IX10

User Guide

Firmware version 23.3

Revision history—90002399

Revision Date Description

G March 2022 Release of Digi IX10 firmware version 22.2:

nVPNenhancements:

lRenamed VPN >IPsec >Tunnels >Policies >Local

network setting to Local traffic selector and

added Remote traffic selector.

lAdded a Dynamic option to the Local traffic

selector to configuration of a local network by

protocol and/or port instead of a network address

range.

lAdded Protocol and Port match criteria for Local

traffic selector and Remote traffic selector.

lAdded VPN >IPsec >Advanced >Debug level to

specify the logging verbosity of IPsec messages in

the device system logs.

nAdded Realport support.

nEnhancements to communications with Digi Remote

Manager:

lEnhanced security for communications with Digi

Remote Manager by using client-side certificates.

lThe default URL for the device's Remote Manager

connection is now edp12.devicecloud.com. This

URL is required to utilize the client-side certificate

support.

nNew Switch SIM SureLink action for WWAN interfaces,

which allows SureLink to be configured to switch to the

alternate SIM if the modem is connected but SureLink

test are failing.

lNew Switch SIM fail count option to determine

how many SureLink failures are required prior to

switching to the alternate SIM.

nNew Socket ID string option to send the configured

text to the remote server(s) when a TCP socket

connection is opened to the serial port.

nNew cat Admin CLI command for displaying file

contents.

H June 2022 Release of Digi IX10 firmware version 22.5:

n5G enhancements:

lAdded 5G slice support for configuring the slice

IX10 User Guide 2

Revision Date Description

type for the 5G modems.

nSurelink enhancements:

lEnabled Surelink reset_modem action by default on

cellular interfaces and set fail count to three.

lUpdated Surelink reset_modem action to

automatically power cycle the modem in the event

that the modem fails to reset.

nSerial port support enhancements:

lAdded serial PPP dial-in mode to handle AT-based

connection requests from a device connected to a

serial port and provide IPv4 networking to the

device.

lAdded suppport for Realport serial mode.

nAdded the ability to configure CPU performance and

power consumption.

nAdded cellular APN and cellular connection duration as

datapoints sent to Digi Remote Manager.

nWi-Fi scanner enhancements:

lAdded support for sending an HTTP or TCP stream

of results from the Wi-Fi scanner to one or more

remote servers.

nSCEP enhancements:

lNew SCEP client settings and underlying

functionality to support connecting to additional

SCEP servers.

lAdded show scep Admin CLI command to show

the sync status, expiration dates, and additional

details of any configured SCEP clients.

nVPN enhancements:

lInclude the hostname of the device in the client

.ovpn file listed on the Status → OpenVPN → Servers

page in the web UI.

nLocation services enhancements:

lNew settings to control the NMEA message content

that the devices sends when there is no valid fix

from any of the configured location sources.

I Not used.

J September 2022 Release of Digi IX10 firmware version 22.8:

nCellular modem enhancements:

lAdded modem ota download and system

firmware ota download commands for

IX10 User Guide 3

Revision Date Description

downloading cellular modem and device firmware.

lAdded cellular carrier name and PLMN ID to the

Modems Status page in the Web UI.

lEnhanced access technology options to set the

modem to 5G-only, including setting to 5G SA-only,

NSA-only, or both NSA/SA-modes.

nVPN enhancements:

lAdded Dynamic Multipoint VPN (DMVPN) support.

lAdded a Strict routing setting to IPsec tunnels that

routes packets through the tunnel if both the

source IP and destination IP match the IPsec

tunnel’s policies. This makes IPsec behave like a

policy-based VPN, rather than a route-based VPN.

lAdded the Microsoft version of the Challenge-

Handshake Authentication Protocol (MS-CHAPv2) as

an option for L2TP network servers authentication

methods.

nContainer support:

lContainer support now a premium feature, enabled

through Digi Remote Manager.

lAdded new metrics for sending container status,

name, CPU load, and disk usage as datapoints to

DigiRM.

nAdded support for running a PPPoE server when an

interface is in IP passthrough mode.

nAdded ability to specify DFS channels for Wi-Fi client

background scanning when DFS client support is

enabled.

nAdded a show eth Admin CLI command to show the

link status of each Ethernet port.

nAdded a poweroff CLI command to perform a graceful

shutdown of the device without automatically

rebooting.

nAdded the ability to turn off all LEDs on the device to

reduce power consumption.

