Danfoss SH-E01 Manuel utilisateur

Electronic Solar Heat Regulator

SH-E01

Installation Guide

Danfoss Heating

MAKING MODERN LIVING POSSIBLE

SHE01

For a large print version of these instructions

please call Marketing on 0845 121 7400.

Danfoss can accept no responsibility for possible errors in catalogues, brochures, and other

printed material. All trademarks in this material are property of the respective companies.

Danfoss Heating 3

SH-E01

Electronic Solar Heat Regulator

Index

1.0 Installation Overview..............................................................................4

2.0 System Overview.......................................................................................4

3.0 Installation

3.1 Wiring.....................................................................................................5

3.2 Reset and setting of regulator.......................................................5

3.3 Mounting Instructions.....................................................................6

4.0 Operation

4.1 Function Test .......................................................................................7

4.2 Temperature Indication...................................................................7

5.0 Trouble Shooting.......................................................................................8

6.0 Technical Data.............................................................................................8

SHE01

1.0 Installation Overview

2.0 System Overview

Please Note:

This product should only be installed by a qualiﬁed electrician or

competent heating installer and should be in accordance with the

current edition of the IEEE wiring regulations.

T1 : Temperature sensor in solar collector

T2 : Temperature sensor in hot-water tank

: Circulation pump

: Solar heat regulator

The SH-E01 regulator is used for controlling utility water installations

consisting of a solar collector circuit and a hot water tank, where the

utility water is heated by solar energy.

The solar heat circuit circulation pump is controlled by the diﬀerential

temperature between the solar collector and the tank bottom.

If the diﬀerential temperature is higher than the preset start-up

temperature diﬀerential, the circulation pump will run.

To avoid unnecessary pump operation the temperature of the solar

collector has to be higher than 15°C before the pump starts operating.

The pump will run until the temperature diﬀerential is below 2°C.

Danfoss Heating 5

3.0 Installation

3.1 Wiring

The wiring to the regulator must be connected to the back plate

terminal strip:

Designation Terminal

Ground

Neutral N

Phase L

Sensor in solar collector T1

Sensor, common COM

Sensor in tank T2

Alarm AL1, AL2

Pump, phase P1

Supply voltage L1, max. 2(1)A

3.2 Reset and setting of regulator

Set the regulator via the DIL switch on the back.

Factory settings: Setting range

Start-up temp. diﬀerential 5 °C* 5 - 10 - 15 - 20 °C

Pump exercise ON** ON-OFF

Reset OFF

*) Pump stop temperature diﬀerential is ﬁxed: 2°C

**) Pump exercise sequence: 1 min/14 days

AL1 AL2

T1 COM T2 AL P1

SHE01

3.3 Mounting Instructions

Install the regulator on a wall. Start by attaching the back plate to

a vertical ﬂat surface by means of 2 x Ø 4 mm screws. The terminals

must be at the top.

1234

Position ON

Position OFF

Switch No.

System

Reset

Pump

Exercise

Setting

of start

temperature

diﬀerential

Switch No. Start temp.

diﬀerential

OFF OFF 5°C

OFF ON 10°C

ON OFF 15°C

ON ON 20°C

Danfoss Heating 7

Fit the temperature sensors in the immersion pockets - in the solar

collector and at the bottom of the hot-water tank. The cables are 3 m,

but can be extended as required by 2 x 0.75 mm2double-insulated

cable. EMC approved for 50 m cable length.

4.0 Operation

4.1 Function Test

The regulator is ready for operation when connected the mains. The

display becomes active and current temperatures are shown.

Display updates once per minute. Pressing the INFO button causes

the display to update immediately.

4.2 Temperature Indication

Solar Collector Tank

200

150

120

-9

-40

°C Display

F1 ashes

150°C ashes

Temperature ashes

Operating Range

Temperature ashes

-9°C ashes

F1 ashes

Meaning

Sensor fault/alarm

High temperature

Low temperature

Sensor fault/alarm

120

-40

°C Display

F2 ﬂashes

Operating Range

0°C ﬂashes

F2 ﬂashes

Meaning

Low temperature

Sensor fault/alarm

99°C ﬂashes

Temperature ﬂashes

HIgh temp./alarm

SHE01

5.0 Trouble Shooting

Display Cause Remedy

No display 230V supply oﬀ Check supply/connections

Red LED lit

Display ﬂashes F1

Fault at sensor 1

(Collector) Check connections/sensor

Red LED lit

Display ﬂashes F2

Fault at sensor 2

(Tank) Check connections/sensor

Red LED lit

Tank temp. >95°C

Pump does not run

Pump cannot‘keep up’

Check pump mode/ connections

Set speed higher

No alarm

Temperature

ﬂashes

Pump runs, indicates

high temperature

Pump does not run

Set speed higher

Pump or pump output defective

6.0 Technical Data

Supply voltage 230V/ 50 Hz ±10%

Ambient temperature Tmin 0°C, Tmax 45°C

Pump output 230 VAC, 2(1)A

Alarm output Voltage free relay output, 2(1)A

Enclosure rating IP40

Switching action Type 1B

Control pollution situation Pollution degree 2

Rated impulse voltage 2.5 kV

Ball pressure T 75 °C

Danfoss Heating 9

Index

1.0 Installationsanweisung....................................................................... 10

2.0 Anwendung............................................................................................... 10

3.0 Installation

3.1 Verkabelung ..................................................................................... 11

3.2 Einstellen des Reglers.................................................................... 11

3.3 Installation......................................................................................... 12

4.0 In Betrieb

4.1 Funktionstest.................................................................................... 13

4.2 Temperaturanzeige........................................................................ 13

5.0 Fehlersuche............................................................................................... 14

6.0 Technische Daten................................................................................... 14

SH-E01

Elektronischer Solarwärmeregler

SHE01

1.0 Installationsanweisung

Bitte beachten Sie:

Dieses Produkt darf nur von einem qualiﬁzierten Elektriker oder

Heizungsinstallateur gemäß der aktuellen Version der IEEE

Verkabelungsvorschriften installiert werden.

T1 : Temperatursensor im Solarkollektor

T2 : Temperatursensor im Warmwasserspeicher

: Umwälzpumpe

: Solarwärmeregler

Der Regler SH-E01 wird zur Regelung in Warmwasseranlagen

mit einem Solarkollektorkreislauf und Warmwasserspeicher

eingesetzt, in denen das Warmwasser durch Solarenergie

aufgeheizt wird. Die Umwälzpumpe des Solarheizkreislaufs wird

durch die Temperaturdiﬀerenz zwischen dem Solarkollektor

und dem Warmwasserspeicher geregelt. Die Pumpen-

Anlauftemperaturdiﬀerenz ist einstellbar. Um überﬂüssigen

Pumpenbetrieb zu vermeiden, empfehlen wir die Einstellung

einer Anlauftemperaturdiﬀerenz von 15 K, d.h. die Pumpe läuft an,

wenn die Temperatur im Solarkollektor die Speichertemperatur

um mehr als 15 K überschreitet und wird gestoppt, wenn diese

Temperaturdiﬀerenz auf unter 2 K gefallen ist.

2.0 Anwendung
