INSTRUCTION MANUAL

Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE.

BREEZE

STROLLER

WARNING:

Adult assembly required because of

small parts. Keep assembly parts out

of reach of children under 3 years.

CHOKING HAZARD

STYLES AND COLORS MAY VARY

13298

CAREANDMAINTENANCE

WARNING: Please follow all of these instructions to ensure the safety of your child. Keep these

instructions for future reference.

WARNING: Failure to follow these instructions could result in serious injury or death.

WARNING: Avoid serious injury from falling or sliding out.Always insure that the child is properly

positioned by using the safety harness according to these instructions.

WARNING: Never leave children unattended.

WARNING: CHOKING HAZARD Adult assembly required because of small parts.

Keep (assembly parts) out of reach of children under 3 years.

CAUTION: Purses, shopping bags, parcels, diaper bags or accessory items may change the balance of

the stroller and cause hazardous unstable conditions.

• The maximum weight that can be carried in the lower basket, and child tray, each is 3 lbs (1.36 kg).

Excessive weight may cause a hazardous unstable condition to exist.

• Before allowing the children near the stroller, be certain the stroller is fully erect and latched in the

open locked position.

• Use of the stroller with children weighing more than 45 pounds or over 42 inches tall, will cause

excessive wear and stress on the stroller and may cause hazardous unstable condition to exist.

NEVER use the stroller on stairways or escalators.

• NEVER use the stroller with roller skates or in-line skates.

Never allow your stroller to be used as a toy.

To prevent injury:

Make sure all body parts are clear of the stroller when folding and unfolding.

• To clean the plastic parts on stroller use a mild cleaning solution with warm water on a sponge or

damp cloth. Hand wash fabric with damp cloth and air dry. Do not use bleach.

• To keep your stroller wheels from squeaking, use silicone or graphite based lubricant.

• Check your stroller for loose screws, worn parts, torn material or stitching on a regular basis. Replace

or repair parts as needed.

• Discontinue use of stroller if it should become damaged or malfunctions.

• If you experience any difﬁculty with assembly, missing parts or use, please DO NOT return this item to

the store.Retail stores are unable to properly assist you. Contact our Customer Service Department

directly for assistance 1-646-435-8726 or [email protected].

Delta Children's Products Corp.

114 West 26th Street

New York, NY 10001

(646) 435-8726

www.DeltaChildren.com

Before returning this product to the store!

Let’s see if we can assist you!

• Not sure how to assemble our product?

Visit our site for easy to follow instructions along with some Tricks and Tips assembly

video’s https://www.deltachildren.com/pages/instructions

• If you are missing a piece or have a damaged part

Please contact our Consumer Experience Center for assistance at 646-435-8726 or email

[email protected]. To better assist you please have your Style# or Model# and

Lot# available. This can be found on a white rectangular sticker on your product, on the

regisatrion card, and on the product’s box.

• In the event we do not have a replacement part available

You may need to return your product to the retailer for an exchange or refund.

• Warranty

In order to protect your investment, don’t forget to register your product.

You may also wish to consider purchasing our extended warranty.

Visit https://www.deltachildren.com/pages/extended-warranty for more details.

• Please note:

“All Final”, “As Is” or Third Party/Liquidator sales are not covered under our Limited

Limited Manufacturer Warranty..

EXTENDED WARRANTY

DON’T MISS YOUR CHANCE TO BE COVERED FOR ALL OF LIFE’S MISHAPS!

With Delta’s Extended Warranty, you’re covered for mechanical failure from normal use or if

your item stops working due to normal wear and tear, plus all those unexpected surprises.

2 YEARS OF PROTECTION

For Additional Information:

Simply visit our Website, register your product, and add the Extended Warranty

https://www.deltachildren.com/pages/product-registration

Extended Warranty only available in the following States: Arkansas, Colorado, Delaware, District of Columbia, Georgia, Idaho,

Illinois, Indiana, Iowa, Kansas, Kentucky, Louisiana, Maryland, Michigan, Mississippi, Missouri, Nebraska, Nevada, New Hampshire,

New York, North Carolina, North Dakota, Pennsylvania, Rhode Island, South Dakota, Tennessee, Utah, West Virginia

LIMITED MANUFACTURER WARRANTY

This Delta product is warranted to be free from defects for a period of 90 days from the date of

purchase under normal use. This warranty extends only to the original retail purchaser and is valid

only when supplied with proof of purchase, or if received as a gift, when the registration is on file

with Delta. This limited manufacturer warranty does not cover the following:

• Products purchased as floor models or samples.

