Digitus DN-80115 Manuel utilisateur
16-Port Gigabit Ethernet
Switch, 10", unmanaged
Manual
DN-80115
2
Introduction
The DN-80115 is a compact Ethernet desktop switch
that provides wire-speed, a Gigabit Ethernet switching
function which allows high-performance, low-cost
connections to 10M/ 100M /1000Mbps Ethernet
network. The Ethernet Switch delivers all the
advantages of a switching hub in a compact desktop
size and is ideal for small office or SOHO network users.
This switch provides 16 auto-sensing 10 / 100 /
1000 Mbps Ethernet RJ-45 ports, which automatically
detect the speed of the devices that you plug into them.
This switching function allows Full/Half-duplex devices
to communicate on the same network without having
to replace any infrastructure. This flexible feature
allows your network a timely, economical migration to
DIGITUS network switch.
Key Features
Conforms to IEEE802.3, 802.3u, 802.3x, 802.3ab
Automatic MDI/MDIX crossover for all ports
N-Way Auto-negotiation for 10/100/1000Mbps
transmissions
Space-saving compact size
Store-and-Forward switching architecture
Auto-detection of full/half-duplex mode in all ports
Plug-and-Play configuration auto address learning
LED indicators for Power, Link/activity
3
Package Contents
Ethernet Switch
User’s manual
AC power cord
IMPORTANT: If any piece is missing or damaged, please
contact your local dealer or reseller for service.
Product Specifications
DN-80115 (16-Port 10/100/1000 Base-TX Gigabit
Ethernet Switch)
Ports: 16-Port 10/100/1000Base-TX
MAC Address: 8K Mac address table
LED Indicator: Per port: Link/Activity
Per unit: Power
Dimension: 250mm x 150mm x 42mm
(W x D x H)
Operating Temp: 0°C to 45°C (32°F to 113°F)
Operating Humidity: 20% to 85% (Non-condensing)
Power Consumption: 15 Watt AC 100-240VAC
50/60Hz (Maximum)
EMI: CE Class A
4
Hardware Description
The Front Panel
The front panel consists of LED Indications.
LED Indicators
Per Device: Power
Per Port: LINK/ACT (Link/Activity)
Figure 1. Front panel view
LED
Status
Color
Description
Power
On
Green
The switch is supplied with
suitable power.
LINK/ACT
Off
-
The port is not linked
successfully with the device.
Figure 2. Back view
5
RJ-45 Ports (Auto MDI/MDIX)
16 auto-sensing ports of 10/100/1000Base-TX
connections. [In general, MDI means connecting to
another Hub or Switch while MDIX means connecting
to a workstation or PC. Therefore, Auto MDI/MDIX
means that you can connect to another Switch or
workstation without changing pin-to-pin or crossover
cabling.]
AC Power Connector
Plug the female connector into the switch and male
connector into a power outlet. Supports input voltages
100-240VAC, 50/60Hz.
6
Troubleshooting
The Switch can be easily monitored through panel
indicators to assist in identifying problems. This section
describes common problems you may encounter and
possible solutions.
Power
If the power indicator does not light when the power
cord is plugged in, you may have a problem with the
power outlet or cord. However, if the power LED goes
off after running for a while, check for loose power
connections, power losses or surges at the power
outlet. Turn off power, wait 30 seconds and turn power
on again. If problem is still not resolved call for dealer’s
assistance
Diagnosing LED Indicators
If link indicator does not light after making a
connection, check whether network interface (e.g., a
network adapter card on the attached device), network
cable, or switch port is defective. Be sure the cable is
plugged into both the switch and corresponding device.
Verify the proper cable type is used and its length does
not exceed specified limits.
7
Cabling
Verify that the cabling type is correct. Make sure all
cable connectors are securely seated in the required
ports. Use only standard Unshielded Twisted-Pair (UTP),
Category 3, 4, 5, or 5e cables. Use only Category 5 or 5e
when connecting with Fast Ethernet. Make certain the
maximum distance between the Switch and what it’s
connected to is 100 meters or less.
NOTE: Do not plug a standard telephone cord into
an RJ-45 port. This may damage the switch
This is a Class A product. In home environment, this product may
cause radio interference. In this case, the user may be required to
take appropriate measures.
Hereby Assmann Electronic GmbH, declares that the Declaration
of Conformity is part of the shipping content. If the Declaration of
Conformity is missing, you can request it by post under the below
mentioned manufacturer address.
www.assmann.com
Assmann Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
16-Port Gigabit Ethernet
Switch, 10", unmanaged
Benutzerhandbuch
DN-80115
2
Einführung
Der DN-80115 ist ein kompakter
Ethernet-Desktop-Switch mit Wire-Speed, einer
Gigabit-Ethernet-Switching-Funktion, die leistungsstarke
und kostengünstige Verbindungen zu 10M/100M/1000
Mbps-Ethernet-Netzwerken ermöglicht. Der
Ethernet-Switch bietet alle Vorteile eines Switch-Hubs in
kompakter Desktop-Größe und ist ideal für kleine Büro-
oder SOHO-Netzwerkanwender. Dieser Switch verfügt
über 16 automatisch abfragende 10/100/1000 Mbps
Ethernet RJ-45-Ports, die automatisch die
Geschwindigkeit der Geräte erkennen, an die Sie sie
anschließen. Diese Switching-Funktion ermöglicht es
Voll-/Halbduplex-Geräten, über das gleiche Netzwerk zu
kommunizieren, ohne die Infrastruktur ersetzen zu
müssen. Diese flexible Funktion ermöglicht Ihrem
Netzwerk eine zeitnahe und kosten-günstige Migration
auf den DIGITUS-Netzwerk-Switch.
Hauptmerkmale
Entspricht IEEE802.3, 802.3u, 802.3x, 802.3x, 802.3ab
Automatische MDI/MDIX-Weiche für alle Ports
N-Way Auto-Negotiation für 10/100/1000 Mbps
Übertragungen
Platzsparende, kompakte Größe
Store-and-Forward-Switching-Architektur
3
Automatische Erkennung des Voll-/
Halbduplex-Modus in allen Ports
Plug-and-Play-Konfiguration mit automatischem
Adresslernen
LED-Anzeigen für Power, Link/Aktivität
Lieferumfang
Ethernet-Switch
Benutzerhandbuch
AC-Netzkabel
WICHTIG: Wenn ein Teil fehlt oder beschädigt ist,
wenden Sie sich bitte an Ihren örtlichen Händler oder
Wiederverkäufer.
Produktspezifikationen
DN-80115 (16-Port 10/100/1000 Base-TX Gigabit
Ethernet Switch)
Ports: 16-fach 10/100/1000Base-TX
MAC-Adresse: 8K Mac-Adresstabelle
LED-Anzeige: Pro Port: Link/Aktivität
Pro Einheit: Leistung
Abmessungen: 250 mm x 150 mm x 42 mm (BxTxH)
