INSTRUCTION MANUAL

Read all instructions BEFORE assembly and USE of product

KEEP INSTRUCTIONS FOR FUTURE USE.

12597A

ADULT ASSEMBLY REQUIRED

STYLES AND COLORS MAY VARY

DCP-IM-20230425

WARNING:

Adult assembly required because of

small parts. Keep assembly parts

out

of reach of children under 3 years.

CHOKING HAZARD

This stroller is not from, sponsored or

endorsed by Graco Children's Products Inc.

This stroller is not from, sponsored or

endorsed by Evenflo Company, Inc.

TURBOGLYDE

REVERSIBLE HANDLE

STROLLER

Fits Graco® SnugRide® Click Connect™ Infant Car Seat (not included)

Fits Evenﬂo® Embrace™ Select Infant Car Seat (not included)

Fits Evenﬂo® Nurture™ Infant Car Seat (not included)

www.DeltaChildren.com

Customer Service [email protected] www.DeltaChildren.com

CARE AND MAINTENANCE

WARNING: Please follow all of these instructions to ensure the safety of your child.

Keep these instructions for future reference.

WARNING: Failure to follow these instructions could result in serious injury or death.

• Avoid serious injury from falling or sliding out. ALWAYS insure that the child is properly positioned by

using the safety harness according to these instructions. ONLY children who have developed enough

upper body control to sit without leaning forward can use the front seat in the upright position.

• NEVER leave children unattended.

WARNING: CHOKING HAZARD Adult assembly required because of small parts.

Keep (assembly parts) out of reach of children under 3 years.

CAUTION: Purses, shopping bags, parcels, diaper bags or accessory items may change the balance of

the stroller and cause hazardous unstable conditions.

TO PREVENT INJURY

• Make sure all body parts are clear of the stroller when folding and unfolding.

• The maximum weight that can be carried in the lower basket, and child tray, each is 3 lbs (1.36 kg).

Excessive weight may cause a hazardous unstable condition to exist.

• Before allowing the children near the stroller, be certain the stroller is fully erect and latched in the

open locked position.

• Use of the stroller with children weighing more than 50 pounds (22.62 kg) or over 42 inches

(106.7 cm) tall, may cause a hazardous unstable condition to the stroller.

• NEVER use the stroller on stairways or escalators.

• NEVER allow your stroller to be used as a toy.

• NEVER use the stroller in conjunction with bicycles, skateboards, roller skates, or in-line skates.

Please discuss using the jogging stroller with your health care provider prior to jogging use.

We recommend that the child occupant needs to be 6 months of age, at the minimum, before use

of the stroller.

Product features and decorations may vary from the photo.

• To clean the plastic parts on stroller use a mild cleaning solution with warm water on a sponge or

damp cloth. Hand wash fabric with damp cloth and air dry. Do not use bleach.

• To keep your stroller wheels from squeaking, use silicone or graphite based lubricant.

• Check your stroller for loose screws, worn parts, torn material or stitching on a regular basis. Replace

or repair parts as needed, discontinue use of stroller if it should become damaged or malfunctions.

Before returning this product to the store!

Let’s see if we can assist you!

• Not sure how to assemble our product?

Visit our site for easy to follow instructions along with some Tricks and Tips assembly

videos https://www.deltachildren.com/pages/instructions

• If you are missing a piece or have a damaged part

Please contact our Consumer Experience Center for assistance at gcs@DeltaChildren.

com. To better assist you please have your Style# or Model# and Lot# available. This can

be found on a white rectangular sticker on your product, on the registration card, and on

the product’s box.

• In the event we do not have a replacement part available

You may need to return your product to the retailer for an exchange or refund.

• Warranty

In order to protect your investment, don’t forget to register your product.

You may also wish to consider purchasing our extended warranty.

Visit https://www.deltachildren.com/pages/extended-warranty for more details.

• Please note:

“All Final”, “As Is” or Third Party/Liquidator sales are not covered under our Limited

Manufacturer Warranty.

This Delta product is warranted to be free from defects for a period of 90 days from the date of purchase

under normal use. If a product is defective during this period, we will at our option repair or replace the

defective part or product. This limited warranty extends only to the original retail purchaser and is valid only

when supplied with proof of purchase, or if received as a gift, when the registration is on file with Delta.

This limited warranty does not cover the following:

• Products purchased as floor models or samples.

• Items purchased on an “as-is” basis, as a second hand product, or as a resale product.

• Items purchased at a Final sale, a “Going out of Business” sale, or a Liquidation sale. This limited warranty

gives you specific legal rights and you may also have other rights which vary from state to state.

This limited warranty gives you specific legal rights and you may also have other rights which vary from

state to state.

TO REGISTER YOUR PRODUCT for important safety alerts and updates to your product please visit www.

deltachildren.com

TO REPORT A PROBLEM, please log on to www.deltachildren.com and click the Consumer Care Tab.

EXTENDED WARRANTY

DON’T MISS YOUR CHANCE TO BE COVERED FOR ALL OF LIFE’S MISHAPS!

