Digi SR44-E Manuel utilisateur

Cellular Routers

Wireless WAN

router / switch

Installation Guide

Disclaimer

Digi International makes no representations or warranties with respect to the contents or

use of this manual, any software drivers or associated application software provided with

this product and specifically disclaims any expressed or implied warranties of

merchantability or fitness for any particular purpose.

Digi International reserves the right to modify or revise all or part of this document, its

contents, and any products described herein at any time without prior notification and

shall not be responsible for any loss, cost, or damage, including consequential damage,

caused by reliance on these materials.

Product disposal instructions

The WEEE (Waste Electrical and Electronic Equipment: 2002/96/EC) directive has been

introduced to ensure that electrical/electronic products are recycled using the best

available recovery techniques to minimize the impact on the environment.

This product contains high quality materials and components which can be recycled. At

the end of its life this product MUST NOT be mixed with other commercial waste for

disposal. Check with the terms and conditions of your supplier for disposal information.

or mechanical, including photocopying, recording, taping, or information and retrieval

systems without written permission of Digi International.

Transport SR Series Installation Guide

Safety Notices

1) Please read all instructions before installing and powering the unit. You should keep

these instructions in a safe place for future reference.

2) The Transport SR family uses a 12V DC/1.5A power supply. If the power supply

shows signs of damage or malfunction, you should stop using it immediately - turn off

the power at the mains and disconnect it from the power supply before contacting

your supplier for a repair or replacement.

3) Changes or modifications not expressly approved by the party responsible for

compliance could void the user‟s authority to operate the equipment. Use only the

accessories, attachments, and power supplies provided by the manufacturer –

connecting non-approved antennas or power supplies may damage the unit, cause

interference or create an electric shock hazard, and will void your warranty.

4) Do not attempt to repair the products; they contain no electronic components that can

be serviced or replaced by the user. Any attempt to service or repair the unit by the

user will void the product warranty.

5) The Transport SR is designed for indoor use only and should be used in an

environment that is suitable for computers and other electronic equipment.

6) Ports that are capable of connecting to other apparatus are defined as SELV ports.

To ensure conformity with IEC60950 ensure that these ports are only connected to

ports of the same type on other apparatus.

Wireless Networks

The Transport SR series routers support both GSM and CDMA networks. GSM networks

support the GPRS, EDGE, UMTS, HSDPA and HSUPA data transmission standards.

CDMA networks support the IXRTT and EVDO data transmission standards. Throughout

this manual these networks will be referred to as either GSM, CDMA, or simply „wireless‟

networks.

The type of network supported by each model is summarized in the table below:

Network

Model

GSM

GPRS

GSM

EDGE

WCDMA

UMTS

WCDMA

HSDPA

WCDMA

HSUPA

CDMA

EVDO1xRTT

SR44-E

SR44-H

SR44-U

SR44-C

Transport SR Series Installation Guide

Special Notes on Wireless Safety

Digi International products are designed to the highest standards of safety and

international standards compliance for the markets in which they are sold. However,

wireless based products contain radio devices which require specific consideration.

Please take the time to read and understand the following guidance. Digi International

assumes no liability for an end user‟s failure to comply with these precautions.

Wireless routers incorporate a wireless radio module. Users should

ensure that the antenna is positioned at least 1 metre away from

themselves and other persons in normal operation.

When in a hospital or other health care facility, observe the restrictions on

the use of mobile phones. Do not use the router in areas where

guidelines posted in sensitive areas instruct users to switch off mobile

phones. Medical equipment may be sensitive to RF energy.

The operation of cardiac pacemakers, other implanted medical

equipment and hearing aids can be affected by interference from cellular

terminals such as the wireless routers when placed close to the device. If

in doubt about potential danger, contact the physician or the

manufacturer of the device to verify that the equipment is properly

shielded. Pacemaker patients are advised to keep the wireless router

away from the pacemaker while it is on.

Wireless routers must NOT be operated on aircraft. The operation of

wireless appliances in an aircraft is forbidden to prevent interference with

communications systems. Failure to observe these instructions may lead

to the suspension or denial of cellular services to the offender, legal

action, or both.

As with any electrical equipment, you should not operate your wireless

router in the presence of flammable gases, fumes or potentially explosive

atmospheres. Radio devices should not be used anywhere that blasting

operations are taking place.

