Delta Children DELUXE LITE Manuel utilisateur

www.DeltaChildren.com

DCP-IM-03222018-V1

Customer Care Tel. 1-(800)-377-3777

ADULT ASSEMBLY REQUIRED

INSTRUCTION MANUAL

Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE.

STYLES AND COLORS MAY VARY

DELTA DELUXE LITE

STROLLER

33009

WARNING:

Adult assembly required because of

small parts. Keep assembly parts

out

of reach of children under 3 years.

CHOKING HAZARD

Prevent serious injury from falls

or sliding out:

•ALWAYS use the restraint system.

•Only children who have developed enough

upper body control to sit without leaning

forward can use the front seat in the

upright position.

•NEVER leave child unattended.

•DO NOT use the storage bag to carry children.

To prevent product from tipping over:

•DO NOT exceed the maximum storage weight

limit of 3 lbs (1.36 kg) in the storage bag.

•DO NOT exceed the maximum storage weight

limit of 3 lbs (1.36 kg) in the cup holder.

•DO NOT place additional items on this

product, except as recommended in

the instructions.

To prevent injury:

•Make sure all body parts are clear of the

stroller when folding and unfolding.

•DO NOT place hot liquids in the cup holder.

Hot liquids can burn your child.

WARNING

•Please read these instructions before assembly and use of this product.

•Adult assembly is required.

•Use only for a child who weighs less than 40 lbs (15.88 kg).

•Maximum weight limit for the storage bag is 3 lbs (1.36 kg).

•Maximum weight limit for the cup holder is 3 lbs (1.36 kg).

•Product features and decorations may vary from the photo.

Consumer Information

Care

•The plastic parts may be wiped clean using a mild cleaning solution and

damp cloth. Hand wash fabric with damp cloth and air dry.

Do not use bleach.

•To keep your stroller wheels from squeaking, use a silicone or graphite

based lubricant.

Manufactured for and distributed by:

114 West 26th Street, New York, NY 10001

Customer Service

Tel. 1-(800)-377-3777

www.DeltaChildren.com

MADE IN CHINA

EXTENDED WARRANTY

DON’T MISS YOUR CHANCE TO BE COVERED FOR ALL OF LIFES MISHAPS!

With Delta’s Extended Warranty, you’re covered for mechanical failure from normal use or if

your item stops working due to normal wear and tear, plus all those unexpected surprises.

2 YEARS OF PROTECTION

For Additional Information:

Simply visit our Website, register your product, and add the Extended Warranty

https://www.deltachildren.com/pages/product-registration

Extended Warranty only available in the following States: Arkansas, Colorado, Delaware, District of Columbia, Georgia, Idaho,

Illinois, Indiana, Iowa, Kansas, Kentucky, Louisiana, Maryland, Michigan, Mississippi, Missouri, Nebraska, Nevada, New Hampshire,

New York, North Carolina, North Dakota, Pennsylvania, Rhode Island, South Dakota, Tennessee, Utah, West Virginia

STOP

Please DO NOT return this product to the store.

If you experience any difficulty with assembly, missing parts or use, please

DO NOT return this item to the store. Retail stores are unable to properly

assist you. Contact our Customer Service Department directly for

assistance 1-800-377-3777.

www.DeltaChildren.com • [email protected]m

Stroller

Cup Holder

Parts Assembly

•Locate the latch clip on the side frame of the stroller.

•Pull to release the latch clip.

IMPORTANT! Before assembly or each use, inspect this product for

damaged hardware, loose joints, missing parts or sharp edges. DO

NOT use if any parts are missing or broken. Contact manufacturer for

replacement parts and instructions if needed. Never substitute parts.

IMPORTANT! Please remove all parts from the package and identify

them before assembly.

•Position the stroller upright on its rear wheels.

•Grasp a handle with one hand. With your other hand, push down on the

front of the stroller to open.

Latch Clip

Side Frame

Customer Service Tel. (800) 377-3777 www.DeltaChildren.com

•With your foot, press down on the frame bar until it “clicks” into place.

