DeWalt D55154 Manuel utilisateur

D55154

Electric Wheeled Dolly-Style 4 Gallon Air Compressor

Compresseur d'air de 17,6 litres (4 gallons) de style diabolo, à roues électriques

Compresor de aire eléctrico sobre ruedas, tipo remolque de 17,6 litros (4 galones)

INSTRUCTION MANUAL

GUIDE D'UTILISATION

MANUAL DE INSTRUCCIONES

INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA

DE GARANTÍA. ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES

DE USAR EL PRODUCTO.

If you have questions or comments, contact us.

Pour toute question ou tout commentaire, nous contacter.

Si tiene dudas o comentarios, contáctenos.

1-800-4-DeWALT • www.dewalt.com

English

A. On/Off Switch

B. Air Tank Pressure Gauge

C. Regulated Pressure Gauge

D. Pressure Regulator

E. Quick Connects

F. Check Valve

G. Safety Valve

H. Air Tank Drain Valve

I. Power Cord Wrap

J. Pressure Switch

K. Pump Oil Dipstick

L. Pump Oil Drain Plug

M. Motor Reset

N. Air Intake Filter

O. Handle

P. Handle Locking Knobs

Q. Top Panel for Cargo

IMPORTANT: Always pull handle

up and lock in place before using

as a dolly.

Air Compressor

NOT A

STEP

FIG. 1

English

Specications

MODEL D55154

WEIGHT 80 lbs. (36.3 kg)

HEIGHT 20.0" (508.0 mm)

WIDTH 18.5" (469.9 mm)

LENGTH 23.0" (584.2 mm)

AIR TANK CAPACITY (GALLONS) 4.0 (15.1 liters)

APPROX CUT-IN PRESSURE

95 PSI (655 kPa)

APPROX. CUT-OUT PRESSURE

125 PSI (861.8 kPa)

SCFM @ 100 PSI (689.5 kPa) 3.8

MOTOR 1.1 HP (continuous)

Volts/Amps/Hertz 120V/14 A/60 Hz.

RPM 3450

Minumum Branch Circuit

Requirement 15 Amp

PUMP OIL CAPACITY 12 oz. (354.9 ml)

DUTY CYCLE 5 MINUTES ON /

5 MINUTES OFF

PUMP

CYLNDER

AND HEAD

Hot Surfaces

FIG. 2

OUTLET TUBE

CHECK

VALVE

English

Denitions: Safety Guidelines

The definitions below describe the level of severity

for each signal word. Please read the manual and

pay attention to these symbols.

DANGER: Indicates an imminently hazardous

situation which, if not avoided, will result in death

or serious injury.

WARNING: Indicates a potentially hazardous

situation which, if not avoided, could result in death

or serious injury.

CAUTION: Indicates a potentially hazardous

situation which,if not avoided,may result in minor or

moderate injury.

CAUTION: Used without the safety alert symbol

indicates a potentially hazardous situation which, if

not avoided, may result in property damage.

IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT

THIS OR ANY D

WALT TOOL, CALL US TOLL FREE AT:

1-800-4-D

WALT (1-800-433-9258)

Important Safety Instructions

WARNING: Do not operate this unit until you read and understand

this instruction manual for safety, operation and maintenance

instructions.

WARNING: Some dust created by power sanding, sawing, grind-

ing, drilling, and other construction activities contains chemicals

known to the State of California to cause cancer,birth defects or other

reproductive harm. Some example of these chemicals are:

 • leadfromlead-basedpaints

 • crystalline silica from bricks and cement and other masonry

products

 • arsenicandchromiumfromchemically-treatedlumber

Your risk from these exposures varies,depending on how often you

do this type of work.To reduce your exposure to these chemicals:

work in a well ventilated area, and work with approved safety

equipment, always wear OSHA/MSHA/NIOSH approved, properly

tting face mask or respirator when using such tools.

When using air tools, basic safety precautions should always be fol-

lowed to reduce the risk of of personal injury.

WARNING: This product contains chemicals, including lead,

known to the State of California to cause cancer, and birth defects

or other reproductive harm. Wash hands after handling.

SAVE THESE INSTRUCTION

DANGER: RISK OF EXPLOSION OR FIRE

WHAT CAN HAPPEN HOW TO PREVENT IT

 • Itisnormalforelectrical

contacts within the motor

and pressure switch to

spark.

 • Alwaysoperatethecom-

pressor in a well ventilated

area free of combustible

materials, gasoline, or sol-

vent vapors.

 • Ifelectricalsparksfrom

compressor come into

contact with flammable

vapors, they may ignite,

causing fire or explosion.