• Items purchased on an “as-is” basis, as a second hand product, or as a resale product.

• Items purchased at a Final sale, a “Going out of Business” sale, or a Liquidation sale.

TO REGISTER YOUR PRODUCT for important safety alerts and updates to your product

please visit www.deltachildren.com

TO REPORT A PROBLEM, please log on to www.deltachildren.com and click the

Consumer Care Tab, or contact us by phone at (646) 435-8726 or email [email protected]

Date of Purchase: _____________ (you should also keep your receipt)

Parts Assembly

IMPORTANT! Please remove all parts from the package and identify them

before assembly.

Customer Service Tel. 646-435-8726 www.DeltaChildren.com

Stroller Frame

IMPORTANT! Before assembly and each use, inspect this product for

damaged hardware, loose joints, missing parts, or sharp edges. NEVER use

if any parts are missing or broken. Contact manufacturer for replacement

parts and instructions if needed. Never substitute parts. IMPORTANT! Adult

assembly is required.

Remove stroller from box. The canopy, and child bar need to be installed

prior to use.

Child Bar

Canopy

WARNING: Care must be taken when folding and unfolding

the stroller to prevent ﬁnger entrapment.

• First, release the locking latch clip which is located on the left side of

the stroller. (Fig. 1)

• Second, lift up on the stroller handle with both hands until the stroller

frame is in a fully opened and locked position. (Fig. 1A) The stroller is

in a fully locked position when stroller clicks. Prior to placing your child

into the stroller, test to make sure stroller is in a fully opened and locked

position.

•Make sure front wheels are facing the correct direction (Fig.1B).

Opening Stroller

WARNING: Care must be taken when folding and unfolding the

stroller to prevent ﬁnger entrapment.

Locking Latch

Lift Upward To Release

Correct Front Wheel

Direction

Fig. 1

Fig. 1A

Fig. 1B

Assembly

Customer Service Tel. 646-435-8726 www.DeltaChildren.com

Attaching / Removing Child Bar

To Attach Child Bar:

•Insert both sides of the child bar into the bottom part of the child bar

(Fig. 3) until child bar “CLICKS” into a fully locked position.

Note: Pull upward on the child bar to ensure that the child bar is securely

locked.

To Remove Child Bar:

• Press the tabs inward located on both sides of the child bar and lift

upward until child bar is fully removed (Fig. 3A).

Attaching Canopy

To Attach Canopy:

•Locate the two metal tubing located on both sides of the front and back canopy.

(Fig. 2).

•Insert the back canopy tubing into the inner piece housing located on the inner

side of the stroller frame (Fig. 2A). Then wrap the elastic around the inner piece

to fully secure (Fig. 2B). Repeat on opposite side of back canopy.

•Insert the front canopy tubing into the side of the stroller frame housing

(Fig. 2C). Then wrap the elastic around the side of the stroller frame housing to

fully secure (Fig. 2D). Repeat on opposite side of the front canopy.

•To securely fasten the canopy, velcro the back of the canopy to the back of the

stroller seat (Fig. 2E).

Note: Pull outward on canopy to ensure that canopy is securely locked.

To Remove Canopy:

•First, remove all elastic bands located on both sides of the canopy. Then lift

both metal tubing located on the front and back of the canopy upward until fully

removed.