K December 2022 Release of Digi IX10 firmware version 22.11:

nUpdated the Linux kernel to version 5.19.

nThe intelliFlow feature now integrates with Digi Remote

Manager to provide aggregated insights and analytics

for all Digi devices in your environment.

nAdded an MQTTbroker service, including support for:

IX10 User Guide 4

Revision Date Description

lMultiple MQTT clients with unique topics and

authentication credentials.

lPre-shared key encryption with multiple

configurable keys.

lPattern filtering for topic access control.

nAdded support for Next-hop routing protocol (NHRP).

nAdded support for mGREtunnels.

nAdded support for ICMP redirect messages.

nAdded a polling interval to control how often the

cellular modem is polled for signal strength and other

status.

nNew commands: tail and grep.

nAdd Timeout option to modem Carrier Scan window in

the Web UI.

nAdded advanced watchdog to:

lMonitor critical services and reboot the device if

those services fail.

lMonitor memory usage and log errors or reboot the

device based on current memory usage.

nAdded the ability to have serial port data written to the

system log.

lRemoved options in the local web UI and Admin CLI

for manually starting, stopping, and clearing serial

logs. These actions are now controlled under the

data logging configuration settings.

L May 2023 Release of Digi IX10 firmware version 23.3:

nSurelink:

lRedesigned Surelink configuration settings.

lAdded show surelink state Admin CLI command to

display the overall pass/fail status of enabled

Surelink tests.

nNew configuration settings for LXC containers:

lStart on boot to configure the container to start

when the system boots.

lRestart timeout to configure the container to

restart if it stops.

lOptional parameters to include optional

parameters for the container.

lMounted directories to setup shared directories

between the host filesystem and the container.

IX10 User Guide 5

Revision Date Description

nAdded a AT&T LWM2M support setting to enable or

disable AT&T lightweight M2M on cellular modems.

nVPN:

lDMVPN phase 1 spoke support with NHRP or mGRE,

including compatibility with Cisco DMVPN hubs.

lAdded support for SHA2 ciphers for IKEv2 IPsec

tunnels.

nDisabled mDNS by default for improved cellular

performance.

nIf the device has a configured System >Name, it is now

displayed on the Dashboard.

Trademarks and copyright

Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United States

and other countries worldwide. All other trademarks mentioned in this document are the property of

their respective owners.

Disclaimers

Information in this document is subject to change without notice and does not represent a

commitment on the part of Digi International. Digi provides this document “as is,” without warranty of

any kind, expressed or implied, including, but not limited to, the implied warranties of fitness or

merchantability for a particular purpose. Digi may make improvements and/or changes in this manual

or in the product(s) and/or the program(s) described in this manual at any time.

Warranty

To view product warranty information, go to the following website:

www.digi.com/howtobuy/terms

Customer support

Gather support information: Before contacting Digi technical support for help, gather the following

information:

Product name and model

Product serial number (s)

Firmware version

Operating system/browser (if applicable)

Logs (from time of reported issue)

Trace (if possible)

Description of issue

Steps to reproduce

IX10 User Guide 6

Contact Digi technical support: Digi offers multiple technical support plans and service packages.

Feedback

To provide feedback on this document, email your comments to

[email protected]

Include the document title and part number (IX10 User Guide, 90002399 L) in the subject line of your

email.