 • Ifsprayingflammablemate-

rials, locate compressor at

least 20 feet (6.1 m) away

from spray area. An addi-

tional length of hose may be

required.

 • Storeflammablematerialsin

a secure location away from

compressor.

English

 • Restrictinganyofthe

compressor ventilation

openings will cause

serious overheating

and could cause fire.

 • Neverplaceobjectsagainst

or on top of compressor

pump.

• Operatecompressorin

an open area at least 12"

(30.5 cm) away from any

wall or obstruction that

would restrict the flow of

fresh air to the ventilation

openings.

 • Operatecompressorina

clean, dry well ventilated

area. Do not operate unit

indoors or in any confined

area.

 • Unattendedoperationof

this product could result in

personalinjuryorproperty

damage. To reduce the

risk of fire, do not allow

the compressor to operate

unattended.

 • Always remain in atten-

dance with the product

when it is operating.

 • Always turn off and unplug

unit when not in use.

DANGER: RISK TO BREATHING (ASPHYXIATION)

WHAT CAN HAPPEN HOW TO PREVENT IT

• Thecompressedairdirectly

from your compressor is not

safe for breathing. The air

stream may contain carbon

monoxide, toxic vapors,

or solid particles from the

air tank. Breathing these

contaminant's can cause

seriousinjuryordeath.

• Airobtaineddirectlyfromthe

compressor should never

be used to supply air for

human consumption. In order

to use air produced by this

compressor for breathing,

suitable filters and in-line

safety equipment must be

properly installed. In-line

filters and safety equipment

usedinconjunctionwiththe

compressor must be capable

of treating air to all applicable

local and federal codes prior

to human consumption.

• Sprayedmaterialssuchas

paint, paint solvents, paint

remover, insecticides, weed

killers, may contain harmful

vapors and poisons.

• Workinanareawithgood

cross ventilation. Read and

follow the safety instructions

provided on the label or

safety data sheets for the

materials you are spraying.

Always use certified safety

equipment: OSHA/MSHA/

NIOSH respiratory protection

designed for use with your

specific application.

English

DANGER: RISK OF INJURY OR PROPERTY DAMAGE WHEN

TRANSPORTING OR STORING

WHAT CAN HAPPEN HOW TO PREVENT IT

• Oilcanleakorspilland

could result in fire or

breathing hazard; serious

injuryordeathcanresult.Oil

leaks will damage carpet,

paint or other surfaces in

vehicles or trailers.

• Alwaysplacecompressor

on a protective mat when

transporting to protect against

damage to vehicle from leaks.

Remove compressor from

vehicle immediately upon

arrival at your destination.

Always keep compressor level

and never lie on its side.

WARNING: RISK OF BURSTING

Air Tank: The air tank on your Air Compressor is designed and

may be UM coded (for units with air tanks greater than 6 inch

diameter) according to ASME Section VIII, Div. 1 rules. All pressure

vessels should be inspected once every two years. To find your

state pressure vessels inspector, look under the Division of Labor

and Industries in the government section of a phone book or call

1-800-4-DeWALT for assistance.

The following conditions could lead to a weakening of the air tank,

and result in a violent air tank explosion:

WHAT CAN HAPPEN HOW TO PREVENT IT

• Failuretoproperlydrain

condensed water from

air tank, causing rust and

thinning of the steel air tank.

• Drainairtankdailyorafter

each use. If air tank develops

a leak, replace it immediately

with a new air tank or replace

the entire compressor.

• Modificationsorattempted

repairs to the air tank. • Neverdrillinto,weld,ormake

any modifications to the

air tank or its attachments.

Never attempt to repair a

damaged or leaking air tank.

Replace with a new air tank.

• Unauthorizedmodifications

to the safety valve or any

other components which

control air tank pressure.

• Theairtankisdesigned

to withstand specific

operating pressures. Never

makeadjustmentsor

parts substitutions to alter

the factory set operating

pressures.

Attachments & accessories:

• Exceedingthepressure

rating of air tools, spray

guns, air operated

accessories, tires, and other

inflatables can cause them

to explode or fly apart, and

couldresultinseriousinjury.

• Followtheequipment

manufacturers

recommendation and never

exceed the maximum

allowable pressure rating

of attachments. Never use

compressor to inflate small

lowpressureobjectssuch

as children’s toys, footballs,

basketballs, etc.

English

Tires:

• Over inflation of tires could

resultinseriousinjuryand

property damage.

 • Useatirepressuregauge

to check the tires pressure

before each use and while

inflating tires; see the tire

sidewall for the correct tire

pressure.