Fig. 2

Fig. 2D

Fig. 2E

Fig. 2A

Fig. 2B

Fig. 2C

Fig. 3

Back Side Metal

Canopy Tubing In Inner

Side Of Stroller Frame

Front Side Metal

Canopy Tubing On Side

Of Stroller Frame

Elastic

Band

Elastic Band

Fig. 3A

Tabs

Customer Service Tel. 646-435-8726 www.DeltaChildren.com

Seat Back Adjustment

• Recline Position: Squeeze both sides on cord housing and pull

away to recline seat, as shown in (Fig. 5A)

• Upright Position: Hold bottom cord loops while squeezing cord

housing and move cord housing upwards the backseat, as shown in

(Fig. 5B)

4Fig. 5B

Fig. 5BFig. 5A

Fig. 5A

RECLINE POSITION UPRIGHT POSITION

UPRIGHT POSITION

RECLINE POSITION

Setup and Use

Fig. 4A

Fig. 4

WARNING: Always lock brakes when the stroller is not being

pushed so that the stroller will not roll away. Never leave stroller

unattended on a hill or incline as the stroller may slide down the hill.

WARNING: NEVER leave child unattended in stroller.

Rear Non-Swivel Wheel Brakes - One Touch Brake System

• To engage brakes: Apply light downward pressure to the linked brake

lever located on the right side of the rear wheel axle. (Fig. 4) Check to make

sure the brakes are in a fully locked position, making sure stroller will not

move when pushed.

• To release brakes: Gently lift up on the linked brake lever (Fig. 4A).

Push downward on brake

lever to lock stroller

Push upward on brake

lever to unlock stroller

Assembly

Customer Service Tel. 646-435-8726 www.DeltaChildren.com

Fig. 6 Fig. 6A

Canopy Adjustment

• To open canopy, push forward on the front frame of the canopy. Pull

backwards on the canopy frame to fold completely (Fig. 6).

• To close the canopy, push on the front edge backward until canopy is all

the way collapsed (Fig. 6A).

Peek-A-Boo

• Peek-A-Boo window is located on the top center of the canopy (Fig. 8).

Foot Rest Adjustment

• To adjust foot rest: Pull lever located underneath footrest outward and

rotate upward or downward to adjust to its desired position (Fig. 7). There

are 2 footrest positions.

Fig. 7

Fig. 8

Rotate

Up or Down

SECURING CHILD

Securing Child

•Place your child in the stroller. Position the crotch belt between your

child’s legs.

•Pull shoulder straps over child’s arm and shoulder and fasten both strap

ends to the restraint system.

•Fasten both waist belts to the buckle on each side of the crotch belt.

Make sure you hear a “click” on both sides.

•Check to be sure the restraint system is securely attached by pulling it

away from your child. The restraint system should remain attached.

To tighten the waist belts and shoulder straps:

•Feed the anchored end of a waist belt up through the buckle to form a

loop A. Pull the free end of the waist belt B.

•Repeat this procedure to tighten the other waist belt.

•Feed the top end of the shoulder strap through the plastic stay to form

a loop . Pull the bottom end down to tighten the strap .

•Repeat this procedure to tighten the other shoulder strap.

To loosen the waist belts and shoulder straps:

•Feed the free end of the waist belt up through the buckle to form a

loop A. Enlarge the loop by pulling on the end of the loop toward the

buckle. Pull the anchored end of the waist belt to shorten the free end of

the waist belt B.

•Repeat this procedure to loosen the other waist belt.

•Feed the bottom end of the shoulder strap through the plastic stay to form

a loop . Pull the top end up to loosen the strap .

•Repeat this procedure to loosen the other shoulder strap.

Please note: After adjusting the restraint system to ﬁt your child, make sure

you pull on it to be sure it is securely fastened.

TIGHTEN

LOOSEN

5 Point Safety

Harness

•Tighten each waist belt and shoulder strap so that the restraint system is

snug against your child.

Please refer to the next section for instructions to tighten the waist belts.

Before Placing your Child in Stroller:

Close Canopy. Press both brake pedals down until they “click” into the locked position.

Make sure the brake pedals are pressed down completely.

Always set both brake pedals when parking the stroller.

Waist Belt

Crotch Belt

Restraint System

Fig. 19B

Fig. 19A

Customer Service Tel. 646-435-8726 www.DeltaChildren.com

Setup and Use

Folding the Stroller

WARNING: Care must be taken when folding and unfolding the stroller to

prevent ﬁnger entrapment.