With Delta’s Extended Warranty, you’re covered for mechanical failure from normal use or if

your item stops working due to normal wear and tear, plus all those unexpected surprises.

2 YEARS OF PROTECTION

For Additional Information:

Simply visit our Website, register your product, and add the Extended Warranty

https://www.deltachildren.com/pages/product-registration

Extended Warranty only available in the following States: Arkansas, Colorado, Delaware, District of Columbia, Georgia, Idaho,

Illinois, Indiana, Iowa, Kansas, Kentucky, Louisiana, Maryland, Michigan, Mississippi, Missouri, Nebraska, Nevada, New Hampshire,

New York, North Carolina, North Dakota, Pennsylvania, Rhode Island, South Dakota, Tennessee, Utah, West Virginia

LIMITED MANUFACTURER WARRANTY

Customer Service [email protected] www.DeltaChildren.com

Parts Assembly

IMPORTANT! Please remove all parts from the package and identify them

before assembly.

Wheels x 4

Reversible

Handle

Child Tray

Stroller Frame

Shoulder Pads x 2

• First, remove the plastic protection box located on the reversible handle

levers.

• Second, release the locking latch clip which is located on the right side

of he stroller. (Fig. 1)

• Third, lift stroller until it “CLICKS” into a fully opened locked position.

Opening Stroller

Locking Latch

Clip

Side Frame

Fig. 1

IMPORTANT! Before assembly and each use, inspect this product for

damaged hardware, loose joints, missing parts, or sharp edges. NEVER use

if any parts are missing or broken. Contact manufacturer for replacement

parts and instructions if needed. Never substitute parts. IMPORTANT! Adult

assembly is required.

Remove stroller from box. The front wheels, rear wheels, reversible handle,

and child tray need to be installed prior to use.

Plastic Protection Box

Customer Service [email protected] www.DeltaChildren.com

Attaching Wheels

• Locate the four (4) legs on the stroller.

• Attach one wheel to the stroller frame leg (Fig. 4), making sure the wheel

swivel lock on the wheel is facing up. You will hear a “snap” once they are

in a fully locked position. (Fig. 4A) Check to make sure the wheel is fully

secure by pulling downward.

• Repeat on the three (3) other legs.

Assembly Wheels

Fig. 4

Stroller Frame

Leg

Fig. 4A

Swivel Lock

Fully Assembled and Locked in Position

Brake

Stroller Frame

Leg

Customer Service [email protected] www.DeltaChildren.com

Assembly Reversible Handle

Attaching Reversible Handle

• Insert handle into the stroller handle housing located on the left / right

side of the stroller frame (Fig. 5) until both sides “CLICK” (Fig. 5A) into a

fully locked position (Fig. 5B).

• Make sure handle is fully secure by lifting upwards.

Reversible

Handle

Housing

NOTE:

Reversible

Handle

Housing

MUST be

assembled

in this

direction

NOTE: Make sure

handle housing

is facing upward

before inserting

handle

Fig. 5

Fig. 5A

Fig. 5B

Attaching Canopy

• To attach canopy: Push both sides of the canopy posts inserts into the

canopy housing (Fig. 6) until they “CLICK” into a fully locked position

(Fig. 6A).

• To remove canopy: Press in both release buttons located on the sides

of the canopy housing, and lift upward.

Fig. 6

Canopy

Housing

Canopy

Inserts

Fig. 6A

Fully Locked

Position

Canopy

Fully Attached

)<5);•

Make sure handle is

in this direction

CORRECT INCORRECT

Fully Locked Position

Push buttons located

on the inside right/left

handle

Customer Service [email protected] www.DeltaChildren.com

Brakes

• To lock brakes: Apply light downward pressure on the wheel brake

located on the back of the wheel. (Fig. 1)

• To unlock brakes: Gently lift upward on the wheel brake located on the

back of the wheel. (Fig. 1A)

Swivel Lock

• To lock: Apply light downward pressure on the swivel lock

located on the front of the wheel. (Fig. 2)

• To unlock: Gently lift upward on the swivel lock located on the

front of the wheel. (Fig. 2A)

To Lock Swivel Lock

Press Downward

Fig. 1

To Lock Brake

Press Downward

Fig. 1A

To Unlock Brake

Push Upward

Set Up and Use

Swivel Lock

Brake

Swivel Lock

Brake

UNLOCK

LOCK

Swivel Lock

Brake

UNLOCK

LOCK

Fig. 2

Fig. 2A

Swivel Lock

Brake

To Unlock Swivel Lock

Press Upward

Customer Service [email protected] www.DeltaChildren.com

Fig. 3

Fig. 3A

Fig. 3B

Attaching and Removing Child Tray

• To attach child tray: First, rotate and align left and right side of child tray

posts with the left and right side stroller tray posts. Slide left and right side

child tray into left and right side stroller tray posts into a fully locked

position. (Fig. 3) Check to make sure child tray is securely attached to the

stroller by pulling upward on the child tray.