NOTE: Air tanks, compressors

and similar equipment used to

inflate tires can fill small tires sim-

ilartotheseveryrapidly.Adjust

pressure regulator on air supply

to no more than the rating of the

tire pressure. Add air in small

increments and frequently use

the tire gauge to prevent over

inflation.

WARNING: RISK OF ELECTRICAL SHOCK

WHAT CAN HAPPEN HOW TO PREVENT IT

• Your air compressor is

Like any other electrically

powered device, If it is not

used properly it may cause

electric shock.

 • Never operate the

compressor outdoors

when it is raining or in wet

conditions.

 • Never operate compressor

with protective covers

removed or damaged.

 • Repairs attempted by

unqualified personnel can

resultinseriousinjuryor

death by electrocution.

 • Any electrical wiring

or repairs required on

this product should be

performed by a DeWALT

factory service center or a

DeWALT authorized service

center in accordance with

national and local electrical

codes.

 • Electrical Grounding:

Failure to provide

adequate grounding to

this product could result

inseriousinjuryordeath

from electrocution. See

Grounding Instructions

under Installation.

 • Make certain that the

electrical circuit to which the

compressor is connected

provides proper electrical

grounding, correct voltage

and adequate fuse

protection.

English

WARNING: RISK FROM FLYING OBJECTS

WHAT CAN HAPPEN HOW TO PREVENT IT

• Thecompressedair

stream can cause soft

tissue damage to exposed

skin and can propel dirt,

chips, loose particles,

andsmallobjectsathigh

speed, resulting in property

damageorpersonalinjury.

• Always wear certified safety

equipment: ANSI Z87.1 eye

protection (CAN/CSA Z94.3)

with side shields when using

the compressor.

• Neverpointanynozzleor

sprayer toward any part of

the body or at other people

or animals.

• Alwaysturnthecompressor

off and bleed pressure

from the air hose and air

tank before attempting

maintenance, attaching tools

or accessories.

WARNING: RISK OF HOT SURFACES

WHAT CAN HAPPEN HOW TO PREVENT IT

• Touchingexposedmetal

such as the compressor

head, engine head, engine

exhaust or outlet tubes, can

result in serious burns.

 • Nevertouchanyexposed

metal parts on compressor

during or immediately after

operation. Compressor

will remain hot for several

minutes after operation.

 • Donotreacharound

protective shrouds or

attempt maintenance until

unit has been allowed to

cool.

English

WARNING: RISK FROM MOVING PARTS

WHAT CAN HAPPEN HOW TO PREVENT IT

• Movingpartssuchasthe

pulley, flywheel, and belt

cancauseseriousinjuryif

they come into contact with

you or your clothing.

• Neveroperatethe

compressor with guards or

covers which are damaged or

removed.

• Keepyourhair,clothing,and

gloves away from moving

parts.Looseclothes,jewelry,

or long hair can be caught in

moving parts.

• Airventsmaycovermoving

parts and should be avoided

as well.

• Attemptingtooperate

compressor with damaged

or missing parts or

attempting to repair

compressor with protective

shrouds removed can

expose you to moving parts

and can result in serious

injury.

• Anyrepairsrequiredonthis

product should be performed

by a DeWALT factory

service center or a DeWALT

authorized service center.

WARNING: RISK OF UNSAFE OPERATION

WHAT CAN HAPPEN HOW TO PREVENT IT

• Unsafeoperationofyour

air compressor could lead

toseriousinjuryordeathto

you or others.

• Reviewandunderstandall

instructions and warnings in

this manual.

• Becomefamiliarwiththe

operation and controls of the

air compressor.

• Keepoperatingareaclear

of all persons, pets, and

obstacles.

• Keepchildrenawayfromthe

air compressor at all times.

• Donotoperatetheproduct

when fatigued or under the

influence of alcohol or drugs.

Stay alert at all times.

• Neverdefeatthesafetyfea

tures of this product.

• Equipareaofoperationwith

a fire extinguisher.

• Donotoperatemachinewith

missing, broken, or unautho-

rized parts.

• Neverstandonthe

compressor.

English

WARNING: RISK OF FALLING

WHAT CAN HAPPEN HOW TO PREVENT IT

• Aportablecompressor

can fall from a table,

workbench, or roof

causing damage to the

compressor and could

resultinseriousinjuryor

death to the operator.

• Alwaysoperatecompressor

in a stable secure position

to prevent accidental

movement of the unit.

Never operate compressor

on a roof or other elevated

position. Use additional

air hose to reach high

locations.