NOTE: Make sure canopy is in it’s fully closed position, seat is in a fully

recline position before folding the stroller.

Folding the Stroller: Close the canopy as described on page 6 (Fig. 6A),

position the seat to a recline position as described on page 5 (Fig. 5A). A

dual action is needed to fold the stroller (Fig.19).

Action 1: Press the unlock tab with your thumb and hold.

Action 2: While pressing unlock tab, press the fold lever inward and

push stroller forward, then downward.

Once the stroller begins to fold, release the unlock tab and push downward

until stroller is in a fully folded position (Fig.19A). Folding latch (located on

the left side of the stroller) will automatically lock once stroller is in a fully

folded and locked position. (Fig. 19B).

Fig. 19

Auto Lock

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Delta Children Poussette

Delta Children

Delta Children ALPHA ELITE 11504 AESV1 Series Manuel utilisateur

Delta Children

Delta Children J is for JEEP CROSS COUNTRY SPORT PLUS Manuel utilisateur

Delta Children

Delta Children CLASSIC TOUR Manuel utilisateur

Delta Children

Delta Children Disney baby 61100-2344 Manuel utilisateur

Delta Children

Delta Children Jeep Scout Double Stroller Manuel utilisateur

Delta Children

Delta Children Jeep 60008A Manuel utilisateur

Delta Children

Delta Children NORTH STAR Jeep VARY 33098 Manuel utilisateur

Delta Children

Delta Children 11588 Manuel utilisateur

Delta Children

Delta Children POWERGLYDE Jeep 11460 Manuel utilisateur

Delta Children

Delta Children J is for Jeep Atlas AL Sport Manuel utilisateur

Delta Children

Delta Children Little Folks Classic Tour Plus Stroller... Manuel utilisateur

Delta Children

Delta Children OLYMPIA Little Folks LF11602 Manuel utilisateur

Delta Children

Delta Children Jeep CLUTCH PLUS Manuel utilisateur

Delta Children

Delta Children Jeep SPORT UTILITY Manuel utilisateur

Delta Children

Delta Children Jeep Classic Jogger Manuel utilisateur

Delta Children

Delta Children Jeep Gemini Manuel utilisateur

Delta Children

Delta Children Jeep PowerGlide plus Manuel utilisateur

Delta Children

Delta Children LX PLUS SIDE X SIDE 11709 Manuel utilisateur

Delta Children

Delta Children LX SIDE X SIDE Manuel utilisateur

Delta Children

Delta Children Revolve 11898 Manuel utilisateur

Delta Children

Delta Children The Clutch Manuel utilisateur

Delta Children

Delta Children DELUXE LITE Manuel utilisateur

Delta Children

Delta Children Jeep WRANGLER DELUXE Manuel utilisateur

Delta Children

Delta Children Jeep POWERGLYDE PLUS 11808 Manuel utilisateur

Manuels Poussette populaires d'autres marques

Hauck

Hauck Priya Trioset Manuel utilisateur

CHILDHOME

CHILDHOME CWQDN Manuel utilisateur

Dreamer Design

Dreamer Design Rebound GST Manuel utilisateur

Britax

Britax STEELCRAFT AGILE Manuel utilisateur

Graco

Graco 7427 Manuel utilisateur

Comfort

Comfort COMPASS Manuel utilisateur

OBaby

OBaby Aura Manuel utilisateur

Tutek

Tutek Tirso Manuel utilisateur

Babify

Babify Dual Plus Manuel utilisateur

Graco

Graco Stroller Manuel utilisateur

Special Tomato

Special Tomato Jogger Manuel utilisateur

Chicco

Chicco CORTINA TOGETHER TWO-PASSENGER STROLLER Manuel utilisateur

Otto Bock

Otto Bock Kimba neo Manuel utilisateur

Milly Mally

Milly Mally ROYAL Guide de démarrage rapide

Hauck

Hauck DUETT 3 PRAM Manuel utilisateur

BOB

BOB DUALLIE Manuel utilisateur

Nuna

Nuna Pepp Manuel utilisateur

Britax

Britax B2 Manuel utilisateur