•Check to be sure the stroller is locked open by pulling up on the frame bar.

Assembly

Frame Bar

Attaching Cup Holder

•Locate the knob on the side of the stroller.

•Fit the notch in the cup holder over the knob on the side rail and push

down until you hear a “click”. Pull up on the cup holder to be sure it

is secure.

Notch

Knob

Locked Position

Customer Service Tel. (800) 377-3777 www.DeltaChildren.com

Latch Clip

Setup and Use

To Unfold

•Locate the latch clip on the side of the stroller.

•Pull to release the latch clip on the side of the stroller.

•Grasp a handle with one hand. With your other hand, push down on the

front leg. Pull the stroller apart.

Prevent serious injury from falls

or sliding out:

•ALWAYS use the restraint system.

•Only children who have developed enough

upper body control to sit without leaning

forward can use the front seat in the

upright position.

•NEVER leave child unattended.

•DO NOT use the storage bag to carry children.

To prevent product from tipping over:

•DO NOT exceed the maximum storage weight

limit of 3 lbs (1.36 kg) in the storage bag.

•DO NOT exceed the maximum storage weight

limit of 3 lbs (1.36 kg) in the cup holder.

•DO NOT place additional items on this

product, except as recommended in

the instructions.

To prevent injury:

•Make sure all body parts are clear of the

stroller when folding and unfolding.

•DO NOT place hot liquids in the cup holder.

Hot liquids can burn your child.

WARNING

Customer Service Tel. (800) 377-3777 www.DeltaChildren.com

Setup and Use

•With your foot, press down on the frame bar until it “clicks” into place.

•Pull up on the frame bar to make sure it is locked.

Frame Bar

Canopy Adjustment

•The canopy can be adjusted to the open or closed position.

CANOPY CLOSEDCANOPY OPEN

Rear Wheel Brakes

To lock the rear wheel brakes:

•Press both brake pedals down until they “click” into the locked position.

Make sure the brake pedals are pressed down completely.

•Always set both brake pedals whenever you park the stroller.

To unlock the rear wheel brakes:

•Lift both brake pedals until they “click” into the unlocked position.

UNLOCK

TO LOCK

BRAKES

LIFT TO

PRESS DOWN

Customer Service Tel. (800) 377-3777 www.DeltaChildren.com

Securing Child

•Place your child in the stroller. Position the crotch belt between your

child’s legs.

•Fasten both waist belts to the buckle on each side of the crotch belt.

Make sure you hear a “click” on both sides.

•Check to be sure the restraint system is securely attached by pulling it

away from your child. The restraint system should remain attached.

To tighten the waist belts:

•Feed the anchored end of a waist belt up through the buckle to form a

loop A. Pull the free end of the waist belt B.

•Repeat this procedure to tighten the other waist belt.

To loosen the waist belts:

•Feed the free end of the waist belt up through the buckle to form a

loop A. Enlarge the loop by pulling on the end of the loop toward the

buckle. Pull the anchored end of the waist belt to shorten the free end of

the waist belt B.

•Repeat this procedure to loosen the other waist belt.

Please note: After adjusting the restraint system to ﬁt your child, make sure

you pull on it to be sure it is securely fastened.

TIGHTEN

LOOSEN

Crotch Belt

Waist BeltWaist Belt

•Tighten each waist belt so that the restraint system is snug against

your child. Please refer to the next section for instructions to tighten

the waist belts.

Restraint System

Customer Service Tel. (800) 377-3777 www.DeltaChildren.com

Before Placing your Child in Stroller:

Close Canopy. Press both brake pedals down until they “click” into the locked position.

Make sure the brake pedals are pressed down completely.

Always set both brake pedals when parking the stroller.

Storage

•Lift the front wheels toward the closed canopy.

•Slide the latch clip onto the side frame to secure in the folded

storage position.

Latch Clip

Side Frame

Customer Service Tel. (800) 377-3777 www.DeltaChildren.com

Hint: Make sure canopy is in the closed position before folding the stroller.

•Push lever outward 1, then upward 2.

Unlocked Position Locked Position