• To remove the child tray: Press the left and right release buttons located

underneath the left and right side of the child tray (Fig. 3A), and pull

upward on both sides to fully remove child tray. (Fig. 3B)

Release

Buttons

Set Up and Use

Fig. 4B

Fig. 4A

Fig. 4

Canopy and Sun Visor Adjustment

• To open the canopy: Pull forward on the front edge of the canopy until

fully opened. To lock canopy position lift canopy lock downward on both

sides (Fig. 4)

• To close canopy: Push canopy lock on both sides of the canopy. Rotate

canopy backward until close. (Fig. 4A)

• To open the sun visor: Grab front edge of the sun visor under canopy and

rotate forward until fully extended. (Fig. 4B)

Fig. 5

Seat Back Recline Positioning

• Pull the bar located on the back of the seat upwards and rotate seat

downward to recline seat. (Fig. 5)

• To return to an upright position: Push the seat upwards until it “CLICKS”

into a locked position.

Sun Visor

Customer Service [email protected] www.DeltaChildren.com

Setup and Use

Fig. 7

Adjusting Reversible Handle Into Forward Position

• First, slide both reversible handle release levers upward (Fig. 7) then,

rotate handle to forward position until it “CLICKS” into a fully locked

position (Fig. 7A).

• Make sure reversible handle is fully secure by lifting upwards.

Reversible Handle

Release Levers

Securing Seat Pad

• Locate the 2 locking buttons on the stroller seat pad and snap to the

lock slot of the stroller frame (Fig. 8). Repeat on the opposite side.

Fig. 7A

Seat Pad

Stroller

Frame

Locking buttons

Lock slot

Fig. 8

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Delta Children Poussette

Delta Children

Delta Children SPYDER 11381 Manuel utilisateur

Delta Children

Delta Children NORTH STAR Jeep VARY 33098 Manuel utilisateur

Delta Children

Delta Children LX SIDE X SIDE Manuel utilisateur

Delta Children

Delta Children Jeep SPORT UTILITY Manuel utilisateur

Delta Children

Delta Children Jeep CLUTCH PLUS Manuel utilisateur

Delta Children

Delta Children ALPHA ELITE 11504 AESV1 Series Manuel utilisateur

Delta Children

Delta Children Little Folks Classic Tour Plus Stroller... Manuel utilisateur

Delta Children

Delta Children Jeep EVOLVE 60010 Manuel utilisateur

Delta Children

Delta Children PATRIOT OPEN TRAILS DELUXE JOGGER Manuel utilisateur

Delta Children

Delta Children Little Folks EXPLORATION Manuel utilisateur

Delta Children

Delta Children Jeep Breeze Manuel utilisateur

Delta Children

Delta Children CLUTCH PLUS 11363 Manuel utilisateur

Delta Children

Delta Children POWERGLYDE Jeep 11460 Manuel utilisateur

Delta Children

Delta Children 11588 Manuel utilisateur

Delta Children

Delta Children CRUZER 11511 Manuel utilisateur

Delta Children

Delta Children J is for JEEP CROSS COUNTRY SPORT PLUS Manuel utilisateur

Delta Children

Delta Children Revolve 11898 Manuel utilisateur

Delta Children

Delta Children Jeep PowerGlide plus Manuel utilisateur

Delta Children

Delta Children DELUXE LITE Manuel utilisateur

Delta Children

Delta Children jeep EVEREST Manuel utilisateur

Delta Children

Delta Children OLYMPIA Little Folks LF11602 Manuel utilisateur

Delta Children

Delta Children The Clutch Manuel utilisateur

Delta Children

Delta Children Jeep 60008A Manuel utilisateur

Delta Children

Delta Children Jeep Arrow Manuel utilisateur

Manuels Poussette populaires d'autres marques

Hauck

Hauck Priya Trioset Manuel utilisateur

CHILDHOME

CHILDHOME CWQDN Manuel utilisateur

Dreamer Design

Dreamer Design Rebound GST Manuel utilisateur

Britax

Britax STEELCRAFT AGILE Manuel utilisateur

Graco

Graco 7427 Manuel utilisateur

Comfort

Comfort COMPASS Manuel utilisateur

OBaby

OBaby Aura Manuel utilisateur

Tutek

Tutek Tirso Manuel utilisateur

Babify

Babify Dual Plus Manuel utilisateur

Graco

Graco Stroller Manuel utilisateur

Special Tomato

Special Tomato Jogger Manuel utilisateur

Chicco

Chicco CORTINA TOGETHER TWO-PASSENGER STROLLER Manuel utilisateur

Otto Bock

Otto Bock Kimba neo Manuel utilisateur

Milly Mally

Milly Mally ROYAL Guide de démarrage rapide

Hauck

Hauck DUETT 3 PRAM Manuel utilisateur

BOB

BOB DUALLIE Manuel utilisateur

Nuna

Nuna Pepp Manuel utilisateur

Britax

Britax B2 Manuel utilisateur
