Digi XPressWireless Manuel utilisateur

User Guide

XPress™Wireless

Ethernet Bridge

XPress Wireless Ethernet Bridge User Guide 2

Revision history—90001305

Trademarks and copyright

Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United States and other

countries worldwide. All other trademarks mentioned in this document are the property of their respective

owners.

Disclaimers

Information in this document is subject to change without notice and does not represent a commitment on the

part of Digi International. Digi provides this document “as is,” without warranty of any kind, expressed or implied,

including, but not limited to, the implied warranties of fitness or merchantability for a particular purpose. Digi

may make improvements and/or changes in this manual or in the product(s) and/or the program(s) described in

this manual at any time.

Warranty

To view product warranties online, visit www.digi.com/howtobuy/terms.

Send comments

To provide feedback on this document, send your comments to techc[email protected].

Customer support

Digi offers multiple technical support plans and service packages to help our customers get the most out of their

Digi product. For information on Technical Support plans and pricing, please contact us at 952.912.3456 or visit

www.digi.com/support.

If you have a customer account, sign in to the Customer Support Web Portal at www.digi.com/support/eservice.

Revision Date Description

A June 2012 Baseline release.

B February 2013 Added the following steps to page 15:

5 Reconnect power.

6 Press and hold the white reset button for 10 seconds. This will cause the

LEDs to flash off then back on. The radio is now set to factory defaults.

C August 2016 Updated links and the template. Added missing antennas.

XPress Wireless Ethernet Bridge User Guide 3

Contents

Hardware

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Setup the Product Name

Identify the kit components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Specifications

Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Physical dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

900 MHz channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Setup and initialization

Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Digital setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

The POE injector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Issue a factory reset

Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Perform a reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Update the firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

FCC certification

FCC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

XPress Wireless Ethernet Bridge User Guide 4

Hardware

Overview

Thank you for your purchase of the Product Name.

The Product Name replaces costly wiring with a solution that can wirelessly connect industrial PLCs,

digital signs, security cameras, access controllers and more. With a range of up to 15 miles, the

ability to transmit through as many as 10 standard walls, a 1.5 Mb/s data rate, and the added range

and capabilities of the 900 MHz band, the easy-to-use, long-range XPress Wireless Ethernet Bridge

communicates where Wi-Fi and other wireless data products fall short.

If you have purchased a single Product Name, you will receive the following:

One XPress Ethernet Bridge RF Modem (-W = international variant)

One 2.1 dBi weatherproof dipole antenna

One 12 VDC power supply

One Power over Ethernet (POE) injector

If you have purchased a pair of Product Names, you will receive two of each item. Additional

configuration is typically not required when XEBs are operated as a pair.

This document contains information on the Product Name functionality only. If you have purchased

an Product Name with XPress Crypto Module, refer to the User Manual Supplement for XPress

Crypto Module with FIPS 140-2 Security for more information.

Setup the Product Name Identify the kit components

XPress Wireless Ethernet Bridge User Guide 5

Setup the Product Name

Identify the kit components

Carefully unpack and verify the contents of your kit. Your kit should include the following:

Product Name: pair

Product Name: single

Specifications Summary

XPress Wireless Ethernet Bridge User Guide 6

Specifications

Summary

The Product Nameallows the user to create a long-range, wireless Ethernet network with up to 16

active (63 total) subscriber units per access point.

Configuring a wireless link with the XEB requires the establishment of six elements:

Each radio must know whether it is to be an access point (AP) or subscriber unit (SU)

Each radio must have an IP address that is unique among all others on the same network

The AP must know how many SUs are expecting communication with it

The AP and any given SU must agree on which radio frequency channel they are using. This can

be set manually or allowed to change automatically.