IX10 User Guide 7

Contents

Revision history—90002399 2

What's new in Digi IX10 version 23.3

Digi IX10 Quick start

Step 1: What's in the box 21

Step 2: Gather accessories 21

Step 3: Connect 22

Apply Dielectric Grease over SIMContacts 23

Step 4: Configure 24

Digi IX10 hardware reference

Digi IX10 features and specifications 26

IX10 accessories 26

IX10 front and side views 26

IX10 LEDs 27

Power (PWR) 28

SIM 28

LTE 28

Signal quality indicators 29

Ethernet Link and Activity 30

Signal quality bars explained 30

IX10 power supply requirements 31

Digi IX10 serial connector pinout 31

10-pin serial cabling options 32

QR code definition 32

Hardware setup

Install SIM cards 35

Apply Dielectric Grease over SIMContacts 35

SIM removal 36

Tips for improving cellular signal strength 36

Connect data cables 36

Mount the IX10 device 36

Attach to a mounting surface by using the mounting tabs 37

Attach to DIN rail with clip 37

IX10 User Guide 8

IX10 User Guide 9

Firmware configuration

Review IX10 default settings 41

Local WebUI 41

Digi Remote Manager 41

Default interface configuration 41

Other default configuration settings 42

Change the default password for the admin user 42

Configuration methods 44

Using Digi Remote Manager 45

Using the local web interface 45

Log out of the web interface 46

Use the local RESTAPI to configure the IX10 device 46

Use the GETmethod to return device configuration information 46

Use the POST method to modify device configuration parameters and list arrays 48

Use the DELETE method to remove items from a list array 49

Using the command line 51

Access the command line interface 51

Exit the command line interface 52

Central management

Digi Remote Manager support 54

Certificate-based enhanced security 54

Configure your device for Digi Remote Manager support 54

Collect device health data and set the sample interval 61

Enable event log upload to Digi Remote Manager 64

Log into Digi Remote Manager 66

Use Digi Remote Manager to view and manage your device 67

Add a device to Digi Remote Manager 67

Configure multiple IX10 devices by using Digi Remote Manager configurations 68

View Digi Remote Manager connection status 69

Learn more 69

Interfaces

Wireless Wide Area Networks (WWANs) 71

Configure SureLink active recovery to detect modem failures 71

Configure the device to reboot when a failure is detected 88

Disable SureLink 101

Using cellular modems in a Wireless WAN (WWAN) 110

Configure a Wireless Wide Area Network (WWAN) 129

Show WWAN status and statistics 139

Delete a WWAN. 140

Local Area Networks (LANs) 143

About Local Area Networks (LANs) 144

Configure a LAN 144

Change the default LAN subnet 151

Change the LAN address type 152

Show LAN status and statistics 154

Delete a LAN 155

DHCP servers 157

Virtual LANs (VLANs) 175

IX10 User Guide 10

Create a trunked VLAN route 176

Create a VLAN using switchport mode 178

Show SureLink status and statistics 180

Show SureLink State 180

Show SureLink status for all interfaces 181

Show SureLink status for a specific interface 181

Show SureLink status for all IPsec tunnels 182

Show SureLink status for a specific IPsec tunnel 182

Show SureLink status for all OpenVPN clients 183

Show SureLink status for a specific OpenVPN client 183

Serial port

Default serial port configuration 185

Serial mode options 185

View serial port information 185

Default serial port configuration 185

Configure Login mode 186

Configure Remote Access mode 190

Configure Application mode 206

Configure PPP dial-in mode 208

Configure UDP serial mode 215

Configure Modbus mode 226

Configure RealPort mode using the Digi Navigator 229

Installation and configuration process 230

Digi Navigator features 230

Install the Digi Navigator 230

Configure RealPort on a Digi device from the Digi Navigator 231

Digi Navigator application features 233

Advanced RealPort configuration without using the Digi Navigator 236

Windows Operating System 237

Linux Operating System 237

Download the RealPort driver 237

Configure RealPort on your laptop 237

Configure the serial port for RealPort mode 239

Configure the RealPort service 243

Show serial status and statistics 243

Review the serial port message log 244

Routing

IP routing 247

Configure a static route 248

Delete a static route 251

Policy-based routing 253

Configure a routing policy 253

Example: Dual WAN policy-based routing 261

Example: Domain-based routing with dual WAN 264

Example: Route traffic to a specific WAN interface based on the client MACaddress 267

Routing services 273

Configure routing services 273

Show the routing table 276

Dynamic DNS 277

Configure dynamic DNS 278

Autres manuels pour IX10

Table des matières

Autres manuels Digi Routeur réseau

Digi

Digi WR41v1 Manuel utilisateur

Digi

Digi IX10 Manuel utilisateur

Digi

Digi 6350-SR Manuel utilisateur

Digi

Digi TransPort WR11 XT Manuel utilisateur

Digi

Digi IX10-00G4 Manuel utilisateur

Digi

Digi TransPort WR11 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Digi

Digi DR6410 Manuel utilisateur

Digi

Digi TransPort WR41 Manuel utilisateur

Digi

Digi TransPort WR21 Manuel utilisateur

Digi

Digi TransPort WR64 Manuel utilisateur

Digi

Digi WR41-G Manuel utilisateur

Digi

Digi Connect EZ 4 Manuel utilisateur

Digi

Digi TransPort WR31 Instructions d'installation

Digi

Digi WR44v1 Manuel utilisateur

Digi

Digi One TS W Manuel utilisateur

Digi

Digi HR4420i Manuel utilisateur

Digi

Digi TransPort LR54 Manuel utilisateur

Digi

Digi TX40 Manuel utilisateur

Digi

Digi IX20-WAG4 Manuel utilisateur

Digi

Digi TransPort LR54-AA401 Manuel utilisateur

Digi

Digi 34 Instructions d'installation et d'utilisation

Digi

Digi TX54 Manuel utilisateur

Digi

Digi TransPort WR21 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité

LevelOne

LevelOne FBR-1416 Manuel utilisateur
