Installation Guide

DEVIreg™ 530M

Electronic Thermostat

DEVIreg™ 530M

Installation Guide2

1 Introduction � � � � � � � � � � � � � � � � � � � � � 2

1.1 Technical Specications . . . . . . . . . . . 3

1.1 Safety instructions . . . . . . . . . . . . . . . 4

2 Mounting instructions � � � � � � � � � � � � � � � 5

3 Settings � � � � � � � � � � � � � � � � � � � � � � � � 8

4 Warranty� � � � � � � � � � � � � � � � � � � � � � � 10

5 Disposal Instruction � � � � � � � � � � � � � � � 13

1 Introduction

DEVIreg™ 530M is an electronic thermostat provided with a

2-pole switch and a wire sensor to measure and control the

desired oor temperature. It can be either ush-mounted

(standard) or surface-mounted (using special box).

The thermostat has a button for adjusting the temperature

setting with a scale from 1 to 6 (each step corresponds to

approximately 3°C). Furthermore, it has a LED indicator

showing standby periods (green light) and heating periods

(red light).

More information on this product can also be found at:

devireg�devi�com

Table of Contents

DEVIreg™ 530M

3Installation Guide

1�1 Technical Specications

Operation voltage 220-240 V~, 50/60 Hz

Standby power consumption Max. 0.25 W

Relay:

Resistive load

Inductive load

Max. 15 A / 3450 W @ 230 V

cos φ= 0.3 Max. 1 A

Sensing units NTC 15 kOhm at 25°C (Default)

Sensing values:

0°C

20°C

50°C

42 kOhm

18 kOhm

6 kOhm

Hysteresis ± 0.4°C

Ambient temperature -10 to +30°C

Temperature range 15-35°C with oor sensor only

Cable specication max. 1x4 mm2or 2x2,5 mm2

Ball pressure test temperature 75°C

Pollution degree 2 (domestic use)

Controller type 1C

Storage temperature -20°C to +65°C

IP class 31

Protection class Class II -

Dimensions 85 x 85 x 36 mm

Weight 90 g

DEVIreg™ 530M

Installation Guide4

The product complies with the EN/IEC Standard“Automatic

electrical controls for household and similar use”:

• EN/IEC 60730-1 (general)

• EN/IEC 60730-2-9 (thermostat)

1�1 Safety instructions

Make sure the mains supply to the thermostat is turned o

before installation.

Important: When the thermostat is used to control a oor

heating element in connection with a wooden oor or

similar material, always use a oor sensor and never set the

maximum oor temperature to more than 35°C.

Please also note the following:

• The installation of the thermostat must be done by an

authorized and qualied installer according to local

regulations.

• The thermostat must be connected to a power supply

via an all-pole disconnection switch.

• The sensor is to be considered as live voltage. Have

this in mind if the sensor must be extended.

• Always connect the thermostat to continuous power

supply.

• Do not expose the thermostat to moisture, water, dust,

and excessive heat.

DEVIreg™ 530M

5Installation Guide

2 Mounting instructions

Place the thermostat at a suitable height on the wall

(typically 80-170cm).

The thermostat should not be placed in wet rooms.

Place it in an adjacent room. Always place the ther-

mostat according to local regulation on IP classes.

Note: A oor sensor enables a more accurate

temperature control and is recommended in all oor

heating applications and mandatory under wooden

oors to reduce the risk of over-heating the oor.

• Place the oor sensor in a conduit in an appropriate

place where it is not exposed to sunlight or draft from

door openings.

• Equally distant and >2cm from two heating cables.

• The conduit should be ush with the oor surface -

countersink the conduit if necessary.

• Route the conduit to the connection box.

• The bending radius of the conduit must be min.

50mm.

DEVIreg™ 530M

Installation Guide6

Follow the steps below to mount the thermostat:

1. Open the thermostat:

devireg™550

• Press the release tab in the bottom of the thermostat

using a at object.

