Digitus DN-7056 Manuel utilisateur
Package Contents ........................................................................ Page 1
Network Card Installation ........................................................... Page 2
Connect to Wireless Access Point.............................................. Page 4
Package Contents
Before you starting to use this wireless network card, please check if there’s anything
missing in the package, and contact your dealer of purchase to claim for missing items:
PCI Wireless Network Card .… … … … … … … … … … … … … … … … .… … … … ..… . 1
Quick installation guide (1 pcs) … … … … … … … … … … … … … … … … … … … ..… . 2
User manual / device driver CDROM (1 pcs) … … … … … .… … … … … … … … ..… . 3
Antenna (3 pcs) … … … … … … … … … … … ..… … … … … .… … … … … … … … … ..… . 4
Quick Installation Guide
DN-7056 –WIRELESS LAN PCI ADAPTER
Network Card Installation
Please follow the following instructions to install your new PCI wireless network card:
1. Turn off your computer, and
remove the case as required so you
can see PCI expansion slots (PCI
slots are usually colored as white),
and then insert the PCI wireless
network card into any available the
PCI slot.
Please make sure the network card is
firmly inserted.
2. Install all three antennas on the
wireless network card, and make
sure the antennas are securely
installed. To improve radio reception,
please adjust antennas to the
position shown in the left picture.
It’s recommended to use the antenna
included in the package. If you’re
going to use antenna of your own,
please make sure those antennas
are designed for 2.4GHz wireless
devices.
3. Switch the computer on now, and
log in the Windows system. The
following message will appear on
your computer, click ‘Don’t show
this message again for this
device’.
4. Insert device driver CDOM into the
CD/DVD ROM drive of your
computer, and execute ‘Setup.exe’
program in ‘Driver’folder.
Please select ‘Allow’if Windows
indicates that ‘an unidentified
program wants access to your
computer’.
6. Please read the end user license
agreement and click ‘Yes’to accept
license agreement.
6. Please select ‘Optimize for WiFi
mode’for wireless compatibility, then
click ‘Next>’.
If you want to enhance wireless
performance, please select ‘Optimize
for performance mode’. However,
wireless compatibility is not
guaranteed in this mode. Please refer
to user manual for details of
performance mode.
If you see ‘Found New Hardware’
message again, please ignore it
and wait.
7. When you see this message,
please click ‘Finish’to complete the
driver installation process.
Connect to Wireless Access Point
Using Configuration Utility to Connect to Wireless Access Point
1. After installation is complete,
wireless configuration utility will be
shown as an icon at the lower-right
corner of your windows desktop.
Please click the icon by right mouse
key, and select ‘Launch Config
Utilities’.
2. Configuration utility will scan for
wireless access points automatically,
and all found access points will be
displayed. Please select an access
point you wish to connect, and click
‘Connect’.
If the wireless access point you want to
connect does not show here, please
click ‘Rescan’
3. You’ll be prompted to input the SSID
(the name of wireless access point) if
the SSID of the access point you want
to connect is hidden, then click ‘OK’.
The SSID you input here must be
identical to the SSID setting of the
wireless access point you want to
connect.
4. If the wireless access point uses
encryption, you have to input WEP
passphrase or WPA preshared key.
Please ask the owner of the wireless
access point you want to connect, and
input the correct passphrase /
preshared key here, then click ‘OK’. If
the value you inputted here is wrong,
you will not be able to connect to
wireless access point.
Authentication type is selected
automatically, please don’t change
it.
5. If the wireless access point is
successfully connected, you’ll see a
‘Connected’message displayed at the
lower-left corner of wireless
configuration utility window. Click ‘OK’
to exit.
For advanced settings and other features of this PCI wireless network card, please refer to
user manual enclosed in supplied CD-ROM.
