Doubleguard®, ESP®, FailSafe®, Ghost Switch®,

Learn Routine™, Nite-Lite®, Nuisance Prevention®, NPC®, Revenger®, Silent Mode™, Soft Chirp®,

Stealth Coding™, Stinger®, Valet®, Vehicle Recovery System™, VRS™, and Warn Away®are all

Trademarks or Registered Trademarks of Directed Electronics, Inc.

limited lifetime consumer . . . . . . .

warranty . . . . . . . . . . . . . . . . . . . . .i

what is included . . . . . . . . . . . . .3

important information . . . . . . . . .3

system maintenance . . . . . . . .4

your warranty . . . . . . . . . . . . .4

transmitter configurations . . . . . .5

transmitter functions . . . . . . . . . .6

standard configuration for 5-but-

ton Radar2 transmitter . . . . . . .6

standard configuration for 4-but-

ton OEM Transmitter . . . . . . . .7

using your system . . . . . . . . . . . . .9

arming . . . . . . . . . . . . . . . . . . .9

disarming . . . . . . . . . . . . . . . .10

disarming without a transmitter .

. . . . . . . . . . . . . . . . . . . . . . .11

remote siren silencing . . . . . .11

transmitter chirp muting . . . .11

transmitter sensor disable . . .12

intellistart and smartwindows

sensor bypass . . . . . . . . . . . . .12

auxiliary channel bypass . . . . .13

disarm/valet mode . . . . . . . . .13

transmitter valet mode . . . . . .14

one-time auto-arming bypass .15

low battery warning . . . . . . .15

automatic noise abatement . .15

multiple event total recall . . . .16

diagnostics . . . . . . . . . . . . . . . . . .16

arming diagnostics . . . . . . . . .16

disarming diagnostics . . . . . . .17

arm/disarm diagnostic chart . .17

table of zones . . . . . . . . . . . .18

high frequency . . . . . . . . . . . . . .19

smart power up II . . . . . . . . . . . .19

power saver mode . . . . . . . . . . .19

programming options . . . . . . . .20

cliffnet wizard installation soft-

ware programming . . . . . . . .21

manual programming instruc-

tions . . . . . . . . . . . . . . . . . . .22

user selectable features . . . . .23

user selectable features descrip-

tions - column one . . . . . . . . .24

user selectable features descrip-

tions - column two . . . . . . . .25

user selectable features descrip-

tions - column three . . . . . . .27

pin programming . . . . . . . . . . . .29

ultrasecure auto-immobiliser . . .30

auto-immobilisation sequence 31

one-time valet feature . . . . .31

blackjax* feature . . . . . . . . . . . .32

blackjax activation sequence .32

blackjax* deactivation sequence

. . . . . . . . . . . . . . . . . . . . . . .34

bypass blackjax temporarily . .34

contents

blackjax* off warning indicator .

. . . . . . . . . . . . . . . . . . . . . . .35

system sensors and adjustments

. . . . . . . . . . . . . . . . . . . . . . .35

glossary of terms . . . . . . . . . . . . .36

security & convenience expansions

. . . . . . . . . . . . . . . . . . . . . . . . . . .38

health check . . . . . . . . . . . . . . . .39

what is included

zIntelliguard 950 Security System

zOne 5-button transmitter and one 4-button transmitter

zPresentation envelope and quick reference card

zTwo window decals

zXHF antenna/receiver

zBlue status LED

zPlainView 2 Valet switch

z515C Smart Self-powered siren

zTilt/Motion sensor

zOne of the following sensor options

Digital Dual-Zone proximity sensor

Ultrasonic sensor

Glass Tamper sensor

important information

Congratulations on the purchase of your state-of-the-art Thatcham

evaluated vehicle security system. It has been designed to provide years

of trouble-free operation. In order to maximise the use of this system,

please review this owner's guide carefully prior to using your system.

You can print additional or replacement copies of this owner’s guide by

accessing the Clifford website at www.clifford.com.

system maintenance

The Intelliguard 950 requires no specific maintenance. Your transmitter

is powered by a miniature 3V lithium battery that will last approximate-

ly one year under normal use. When the battery weakens, operating

range will be reduced and the system will provide a low battery warn-

ing chirp indication when disarming.

your warranty

It is necessary to retain your sales receipt, which reflects that the prod-

uct was installed by an authorised dealer. For full details regarding your

warranty coverage, please refer to the consumer warranty section of

this guide.

nnoottee::Making changes to the existing system will invalidate the certifi-

cate of installation.

nnoottee::The Installation Certificate must be completed by your installer at

the authorised dealer. Other than the remote controls, this system has no

user-serviceable parts. Your authorised dealer can correct any system

wiring problems and, if needed, can return any malfunctioning compo-

nent to Directed Electronics for repair/replacement under the terms of

the Limited Lifetime Warranty printed at the beginning of this guide.

nnoottee::Your system MUST be installed by an Authorised dealer in accor-

dance with the instructions we supply them. The Clifford Intelliguard

950 system is designed to be installed in any petrol or common rail

diesel vehicle with a 12-volt battery.

transmitter configurations

Your Intelliguard 950 system has a 5-button and 4-button remote con-

trol. Your system can accept up to 2 additional remotes. Each remote

can be used to control the various standard features and options of

your system as shown in the following pages.

nnoottee::This manual describes the features and accessories that are

included with your system along with information about compatible

Clifford accessories that are not included. For a list of included acces-

sories, please refer to the

What Is Included

section of this manual.

