Sullair 185 Manuel utilisateur

PART NUMBER:

02250216-783 R02

The information in this manual is current as of its

publication date and applies to compressor models

indicated on this cover with serial number:

201808010000

andallsubsequentserialnumbersuntilnextrevisionof

this manual or release of a replacement manual.

Publication date: 10/11/2019

WARRANTY NOTICE

Failure to follow the instructions

and procedures in this manual,

or misuse of this equipment, will

void its warranty.

Subject to EAR, ECCN EAR99 and related export control restrictions.

SAFETY WARNING

Users are required to read the

entire User Manual before han-

dling or using the product. Keep

the User Manual in a safe place

for future reference.

PARTS LIST MANUAL

Portable Air Compressor

185

Tier 4 Final

Kubota

Service Training Courses

Sullair training courses provide hands-on and classroom instruction for the proper operation, maintenance, and

servicing of Sullair products. Individual courses on Portable compressors are offered at regular intervals

throughout the year at Sullair’s training facility located in Michigan City, Indiana and on-site at Sullair distributor

locations.

Instruction includes training on the function and installation of Sullair service parts, troubleshooting common

faults and malfunctions, and actual equipment operation. These seminars are recommended for maintenance,

contractor maintenance, and distributor service personnel.

For more information contact:

Sullair Training Department

1-888-SULLAIR or

219-879-5451 (ext. 5623)

[email protected]

www.SullairTraining.com

- Or Write -

Sullair

1 Sullair Way

Michigan City, IN 46360

Attn: Training Department

Subject to EAR, ECCN EAR99 and related export control restrictions.

185 T4F Kubota Parts List Manual Table of Contents

Table of Contents

02250216-783 R02

Subject to EAR, ECCN EAR99 and related export control restrictions. iii

1.1 Procedure for ordering parts.............................................1

1.2 Recommended spare parts list.........................................2

1.3 Engine, compressor & parts..............................................4

1.4 Air inlet & exhaust.............................................................6

1.5 Cooling system & parts.....................................................8

1.6 Discharge system ...........................................................12

1.7 Manifold regulator/blowdown valve.................................18

1.8 Fuel system.....................................................................20

1.9 Electrical system parts....................................................24

1.10 Disconnect switch (optional)...........................................28

1.11 Frame, running gear & parts...........................................30

1.12 Frame & parts less running gear.....................................34

1.13 Canopy & parts ...............................................................36

1.14 Decals & parts.................................................................40

1.15 Instrument panel, standard gauge ..................................44

1.16 Optional dual hose reels & oilers ....................................46

1.17 Optional single hose reel & oilers....................................48

1.18 Drawbar installation.........................................................50

1.19 Optional Canadian lights.................................................52

185 T4F Kubota Parts List Manual Table of Contents

Notes:

02250216-783 R02

Subject to EAR, ECCN EAR99 and related export control restrictions. iv

185 T4F Kubota Parts List Manual 1: Parts List

02250216-783 R02

Subject to EAR, ECCN EAR99 and related export control restrictions. 1

1.1 Procedure for ordering parts

You should order parts from the nearest authorized Sullair representative or the

representative from whom the compressor was purchased. If for any reason you

cannot obtain parts in this manner, contact the factory directly at the address,

phone number, or website listed below.

When ordering parts, always indicate the serial number of the compressor. You

can get the serial number from the Bill of Lading for the compressor or from the

Serial Number Plate located on the compressor (see Figure 1-1: Serial Number

Plate Location).

The genuine Sullair service parts listed meet or exceed the demands of this

compressor. Use of replacement parts other than those approved by Sullair will

void the Sullair warranties specific to this product and may lead to hazardous

conditions over which Sullair has no control. Such conditions include, but are

not limited to, bodily injury and compressor failure.

Sullair North America Operations

1 Sullair Way

Michigan City, IN 46360 USA

www.sullair.com

1-800-SULLAIR (USA only)

1-219-879-5451 (non-USA)

Figure 1-1: Serial Number Plate Location

02250216-783 R02

Subject to EAR, ECCN EAR99 and related export control restrictions. 2

185 T4F Kubota Parts List Manual 1: Parts List

1.2 Recommended spare parts list

Part number Qty Description Notes

02250102-158 2 Element, Primary for Air Filter

02250102-160 2 Element, Safety for Air Filter (optional)

250028-032 1 Element for Compressor Fluid Filter

250034-112 1 Element for Air/Fluid Separator

02250212-657 1 Element for Engine Fuel/Water Separator (Kubota)

02250147-737 1 Repair kit for Regulator/Blowdown Valve Manifold

02250124-404 1 Element for Compressor Fluid Thermal Valve

241772 1 Repair Kit for Separator Return Line Strainer

02250115-271 1 Replacement, Air Filter Dust Ejector

02250218-969 1 Kit, Engine/Compressor Drive Coupling

02250218-962 1 Repair Kit for Compressor Inlet Valve

02250211-226 1 Element for Engine Oil Filter (Kubota filter)

