Digitus DA-70840 Manuel utilisateur

USB 3.0 to VGA adapter

Manual

DA-70840

Description

DIGITUS USB 3.0 to VGA Adapter, resolution up to 1920x1080 @60Hz, extend and

mirror mode support

The DIGITUS USB 3.0 to VGA Adapter extends your workspace with an additional

monitor, TV or projector via the USB interface. You can use two graphic adapters

simultaneously on the PC and add or remove a monitor without rebooting the

system. This adapter supports resolutions up to 1920x1080, video streaming up to

1080p. The USB 3.0 to VGA adapter impresses with its elegant black housing and

without additional installation of graphics cards. The power supply runs through an

USB port, so there’s no additional external power supply needed.

Feature

Compliant with USB3.0 Specification Revision 1.0

Compliant with Universal Serial Bus Device Class Definition for Audio/Video

Devices (USB A/V)

USB upstream port supporting SS/HS data rate (5Gbps/480Mbps)

Video output up to 1920x1080@60Hz in USB 3.0 application (Video output

800x600 in USB 2.0 application)

Supports USB Plug and Play (PNP)

WHCK/WHQL certified driver support for Windows 7, 8 and 10

Support Windows Aero Effects

Package content

1. USB3.0 Graphic adapter

2. Quick Installation Guide

System Requirement:

Intel i3 2.5GHz or Higher

4GB DDR3 SDRAM

Operating System: Windows 7 and above

Installation

1. Connect DA-70840 USB port to computer

2. New USB flash driver will be found

3. Install the driver (.exe file) and reboot the computer.

4. Connect HDMI connector to monitor

PS: If there is new OS version released, please go to website

http://www.business.assmann.com/and download new driver.

Connection Diagram

OUT

IN

LED Monitor 1080P TV NB PC

VGA Cable

Hereby ASSMANN Electronic GmbH, declares that this device is in compliance with the

requirements of Directive 2014/30/EU and the Directive 2011/65/EU for RoHS compliance.

The complete declaration of conformity can be requested by post under the below mentioned

manufacturer address.

Warning:

This device is a class B product. This equipment may cause some radio interference in living

environment. In this case, the user can be requested to undertake appropriate measures to

prevent interference.

www.assmann.com

Assmann Electronic GmbH

Auf dem Schüffel 3

58513 Lüdenscheid

Germany