Wireless routers receive and transmit radio frequency energy while

switched on. Remember that interference can occur if it is used close to

TV sets, radios, computers or inadequately shielded equipment. Follow

any special regulations and always switch off your wireless router

wherever forbidden or when you suspect that it may cause interference

or danger.

SOS IMPORTANT! –Wireless routers operate using radio signals and

cellular networks cannot be guaranteed to connect in all possible

conditions. Therefore, you should never rely solely upon any wireless

device for life critical communications.

Transport SR Series Installation Guide

Preface

This guide describes the installation procedure for the Digi Transport SR family. It is

intended to provide sufficient information for you to be able to connect the unit to your

terminal equipment and power supply. A complete reference guide to the software

features that are available on the product is available separately in PDF format, and can

be downloaded from the Digi International website (www.digi.com).

All models feature:

4 x 10/100Base-T Ethernet ports

2 x RS232 sync/async serial ports (25-way D)

2 x USB 2.0 host ports

Several combinations of wireless and PSTN connectivity are available depending on the

model.

Note: You will not be able to use the router for remote communication until you have

subscribed to a suitable wireless network service.

Package Contents

When you receive the router carefully unpack it and check the contents. These should

include:

Item

System unit

12V power supply

Installation guide

2m CAT5 STP LAN cable (blue)

2m PSTN cable (Models with PSTN only)

Cellular antenna (may be sold separately)

If any item is missing or damaged, please contact your supplier. You should also make a

record of any damage that may have occurred during shipping and report it to the carrier.

Transport SR Series Installation Guide

1 Introduction

The Transport SR and other models described in this guide are compact IP routers that

facilitate the transmission of data over UMTS, HSDPA, EVDO, GPRS, EDGE and/or

PSTN networks. All models incorporate a 4-port 10/100 Ethernet switch. Depending on

the model, each unit also incorporates one or more WAN interfaces as follows:

SR44-E, H, U –wireless GPRS/EDGE/UMTS/HSDPA/HSUPA only

SR44-C –wireless CDMA/IXRTT/EVDO only

The routers can be configured either by using commands entered at the serial port (much

like a modem), or via the built-in Web interface. We recommend that you use the Web

interface whenever possible.

In addition to many standard LAN and Internet protocols such as PPP, Transport SR

series products provide a combination of powerful but easy to use configuration,

management and diagnostic tools. This makes them simple and cost-effective solutions

for migrating existing terminal or telemetry equipment, which use wired networks (PSTN,

ISDN, etc.), to wireless operation.

1.1 Front Panel Features

The front panel of the unit incorporates the USB host connectors, a number of LED

indicators depending on the model and the two SIM card-holders as shown in the

following illustration (GSM models):

USB Host Connectors

The USB host connectors may be used to connect compatible USB client devices such as

memory sticks, serial adapters, etc.

Transport SR Series Installation Guide

Status Indicators

The status indicators operate as follows:

Illuminates steady red when power is applied.

LAN 0, 1, 2, 3

Illuminate steady when there is a network connection to the

associated LAN port and flash when data is transmitted or

received.

W-WAN:

NET, SIM,

DAT

These indicators display the wireless WAN status as follows:

NET –Illuminates green when a wireless network has been

detected.

SIM –Illuminates green when a valid SIM card is installed in the

unit.

DAT –Flashes green when data is being transmitted or received.

SIGNAL

The three indicators labelled SIGNAL illuminate to indicate the

wireless signal strength as follows:

None illuminated < -113 dBm (effectively no signal)

1 LED illuminated >= -112 dBm and <= -87dBm (weak)

2 LED‟s illuminated >= -86dBm and <= -71dBm (medium)

3 LED‟s illuminated >= -70dBm and <= -51dBm (strong)

PSTN:

OH, CD, DAT

On the Transport SR models with a PSTN interface, these

indicators operate as follows:

OH –Illuminates green when the modem has gone off-hook.

CD –Illuminates green when the unit has connected to a remote

modem and asserted the Carrier Detect signal at the serial port.

DAT –flashes green when the unit has connected to a remote

modem and data is being transferred.

SERIAL:

0, 1

These indicators operate in one of two software configurable

modes:

Connection Mode: Illuminate steady if a terminal is connected to

the serial port and the DTR signal is on. Flash when data is

transmitted or received.

DTR Mode: Flash when data is transmitted or received only.