The SU must be assigned a unique subscriber ID to specify which time division slot it will use

when communication with the AP

The AP and any given SU must share a common 128-bit encryption key

The access point (AP) automatically scans for the best of the 12 available radio frequency channels,

encrypts Ethernet data received from the network, and transmits it wirelessly to the correct

subscriber unit (SU). The AP is constantly monitoring the radio link and can automatically change the

channel if performance is degraded due to interference. If two AP units are very close to one another,

they may interfere if operating on adjacent frequency channels. Place them at least 10 feet apart or

manually select non-adjacent channels for their operation. Also, the SU should be placed at least 10

feet from the AP to avoid overloading the radio’s receiver.

Any 10/100 BaseT Ethernet client device (ECD) can be connected to an XPress subscriber unit. Each

SU encrypts Ethernet traffic received from the attached ECD and transmits the data wirelessly to its

AP.Each SU can be plugged directly into an ECD without adding drivers or loading software.

Essentially, once the AP/SU pair is configured and running, it behaves like a continuous Ethernet

cable.

Specifications Specifications

XPress Wireless Ethernet Bridge User Guide 7

Specifications

Characteristic Specification/Description

RF Transmission Rate 1.536 Mb/s

EthernetThroughput 935 kb/s

Output Power +21 dBm (125 mW), (4 W EIRP with 15 dBi antenna)

Receiver Sensitivity -97 dBm at 10-4 bit error rate

Range Up to 1000 ft (300 m) indoor with 2.1 dBi dipole antennas

Up to 2 miles (3.2 km) outdoor line of sight with 2.1 dBi dipole antennas

Up to 15 miles (24 km) outdoor line of sight with high- gain antennas

Radio Channels /

Bandwidth 12 channels (6 in international version) with 2.0833 MHz

spacing and 1.75 MHz

occupied bandwidth

Manual Frequency Select Channel selected with dip switch or via web browser

interface

Connector Types RF RPTNC female / Ethernet RJ-45 / Power Jack P5-2.1

mm center positive

Status LEDs Power, Ethernet Link, RF RX, RF TX, 4/Channel and

6/Link Quality

Error Correction Technique Sub-block error detection and retransmission

Adjacent Band Rejection SAW receiver filter attenuates cellular interference

Regulator Type Switching regulator

BrowserManagement

Tools QoS Statistics, Network Settings, Spectrum Analyzer

and Firmware Upgrading

PowerConsumption Transmit: 1.7 W Receive: 0.8 W

Voltage Power over Ethernet 9-48 VDC pins 4/5 positive and 7/8

ground

TemperatureRange Radio/Enclosure: -40 C to 70 C; PoE Injector: -40 C to 85 C; Power Supply: 0 C to

40 C

Transmit Current Draw 175 mA @ 9 VDC; 140 mA @ 12 VDC; 35 mA @ 48

VDC

Size 9.22” L x 3.60” W x 2.19” H; 320 grams

Weatherproofing The XPress enclosure is IP65 rated and tested for

weatherproof installation. The

PoE injector and power

supply are not weatherproof and should be installed

indoors.

Certificationsand

Compliance

FCC Part 15; Industry Canada (IC); contains FCC ID:

R4N-AW900MRandIC:5305A-

AW900MR;UL60950-1;

CSA C22.2, No. 60950-1, E112790; RoHS

Specifications Physical dimensions

XPress Wireless Ethernet Bridge User Guide 8

Physical dimensions

900 MHz channels

Channel US/Canada International Center Frequency

0xx AutoMode

1 x 903.12500 MHz

2 x 905.20833 MHz

3 x 907.29167 MHz

4 x 909.37500 MHz

5 x 911.45833 MHz

6 x 913.54167 MHz

7 x x 915.62500 MHz

8 x x 917.70833 MHz

9 x x 919.79167 MHz

10 x x 921.87500 MHz

11 x x 923.95833 MHz

12 x x 926.04167 MHz

Setup and initialization Setup

XPress Wireless Ethernet Bridge User Guide 9

Setup and initialization

Setup

1Consult IT - Each XPress radio comes default with a static IP address of 192.168.17.17. We

recommend connecting each radio to a standalone computer disconnected from any shared

network, and consulting with your IT department before connecting them to any shared

network.