• Carefully detach the front cover.

• Carefully detach the frame.

2. Connect the thermostat according to the connection

diagram.

IP31

-10T30

D530M

Mains

220-240V~

Max. Load

15 (1) A

Sensor

NLNTC

LOAD

-5°C

Danfoss A/S

Ulvehavevej 61

7100 Vejle

Denmark

DEVIreg™ 530M

7Installation Guide

By connecting an external timer to the terminal marked by

a moon symbol (and by using for example the same phase

as for the mains power supply), the thermostat can be set

to reduce the temperature by 5ºC during specied periods.

The screen of the heating cable must be connected to

the earth conductor of the power supply cable by using a

separate connector.

Note: Always install the oor sensor in a conduit in the oor.

3. Mount and reassemble the thermostat.

• Fasten the thermostat to a socket or an exterior wall

box by driving the screws through the holes in each

side of the thermostat.

• Install the frame and front cover in the reverse order of

disassembly.

4. Turn on the power supply.

DEVIreg™ 530M

Installation Guide8

3 Settings

How to change the minimum and maximum oor

temperatures

1. Remove the adjustment button.

4. Move the pins to the desired

positions.

5. Put the adjustment button

back in place.

Note: Please be aware of the following:

• The oor temperature is measured where the oor

sensor is placed.

• The temperature of the bottom of a wooden oor can

be up to 10 degrees higher than the top.

• Floor manufactures often specify the max temperature

on the top surface of the oor (usually 27-28˚C).

• Always use a oor sensor to control oor heating.

Without a oor sensor, the temperature control may

be less accurate and you risk overheating the oor.

devireg™550

DEVIreg™ 530M

9Installation Guide

Thermal

resistance

[m2K/W]

Examples of

ooring

Details Approximate

setting for

25˚C oor

temperature

0.05 8 mm HDF based

laminate > 800 kg/m328°C

0.10 14 mm beech

parquet 650 - 800 kg/m331°C

0.13 22 mm solid oak

plank > 800 kg/m332°C

< 0.17

Max. carpet thick-

ness suitable for

oor heating

acc. to EN 1307 34°C

0.18 22 mm solid r

planks 450 - 650 kg/m335°C

DEVIreg™ 530M

Installation Guide10

4 Warranty

A 2-year product warranty is valid for:

• thermostats: DEVIreg™ 530M

Should you, against all expectations, experience a problem with your DEVI product,

you will nd that Danfoss oers DEVIwarranty valid from the date of purchase on

the following conditions: During the warranty period Danfoss shall oer a new com-

parable product or repair the product if the product is found to be faulty by reason

of defective design, materials or workmanship.The repair or replacement.

The decision to either repair or replace will be solely at the discretion of Danfoss.

Danfoss shall not be liable for any consequential or incidental damages including,

but not limited to, damages to property or extra utility expenses. No extension of the

warranty period following repairs undertaken is granted.

The warranty shall be valid only if the WARRANTY CERTIFICATE is completed

correctly and in accordance with the instructions, the fault is submitted to the

installer or the seller without undue delay and proof of purchase is provided. Please

note that the WARRANTY CERTIFICATE must be lled in, stamped and signed by the

authorized installer performing the installation (Installation date must be indicated).

After the installation is performed, store and keep the WARRANTY CERTIFICATE and

purchase documents (invoice, receipt or similar) during the whole warranty period.

DEVIwarranty shall not cover any damage caused by incorrect conditions of use,

incorrect installation or if installation has been carried out by non-authorized electri-

cians. All work will be invoiced in full if Danfoss is required to inspect or repair faults

that have arisen as a result of any of the above. The DEVIwarranty shall not extend to

products which have not been paid in full. Danfoss will, at all times, provide a rapid

and eective response to all complaints and inquiries from our customers.

The warranty explicitly excludes all claims exceeding the above conditions.

For full warranty text visit www�devi�com�

devi�danfoss�com/en/warranty/
