Digitus DS-55508 Manuel utilisateur

4K HDBaseT™ HDMI

Extender Set, 150 m

Manual

DS-55508

Table of Contents

1. Introduction ............................................................................2

2. Main Features .........................................................................3

3. Package Contents ....................................................................3

4. Specification............................................................................4

5. Operating Controls and Functions............................................6

5.1 Transmitter Panel...................................................................6

5.2 Receiver Panel........................................................................8

5.3 IR Pin Definition .....................................................................9

6. Application Example..............................................................11

1. Introduction

The HDBaseT™ HDMI Extender Set enables uncompressed, high-

resolution signal transmission over large distances using a simple

copper data cable. The maximum transmission distance is 150 m (Full

HD). 4K signals can be extended to up to 120 m. Thanks to PoC, only

one unit needs to be supplied with power by an external power

adapter. RS232 and bi-directional IR transmission are also included as

features. Thanks to an HDMI loop-out to the transmitter unit, a local

monitor can be connected in order to control the output to the

receiver.

2. Main Features

•Supports HDBaseT™ 1.0 via CAT5e/6/7/8 cable up to 150 m

•Supports 4K2K/60Hz (4:4:4)

•Maximum transmission distance (UHD 4K2K): 120 m

•Maximum transmission distance (Full HD 1080p): 150 m

•Video bandwidth: 18 Gbps

•HDMI loop-out to the transmitter unit

•PoC (Power over Cable) - Only the unit requires an

external power adapter

•HDCP 2.2 / 1.4

•HDR, HDR10+, Dolby Vision, HLG

•R232 signal transmission

3. Package Contents

•1x Transmitter unit

•1x Receiver unit

•1x IR transmission cable (1.5 m)

•1x IR receiver cable (1.5 m)

•1x Power adapter (DC 24V/1A, 1.45 m)

•2x 3-pin Phoenix connector

•4x Mounting plate

•1x User manual

4. Specification

Technical

HDCP Compliance

HDCP 2.2 / HDCP 1.4

Video Bandwidth

18Gbps

Video Resolution

4K2K 50/60Hz 4:4:4

4K2K 50/60Hz 4:2:2

4K2K 50/60Hz 4:2:0

4K2K 30Hz 4:4:4

1080p, 1080i, 720p, 720i, 480p, 480i

All HDMI 3D TV formats

All PC resolutions including 1920 x 1200

Color Space

RGB / YCbCr 4:4:4, YCbCr 4:2:2,

YCbCr 4:2:0

Color Depth

8/10/12-bit (1080P60Hz, 4K30Hz,

4K60Hz, YCbCr 4:2:2/4:2:0)

8-bit (4K60Hz 4:4:4)

HDMI Audio Formats

LPCM 2.0/2.1/5.1/6.1/7.1,

Dolby Digital, Dolby TrueHD,

Dolby Digital Plus (DD+), DTS-ES, DTS

HD Master, DTS HD-HRA, DTS-X

L/R Audio Formats

PCM 2.0

ESD Protection

Human body model

±8kV (Air-gap discharge)

±4kV (Contact discharge)

Connections

Transmitter

Inputs: 1x HDMI Type A [19-pin female]

Outputs: 1x HDMI Type A [19-pin female]

1x HDBT OUT [RJ45, 8-pin female]

Control: 1x IR IN [3.5mm Stereo Mini-jack]

1x IR OUT [3.5mm Stereo Mini-jack]

1x RS-232 [Phoenix jack]

1x SERVICE [Mini-USB, Update port]

Receiver

Inputs: 1x HDBT IN [RJ45, 8-pin female]

Outputs: 1x HDMI Type A [19-pin female]

1x AUDIO OUT

[3.5mm Stereo Mini-jack]

Control: 1x IR IN [3.5mm Stereo Mini-jack]

1x IR OUT [3.5mm Stereo Mini-jack]

1x RS-232 [Phoenix jack]

1x SERVICE [Mini-USB, Update port]

Mechanical

Housing

Metal Enclosure

Color

Black

Dimensions

67mm (W) × 91.5mm (D) × 17.5mm (H)

Weight

Transmitter: 160g, Receiver: 155g

Power Supply

Input: AC 100 - 240V 50/60Hz

Output: DC 24V/1A (Locking connector)

Power

Consumption

9.36 W

Operating

Temperature

32 - 104°F / 0 - 40°C

Storage

Temperature

-4 - 140°F / -20 - 60°C

Relative Humidity

20~90% RH (non-condensing)

Resolution / Distance

4K2K

394ft / 120M

1080P

492ft / 150M

Resolution /

Cable Length

4K60 -

Feet / Meters

4K30 -

Feet / Meters

1080P60 -

Feet / Meters

HDMI IN / OUT

16ft / 5M

32ft / 10M

50ft / 15M

The use of “Premium High Speed HDMI” cable is highly

recommended.

5. Operating Controls and Functions

5.1 Transmitter Panel

No.

Name

Function description

Power LED

Red LED indicates that the transmitter

is powered on

SERVICE port

Firmware update port

DC 24V

DC 24V/1A power supply input port.

Note that the extender supports PoC

function, it means that either

transmitter or receiver is powered on

by 24V/1A power adapter, the

other one doesn’t need power supply

HDBT OUT

RJ45 connector for connecting the

HDBT IN port of receiver

with a CAT 5e/6 cable

Connection

Signal Indicator

lamp

•Illuminating: Transmitter and

Receiver are in good connection

status

•Flashing: Transmitter and Receiver

are in poor connection status

•Dark: Transmitter and Receiver are

not connected

Data Signal

Indicator lamp

•Illuminating: HDMI signal with HDCP

•Flashing: HDMI signal without HDCP

•

Dark: No HDMI signal

HDMI OUT

HDMI loop output for display

HDMI IN

HDMI source input

IR IN

IR input port for receiving the signal of

IR remote

IR OUT

IR output port for control of source

device. This IR output signal is from the

IR IN port of receiver

RS-232

3-pin Phoenix connector for RS-232

command transmission.

The RS-232 command will pass-through

from transmitter to receiver or from

receiver to transmitter

5.2 Receiver Panel

No.

Name

Function description

Power LED

Red LED indicates that the receiver is

powered on

SERVICE port

Firmware update port

DC 24V

DC 24V/1A power supply input port.

Note that the extender supports PoC function, it

means that either transmitter or receiver is powered

on by 24V/1A power adapter, the other one doesn’t

need power supply

HDBT IN

RJ45 connector for connecting the

HDBT OUT port of transmitter with a

CAT 5e/6 cable

Connection

Signal Indicator

lamp

•Illuminating: Transmitter and

Receiver are in good connection

status

•Flashing: Transmitter and Receiver

are in poor connection status

•Dark: Transmitter and Receiver are

not connected

Data Signal

Indicator

•Illuminating: HDMI signal with HDCP

•Flashing: HDMI signal without HDCP

•

Dark: No HDMI signal

HDMI OUT

HDMI output for display

AUDIO OUT

3.5mm stereo connector for analog

audio output

5.3 IR Pin Definition

IR Receiver and Blaster pin’s definition is as below:

IR RECEIVER

IR BLASTER

IR Blaster

Signal

Power

IR Receiver

IR Signal

Power

Grounding

The following is IR system diagram about IR cable use method.

Transmitter

TV remote

IR Blaster cable

DVD

IR Receiver cable

CAT 5e/6 cable

DVD remote

Receiver

Note: When the angle between the IR receiver and the remote

control is ± 45°, the transmission distance is 0-5 meters; when the

angle between the IR receiver and the remote control is ± 90°, the

transmission distance is 0-8 meters.