2Install hardware - If the device is to be used outdoors, mount it vertically with the antenna facing

up. This orientation will mitigate any environmental effects and allow drainage. Attach the

antenna to the XPress radio. Antenna installation is required to maintain device sealing. Attach

the Ethernet cable (straight or cross-over) between the XPress radio and the “DATA + PWR” jack

on the PoE injector. In order to maintain the seal around the Ethernet cable, the Ethernet gland

cap should be firmly tightened.

3Configure the radios - Use either the Digital Setup method as shown below, or use the DIP switch

method; see page 3 of the XPress Ethernet Bridge Multipoint: User Guide (part number 90000888)

manual at www.digi.com:

ftp://ftp1.digi.com/support/documentation/90000888_B.pdf

Note XEB09-CIPA(-W) radios come pre-configured as a paired set. No configuration is required.

Digital setup

1Perform the digital configuration using the XPress built-in browser interface. It should be

powered on and connected at least temporarily to a network containing a computer that can run

a conventional web browser.

2Download the Digi IP Discovery Utility from our website at:

http://ftp1.digi.com/support/utilities/changer_digi.zip

Note This utility only runs on Windows, not Linux or Mac. If you must use a non-Windows

computer for configuration, make sure your subnet mask allows your computer to see

192.168.17.17. Connect to that default IP address with your web browser, continuing the

setup procedure with step 6.

3Unzip and run the IP Discovery Utility (changer_DIGI.exe) and a window appears that is similar to

this:

Setup and initialization Digital setup

XPress Wireless Ethernet Bridge User Guide 10

4The XPress should appear in the list at the default IP address of 192.168.17.17. If it does not, click

Search to regenerate the list. If it still does not appear, you have a connection issue and need to

re-examine the cabling or you may have a firewall issue on your computer.

5Double-click the list item that refers to the XPress being configured. A window appears that is

similar to the following picture:

6This information is the current status of the radio, while the boxes on the right allow you to

change it. It is important that the IP address of the XPress is in the same subnet as your

computer. For example, if the subnet mask is 255.255.255.0 (a class C network), the first three

number groups of the IP address must match. Choose your desired parameters and click Apply.

Table des matières

Autres manuels Digi Routeur réseau

Digi

Digi TransPort WR21 Instructions d'installation et d'utilisation

Digi

Digi Connect Series Guide de l'utilisateur

Digi

Digi TransPort LR54 Manuel utilisateur

Digi

Digi TransPort WR44 Manuel utilisateur

Digi

Digi IX10 Manuel utilisateur

Digi

Digi TransPort WR31 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Digi

Digi 6330-MX Manuel utilisateur

Digi

Digi TransPort WR64 Manuel utilisateur

Digi

Digi TransPort WR54 Guide d'application

Digi

Digi TransPort WR11 Manuel de l'opérateur

Digi

Digi ConnectPort X4 H Manuel utilisateur

Digi

Digi WR41-G Manuel utilisateur

Digi

Digi Connect EZ 4 Manuel utilisateur

Digi

Digi TX40 Manuel utilisateur

Digi

Digi TX54 Manuel utilisateur

Digi

Digi TransPort WR31 Instructions d'installation

Digi

Digi 6310-DX Manuel utilisateur

Digi

Digi XPress Manuel utilisateur

Digi

Digi TransPort WR11 XT Manuel utilisateur

Digi

Digi TransPort WR44 R Manuel utilisateur

Digi

Digi TransPort WR41 Manuel utilisateur

Digi

Digi Digi Connect WAN Guide de l'utilisateur

Digi

Digi TransPort WR11 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité

LevelOne

LevelOne FBR-1416 Manuel utilisateur