WARNING: RISK OF

INJURY FROM LIFTING

WHAT CAN HAPPEN HOW TO PREVENT IT

 • Seriousinjurycanresult

from attempting to lift too

heavyanobject.

 • Thecompressoristooheavy

to be lifted by one person.

Obtain assistance from oth-

ers before lifting.

CAUTION: RISK FROM NOISE

WHAT CAN HAPPEN HOW TO PREVENT IT

 • Under some conditions

and duration of use, noise

from this product may con-

tribute to hearing loss.

 • Alwayswearcertifiedsafety

equipment: ANSI S12.6

(S3.19) hearing protection.

SAVE THESE INSTRUCTIONS

FOR FUTURE USE

FEATURES (Fig. 1)

ON/OFF SWITCH

Place this switch (A) in the ON position to

provide automatic power to the pres-

sure switch and OFF to remove power

at the end of each use.

PRESSURE SWITCH

The pressure switch (J) automatically starts the motor when the

air tank pressure drops below the factory set cut-in pressure. It

stops the motor when the air tank pressure reaches the factory

set cut-out pressure.

SAFETY VALVE

If the pressure switch does not shut off the air

compressor at its cut-out pressure setting, the

safety valve (G) will protect against high

pressure by popping out at its factory set

pressure (slightly higher than the pressure

switch cut-out setting).

Autres manuels pour D55154

Table des matières

Langues :

Autres manuels DeWalt Compresseur d'air

DeWalt

DeWalt Emglo D55151 Manuel utilisateur

DeWalt

DeWalt DXCMV5048055 Manuel utilisateur

DeWalt

DeWalt XR DCC1018 Manuel utilisateur

DeWalt

DeWalt Emglo D55152 Manuel utilisateur

DeWalt

DeWalt DXCMTA5090412 Manuel utilisateur

DeWalt

DeWalt DWFP55126 Manuel utilisateur

DeWalt

DeWalt D55168 Manuel utilisateur

DeWalt

DeWalt DXCMTE6590811 Manuel utilisateur

DeWalt

DeWalt D55146 Manuel utilisateur

DeWalt

DeWalt DXCMH9919910 Manuel utilisateur

DeWalt

DeWalt DXCM271 Manuel utilisateur

DeWalt

DeWalt D55154 Manuel utilisateur

DeWalt

DeWalt DXCMLA1983054 Manuel utilisateur

DeWalt

DeWalt D55146 Manuel utilisateur

DeWalt

DeWalt DWFP55130 Manuel utilisateur

DeWalt

DeWalt Emglo D55151 Manuel utilisateur

DeWalt

DeWalt DXCMLA4708065 Manuel utilisateur

DeWalt

DeWalt DXCMTB5590856 Manuel utilisateur

DeWalt

DeWalt DXCM303 Manuel utilisateur

DeWalt

DeWalt Contractor's Electric Wheeled Portable Air Compressor... Manuel utilisateur

DeWalt

DeWalt DXCMV7518075 Manuel utilisateur

DeWalt

DeWalt Contractor's Electric Wheeled Portable Air Compressor... Manuel utilisateur

DeWalt

DeWalt D55141 Manuel utilisateur

DeWalt

DeWalt Emglo D55155 Manuel utilisateur

Manuels Compresseur d'air populaires d'autres marques

Sparmax

Sparmax DC-25XR Manuel utilisateur

KAESER

KAESER M122 Manuel utilisateur

GMC

GMC GAC1500 Manuel utilisateur

Briggs & Stratton

Briggs & Stratton Air Compressor Manuel utilisateur

Fini

Fini F3GST2TK Manuel utilisateur

Industrial Air

Industrial Air CP1580325 Manuel de programmation

Campbell Hausfeld

Campbell Hausfeld RP3300 Guide de démarrage rapide

Ingersoll-Rand

Ingersoll-Rand UP6 20 HP Manuel utilisateur

Hitachi

Hitachi EC99S Manuel de l'opérateur

Parkside

Parkside PKO 270 A1 Manuel utilisateur

Sullair

Sullair 185 Manuel utilisateur

Clas Ohlson

Clas Ohlson QIE-ZTH-15 Manuel utilisateur

Ferm

Ferm CRM1046 Manuel utilisateur

BE AC153 Manuel utilisateur

RIDGID

RIDGID OF25150A Manuel utilisateur

Johnson Controls

Johnson Controls QUANTUM LX Manuel

Sears

Sears Craftsman 919.167463 Manuel utilisateur

Ring Automotive

Ring Automotive RAC700 Manuel utilisateur
