D-Link KVM-440 Manuel utilisateur

Package Contents

Open the shipping carton and carefully unpack its contents. Please verify if the

following package contents are present and undamaged.

(1) 8- Port or 16- Port PS2/USB Combo KVM Switch

(4) 4-in-1 PS2/USB Combo KVM cable

(1) Rack Mount Bracket Kit Set

(1) Power Adapter

(1) CD-ROM with Manual

If any item is missing or damaged, please contact your local D-Link reseller for

replacement.

Product Overview

Item Feature Description

A Status LEDs Selected (Red):

A Red LED indicates that the corresponding PC is

selected.

Online (Green):

A Green LED indicates that the corresponding PC

is online.

B Switch Button Press the button corresponding to the computer

you would like to control via console.

C Reset Switch Press the Reset switch when you would like to reset

the device. The reset switch must be depressed

using a thin object like the end of a paper clip, or a

ball point pen.

D Power LED Indicates that the device is powered on.

Device Status LEDs and Buttons

Front Panel

ABCD

A B CD

Figure 1- KVM-440 Front Panel

Figure 2 - KVM-450 Front Panel

Rear Panel

Item Feature Description

APS/2 Mouse Console Port Connects to the PS/2 mouse

BPS/2 Keyboard Console

Port

Connects to the PS/2 keyboard

CVGA Monitor Console Port Connects to the VGA monitor

DComputer Connectors Connects to the computers with the 4-in-1 KVM

combo cables

ABCD

Figure 3 - KVM-440 Rear Panel

ABCD

Figure 4 - KVM-450 Rear Panel

KVM Port Connections

Precautions:

• Please turn o computers and attached devices before installing the KVM Switch.

• For computers with Keyboard Power On function, please unplug the power

cords in advance. Otherwise, the switch may not work properly.

• Some older computers may require you to enable USB in BIOS to make the USB

interface work.

Console Connection:

Plug the keyboard, mouse and monitor into the console ports on the rear panel

of the KVM Switch.

Installation:

System Connection:

Use the 4-in1 KVM combo cable to connect your computers. Refer to the gures

and instructions shown below for information about connecting the KVM to PCs.

You can connect the KVM switch to computers using one of the three methods

shown below:

A. Connect USB, PS/2 Keyboard, PS/2 Mouse and VGA connectors to your

computer. We recommend that users connect computers in the manner

shown below. (Figure 6)

Figure 6: USB, PS/2 and VGA Setup

Note: Please contact your reseller to purchase additional 4-in-1 KVM combo cables.

CONSOLE

UPGRADES

5V 2A

CONSOLE

UPGRADES

5V 2A

CONSOLE

UPGRADES

5V 2A

CONSOLE

UPGRADES

5V 2A

CONSOLE

UPGRADES

5V 2A

Figure 3

CONSOLE

UPGRADES

5V 2A

CONSOLE

UPGRADES

5V 2A

CONSOLE

UPGRADES

5V 2A

Scroll

1 2

! @

Scroll

Figure 5: 4-in-1 KVM combo cable

B. Connect only PS/2 Keyboard, PS/2 Mouse and VGA connectors to your

computer. (Figure 7)

Figure 7: PS/2 and VGA Setup

C. Connect only USB and VGA connectors to your computer. (Figure 8)

Figure 8: USB and VGA Setup

Cascade Chaining

The KVM switch supports cascades of up to 3 levels. Control up to 64/256/4096

PCs from a single console. Cascaded units do not require any special conguration

Once connected, the KVM Switches will automatically congure themselves

appropriately as the Master or Slave.

To install a cascade chain, please follow the instruction below.

A. Power o any attached computers/devices before installing the KVM Switch.

B. Use the 4-in-1 KVM combo cable (See Figure 5) to connect one or more Slave

KVM Switches to any PC port on the Master KVM Switch. The KVM to KVM must

be connected through a PS/2 connection. (Please refer to Figure 6 & Figure 7).

C. Plug in the power adapter for the rst level Master KVM Switch and connect

the Master KVM switch to computers.

D. Plug in the power adapter for each level Slave KVM Switch and connect the

Slave KVM switch to computers.

E. The power on sequence should be:

1. Master KVM Switch.

2. Second level Slave KVM Switch (connected to Master KVM Switch) if

needed.

3. Third level Slave KVM Switch (connected to second level Slave KVM Switch)

if needed.

4. All computers connected to Master/Slave KVM Switch.

Initial Plug-in Process:

Please plug in the Master KVM Switch rst before turning on any other devices

like monitor or computers.

Hot plugging and hot swapping:

The KVM switch supports hot plugging and hot swapping.

Rack Mounting

Operation

You can select a computer to control with the KVM switch using the front panel

buttons, hotkeys, or OSD.

1. Button Operation

Press the front panel button to select the connected PC.

2. Hotkey Operation

Please refer to the Hotkey Operation section in the User Manual.

3. OSD Operation

Please refer to the OSD Operation Section in the User Manual.

Figure 9 shows you how to attach the mounting brackets to the KVM Switch unit

for a standard 19-inch rack cabinet.

1. Attach the mounting brackets onto the sides of the KVM Switch unit using

screws. (Figure 9).

2. Install the KVM Switch unit into the rack cabinet.

Figure 9: Rack Mount