Arm/Disarm

Button

Boot Release or

Optional Accessory

Output Button

Remote Start or

Accessory Output

Button

Accessory Output

Button

4-Button Transmitter

Arm/Disarm Button

Boot Release or

Optional Accessory

Output Button

Remote Start or

Accessory Output

Button

Silent Arm/Disarm or

Accessory Output

Button

Shift Button

5-Button Transmitter

transmitter functions

This system uses computer-based code learning to learn the transmitter

buttons. This makes it possible to assign any transmitter button to any

system function. The transmitter initially comes programmed with stan-

dard configuration, but may also be customised using the CliffNet

Wizard PC program. The buttons in all of the instructions in this manu-

al correspond to a standard configuration transmitter.

standard configuration for 5-button Radar2 transmitter

Button

The arming and disarming functions are controlled by this button.

Button

The boot release or accessory output A is controlled by this button.

Button

Silent arm and disarm is controlled by this button.

Button

Remote start is controlled by this button, if the Intellistart* accessory is

added.

Button, then Button

Accessory B output is controlled by these buttons.

* This feature/accessory is not evaluated by Thatcham.

Button, then Button

These buttons activate the optional SmartWindows.

Button, then Button

Accessory C output is controlled by these buttons.

Button twice, then Button

These buttons activate remote valet.

Button twice, then Button

These buttons disable the sensors.

Button twice, then Button

These buttons enter safe start mode for manual transmission vehicles

and activate Autostart mode. (Requires optional Intellistart* accessory.)

standard configuration for 4-button OEM Transmitter

Button

The arming and disarming functions are controlled by this button.

Button

The boot release or accessory output A is controlled by this button.

Button

Accessory output B is controlled by this button.

* This feature/accessory is not evaluated by Thatcham.

Table des matières

Autres manuels Directed Electronics Alarme de voiture

Directed Electronics

Directed Electronics Matrix 1 Manuel utilisateur

Directed Electronics

Directed Electronics Auto Mate AMX 8.5 Manuel utilisateur

Directed Electronics

Directed Electronics 417 Manuel utilisateur

Directed Electronics

Directed Electronics 6000 Manuel utilisateur

Directed Electronics

Directed Electronics Avital 2300 Manuel utilisateur

Directed Electronics

Directed Electronics 736T Manuel utilisateur

Directed Electronics

Directed Electronics MERLIN 2000 Manuel utilisateur

Directed Electronics

Directed Electronics SmartStart 5000-series Manuel utilisateur

Directed Electronics

Directed Electronics Intelliguard 750 Manuel utilisateur

Directed Electronics

Directed Electronics 592 Manuel utilisateur

Directed Electronics

Directed Electronics PS-7870TWE-FM Manuel utilisateur

Directed Electronics

Directed Electronics 791XV Manuel utilisateur

Directed Electronics

Directed Electronics ProSecurity SR6000 Manuel utilisateur

Directed Electronics

Directed Electronics 100 ESP Manuel utilisateur

Directed Electronics

Directed Electronics 381 Series Manuel utilisateur

Directed Electronics

Directed Electronics Viper 106V Manuel utilisateur

Directed Electronics

Directed Electronics Viper 140 HF Manuel utilisateur

Directed Electronics

Directed Electronics Concept 550 Manuel utilisateur

Directed Electronics

Directed Electronics 10 Manuel utilisateur

Directed Electronics

Directed Electronics CLIFFORD 320.3X Manuel utilisateur

Directed Electronics

Directed Electronics Intelliguard 850 Manuel utilisateur

Directed Electronics

Directed Electronics 650 ESP Manuel utilisateur

Directed Electronics

Directed Electronics Clifford 2.2 Manuel utilisateur

Directed Electronics

Directed Electronics AutoCommand 20095 Manuel utilisateur

Manuels Alarme de voiture populaires d'autres marques

Clifford

Clifford 3606X Manuel utilisateur

Ultra Start

Ultra Start 2500M SERIES Manuel utilisateur

Ultra Start

Ultra Start 650 Series Manuel utilisateur

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuel utilisateur

Sparkrite

Sparkrite SRA8 Manuel utilisateur

Viper

Viper 4708V Manuel utilisateur

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuel

Falcon

Falcon Predator XL3 Guide de l'utilisateur

Audiovox

Audiovox Auto Security XR91 Mode d'emploi

Clifford

Clifford Sabre II Manuel utilisateur

CrimeStopper

CrimeStopper CS-8717 Guide de démarrage rapide

Ultra Start

Ultra Start 450 SERIES Manuel utilisateur

Scytek electronic

Scytek electronic Vectra X3 Manuel utilisateur

Excalibur

Excalibur AL-1860-EDPB Manuel utilisateur

Clifford

Clifford CYBER 2 Manuel utilisateur

Gemini

Gemini 7057 Manuel utilisateur

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuel utilisateur

Magicar

Magicar FAI-440 Manuel utilisateur