02250211-228 1 Element for Engine Fuel Filter (Kubota filter)

02250217-926 1 Belt, engine (Kubota)

02250212-739 1 Element for engine oil separator (CCV filter) (Kubota)

02250212-692 1 Kit, 50 Hour Maintenance Parts included in kit:

02250211-226 1

250028-032 1

241772 1

02250212-693 1 Kit, 250 Hour Maintenance Parts included in kit:

02250102-158 2

250028-032 1

241772 1

02250212-695 1 Kit, 400 Hour Maintenance Parts included in kit:

02250211-226 1

02250212-696 1 Kit, 500 Hour Maintenance

Parts included in kit:

02250102-158 2

250028-032 1

02250212-657 1

241772 1

02250211-228 1

02250217-926 1

1.2 Recommended spare parts list

02250216-783 R02

Subject to EAR, ECCN EAR99 and related export control restrictions. 3

185 T4F Kubota Parts List Manual 1: Parts List

02250212-699 1 Kit, 1500 Hour Maintenance

Parts included in kit:

02250102-158 2

250028-032 1

250034-112 1

02250212-657 1

241772 1

02250211-226 1

02250211-228 1

250030-757 1

02250217-926 1

02250212-739 1

02250218-900 1 Relay, Glow Plug/Shutdown

02250218-901 1 Relay, Start/EGR

250030-757 1 Sullair AWF®Fluid—5 Gallons (18.9 Liters)

250030-758 1 Sullair AWF Fluid—55 Gallon Drum (208 Liters)

250023-146 1 Manual, CIMA Safety

Part number Qty Description Notes

02250216-783 R02

Subject to EAR, ECCN EAR99 and related export control restrictions. 4

185 T4F Kubota Parts List Manual 1: Parts List

1.3 Engine, compressor & parts

02250214-299 R06

1.3 Engine, compressor & parts

02250216-783 R02

Subject to EAR, ECCN EAR99 and related export control restrictions. 5

185 T4F Kubota Parts List Manual 1: Parts List

Key Part number Qty Description Notes

1 02250125-471 4 WASHER, SNUBBING VIBRATION MOUNT

2 02250125-472 4 MOUNT, VIBRATION ISOLATOR 185

3 02250148-791 1 VALVE, ENG OIL DRAIN M22X1.5

4 02250201-829 1 Design Item (dwg),COMPR ASSY DXX145147A

5 02250208-353 1 SPACER,FAN 1.5LG 185C KUB

6 02250208-412 1 FAN,BLWR 18" 185C KUB 10-BLD

7 02250208-584 1 COUPLING,185C KUB 49HP SAE 10.5

8 02250209-053 1 ENGINE,DIESEL KU D1803 49HP

9 02250209-483 1 VALVE,AIR INLET 2 1/2"

10 02250210-528 6 CAPSCREW,HEX M12X1.25X30 8.8GR

11 02250210-871 1 SUPPORT,BRACKET UNIT MTG 185C

12 02250249-814 2 SUPPORT,ENG FRT 185D KUB T4F

13 02250250-184 2 SUPPORT,SPACER ENG FRT 185D

14 043197 1 CLAMP, HOSE 1/2"

15 826202-242 1 O-RING, NEOPRENE 4 X 1/8"

16 828006-065 4 CAPSCREW, HEX 8.8 M6 X 65MM

17 828012-030 2 CAPSCREW,HEX 8.8 M12 X 30MM PLT

18 828406-075 8 CAPSCREW,FERRY HEAD 3/8-16 X 3/4"

19 829106-150 10 CAPSCREW,HX GR5 3/8-16 X 1 1/2

20 829108-325 4 CAPSCREW, HEX GR5 1/2 X 3 1/4"

21 829316-030 4 SCREW,SOCKET ISO 4762 M16X30MM

22 837806-094 10 WASHER,SPRLOCK REG PLTD 3/8

23 838806-160 4 WASHER, SPRLOCK METRIC M6

24 838816-350 4 WASHER, SPRLOCK METRIC M16

25 842115-062 1 HOSE, HEATER 5/8" (FT)

26 883212-195 8 WASHER, NORD-LOCK PL M12

Drawing notes

A1 MOUNT TO FRAME

A2 USE LOC-TITE 242

A3 APPLY "SIL-GLYDE" OR EQUIVALENT TO O-RING BEFORE INSTALLING

02250216-783 R02

Subject to EAR, ECCN EAR99 and related export control restrictions. 6

185 T4F Kubota Parts List Manual 1: Parts List

1.4 Air inlet & exhaust

02250215-360 R08