Transport SR Series Installation Guide

SIM Card Sockets

The two sockets at the right side of the front panel are for the GSM SIM card(s) that you

will receive from your service providers. Details of how to insert these correctly are given

in section 2 below.

CDMA models do not require SIM cards and therefore do not have SIM card sockets.

Rear Panel Features

(SR44 shown with PSTN option)

The functions of these connectors are described in the following table:

12V DC

This socket is used to connect the unit to the power supply using

the 12V DC power supply provided .

LAN 0, 1, 2, 3

The LAN sockets are used to connect the unit to 10/100-BaseT

LANs using the 2-meter STP (Shielded Twisted Pair) cable

supplied or a suitable alternative. These ports are auto-sensing

for speed and wiring (straight-through or cross-over). To comply

with EMC requirements they should not be used with non-STP

cable.

W-WAN ANT.

(main)

This SMA connector is used to fit the wireless antenna. The

Transport SR-, E and H models are supplied with a single stub

antenna which should be fitted to this connector.

Note: Stub antennas are provided as standard but a range of

suitable alternative for use in different applications may be

purchased separately.

W-WAN ANT.

(aux)

This SMA connector is used on the Transport SR44-U and C

models to fit the second antenna supplied with the unit. The

receiver supports “diversity” antenna capability to improve

performance and are there supplied with two stub antennas. On

models that do not support diversity antennas this connector will

not be present.

Transport SR Series Installation Guide

SERIAL 0, 1

These DB 25 sockets provide synchronous/asynchronous RS232

serial ports which may be used to connect the router to

compatible serial devices. To comply with EMC requirements it

should not be used with a cable longer than 2 meters.

PSTN

This socket is used to connect the router to a PSTN line.

Reset Switch

This is located on the underside of the unit near the front. Pressing the switch gently with

the tip of a pen or other suitable implement while the unit is powered will generate a

hardware reset.

Transport SR Series Installation Guide

2 Installation

All of the products described in this guide are designed for indoor use (office or home).

The system unit should be positioned on a smooth, level surface making sure that there is

adequate ventilation. Do not expose it to extremes of heat or cold, strong magnetic fields

or liquids.

It is important to remember that these products are wireless devices just like a mobile

phone, so they will only operate reliably over the wireless network if there is a good signal.

For many applications the stub antenna provided will be suitable but in some

circumstances it may be necessary to use a window-mounted or magnetically mounted

antenna with an extended cable to allow the antenna itself to be positioned to provide the

best possible signal reception. Digi International can supply a range of suitable antennas.

Step 1 - Installing the SIM card (GSM models only)

The router incorporates two separate SIM card holders so that if your application

demands it, you may install SIM cards for two different networks. This means that one

wireless service may be used as a back-up service in the event that the primary service

fails in some way. By default, SIM 1 is the default SIM used for access to the primary

network and SIM 2 is used for the back-up network.

Note: SIM 1 and SIM 2 cannot be used to access two networks simultaneously.

The SIM card(s) should be inserted into SIM cardholders at the right side of the front

panel as illustrated below.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Digi Routeur réseau

Digi

Digi Transport DR64-H Manuel utilisateur

Digi

Digi XPress Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Digi

Digi TransPort WR31 Instructions d'installation

Digi

Digi TransPort LR54 Manuel utilisateur

Digi

Digi ConnectPort X2e ZB Manuel utilisateur

Digi

Digi Digi TransPort WR Manuel utilisateur

Digi

Digi IX10 Manuel utilisateur

Digi

Digi TX54 Manuel utilisateur

Digi

Digi TransPort WR64 Manuel utilisateur

Digi

Digi DR6410 Manuel utilisateur

Digi

Digi TX64 Manuel utilisateur

Digi

Digi IX30 Manuel utilisateur

Digi

Digi TransPort WR31 Manuel utilisateur

Digi

Digi TransPort WR41 Manuel utilisateur

Digi

Digi WR44v1 Manuel utilisateur

Digi

Digi WR41-G Manuel utilisateur

Digi

Digi IR4420 Manuel utilisateur

Digi

Digi XPressWireless Manuel utilisateur

Digi

Digi WR41v1 Manuel utilisateur

Digi

Digi TransPort Manuel utilisateur

Digi

Digi EX40 Manuel utilisateur

Digi

Digi ConnectPort X2e ZB Manuel utilisateur

Digi

Digi IX20-WAG4 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité

LevelOne

LevelOne FBR-1416 Manuel utilisateur
