Digital Equipment PrintServer 17/300 Manuel utilisateur

PrintServer17/300Printer

ControllerFirmware

Version2.1Upgrade

Order Number: EK–LPS1X–IN. A01

Digital Equipment Corporation

Maynard, Massachusetts

First Printing, June 1994

Digital Equipment Corporation makes no representations that the use of its products

in the manner described in this publication will not infringe on existing or future

patent rights, nor do the descriptions contained in this publication imply the granting

of licenses to make, use, or sell equipment or software in accordance with the

description.

Printed in U.S.A.

PrintServer and the DIGITAL logo are trademarks of Digital Equipment Corporation.

NetWare is a registered trademark of Novell, Inc.

All other trademarks and registered trademarks are the property of their respective

holders.

S2644

This document was prepared using VAX DOCUMENT Version 2.1.

Installing the Firmware

Software

Requirements Version 2.1 of the controller ﬁrmware ROM chips must be

installed in a PrintServer 17/300 printer if you are booting from

NetWare. The minimum version of PrintServer software required

to boot from NetWare is Version 5.0.

The ﬁrmware upgrade is not required for PrintServer 17/600

printers.

Kit Contents The upgrade kit (order number 4A–LPS1X–FW) contains:

• ROM chips (2)

• Antistatic wrist strap

• This document

Tool

Requirements The procedure for installing the Version 2.1 controller ﬁrmware

requires the following tools:

• Flat work surface — for working on the controller board

• Flat blade screwdriver — for loosening and tightening captive

screws and for extracting ROM chips

• Antistatic wrist strap — for preventing damage to electronic

components

Your upgrade kit includes an antistatic wrist strap.

Caution Take these precautions while performing the installation

procedure:

•Static electricity can damage electronic components on

the controller board. Use the antistatic wrist strap to

ground yourself to a metal object.

•Work on a ﬂat surface to keep from bending the

controller board.

•Be careful not to gouge any components on the

controller board with the screwdriver.

•Be careful when handling the ROM chips. The pins

bend easily and damage is not covered by warranty.

Installing the Firmware

Installation

Procedure To install the ROM chips:

1. Disconnect the power cord from the wall outlet and then from

the rear panel.

2. Disconnect the Ethernet cable from the rear panel.

3. Loosen the two captive screws by the Ethernet connection on

the rear panel.

4. Grasp each side of the lower plastic cover at the front of the

printer, and slide out the controller board.

DSG-000307

Installing the Firmware

5. Extract the existing ROM chips (



) by sliding the screwdriver

underneath each chip and gently loosening the pins from their

sockets.

6. Carefully align the pins on each new chip with the sockets on

the board, noting the orientation of the notch (



Note: You may ﬁnd it easier to align the pins with the sockets

if you bend in the pins slightly. The pins bend easily, so gently

rock each chip on each side, on your ﬂat work surface, to

adjust the pins for alignment.

Press the chips ﬁrmly and evenly to seat them in their sockets.

273E8

272E8

7. Slide the controller board back into the unit until it is securely

seated, then tighten the two captive screws by the Ethernet

connection on the rear panel.

8. Reconnect the power cord and the Ethernet cable.

Installing the Firmware

Veriﬁcation

Procedure To verify correct installation of the chips, power on the printer.

The power-up diagnostics run and the following display appears

on the operator panel:

XX-XX-XX-XX-XX-XX

2.1 XX XX

If the operator panel is blank, either the controller board is not

fully seated or the chips are not installed correctly.
