D-Link DAP-1650 Manuel utilisateur

DAP-1650

Quick Install Guide

Wireless AC1200

Dual Band Gigabit Range Extender

2DAP-1650 Install Guide

Computer with:

• Windows® 8, 7, Vista®, XP (SP3), Mac OS® X (10.5 or higher)

• Internet Explorer 7, Chrome, Firefox, or Safari 5 or higher

Mobile Apps:

• SharePort Mobile App requires iOS 4.3 or Android 2.0

• QRS Mobile App requires iOS 4.3 or Android 2.0

For Internet Access:

• Cable or DSL Modem and Router

• Subscription with an Internet Service Provider (ISP)

Minimum Requirements

Package Contents

Note: Using a power supply with a dierent voltage than the one included with the

DAP-1650 will cause damage and void the warranty for this product. If any of the above

items are missing, please contact your reseller.

DAP-1650 Wireless Range Extender

Power Adapter

Ethernet Cable

Wi-Fi Conguration Card

Quick Install Guide

If any of the above items are missing, please contact your reseller.

DAP-1650 Install Guide 3

Product Overview

LED Color Status Description

Power LED

Orange Solid The DAP-1650 is powering on or booting up.

Blinking The device is in recovery mode.

Green

Solid The device is on and functioning properly.

Blinking The WPS button has been pushed and the device

is processing a connection.

Internet LED

Green Solid A successful connection has been established.*

Orange Blinking A rmware upgrade is in progress.

O The device is being reset to the factory default

settings.

Internet LED

Power LED

*Note: When the LED turns solid green, this indicates that the DAP-1650 is securely

connected to your wireless router or access point.

4DAP-1650 Install Guide

Connections

1 USB Port Connect a USB thumb drive to share les. (Only in AP mode.)

2 WPS Button Press to initiate the WPS (Wi-Fi Protected Setup) process.

3Ethernet

Ports (1-4)

Connect Ethernet devices like computers, gaming consoles,

printers, and NAS (Network Storage) devices to your wireless

network.

4Power

Button Press to power the device on and o.

5 Power Port Connect the supplied power adapter to an outlet.

DAP-1650 Install Guide 5

Connect to Your Router

Using WPS

1Find an available outlet near your wireless

router. Plug in the DAP-1650 and wait until the

Power LED is solid green.

2Press the WPS (Wi-Fi Protected Setup) button

on your wireless router.

Within one minute, press the WPS button on

the DAP-1650. The Power LED will start to blink.

4You can now unplug and move the DAP-1650 to a location between your

wireless router and the area that you need wireless coverage.

12V

USB

WPS

LAN

POWER

12V

USB

WPS

LAN

POWER

6DAP-1650 Install Guide

Connect Your

Wireless Devices

5From your wireless device go to the Wireless Utility to display the available

wireless networks and select the Wi-Fi Name (SSID) that appears on the Wi-Fi

Conguration Card.

6Your device is now connected to the DAP-1650 and can connect to your

wireless router. If you want to change your network settings, password, etc.,

follow the steps on the next page to congure the DAP-1650. To connect

additional devices, repeat step 5.

Your setup is complete!

When using WPS to connect to the router, the SSID on the DAP-1650 will

automatically be assigned the following:

• 2.4GHz (Your Router’s SSID) - EXT

• 5GHz (Your Router’s SSID) - EXT5G

The Wi-Fi password for your router will be the same for the DAP-1650.

Repeat step 5 to connect additional Wi-Fi devices to the DAP-1650.

Wi-Fi Name(SSID) 2.4Ghz:

dlink-xxxx

Wi-Fi Name(SSID) 5GHz:

dlink-xxxx-5GHz

Password: xxxxxxxx

To congure your extender, go to:

http://dlinkap.local.

Or http://192.168.0.50

Username: “Admin”

Password:”“ (leave the eld blank)

DAP-1650 Install Guide 7

Congure the DAP-1650

Using a Web Browser

Use the web-based conguration utility on the DAP-1650 to do the following:

• Run the Setup Wizard

• Change wireless and network settings

Open the wireless utility on your wireless device or computer. Select the Wi-Fi

Name (from the Wi-Fi Conguration Card) and enter the password.

1Plug the DAP-1650 in an available outlet near your

router. You may move it to a more suitable location

after conguration.

Open a web browser (e.g., Internet Explorer, Firefox, Safari, or Chrome) and enter

http://dlinkap.local./. You may also enter the IP address* of the DAP-1650.

Windows XP users can enter http://dlinkap.

* The default IP address is 192.168.0.50. Once the DAP-1650 connects to your router, it

will get assigned a new IP address based on your router/network’s DHCP settings. You

will need to log in to your router and view the DHCP table to see what IP address was

assigned to the DAP-1650. The MAC address is printed on the label on the DAP-1650.

12V

USB

WPS

LAN

POWER

Wi-Fi Name(SSID) 2.4Ghz:

dlink-xxxx

Wi-Fi Name(SSID) 5GHz:

dlink-xxxx-5GHz

Password: xxxxxxxx

To congure your extender, go to:

http://dlinkap.local.

Or http://192.168.0.50

Username: “Admin”

Password:”“ (leave the eld blank)

8DAP-1650 Install Guide

The rst time you connect, the DAP-1650 will automatically launch the Wi-Fi

Connection Setup Wizard. Click Next.

Note: The next time you go to the conguration utility, you will see the login

screen. By default the password is blank. Click Log in.

5By default, your DAP-1650 will be set to Extender mode. Click Next.

DAP-1650 Install Guide 9

6This screen will allow you to set a Wi-Fi Network Name (SSID) and

Wi-Fi Password for both the 2.4GHz and 5GHz bands. Click Next.

7You will see this screen while the DAP-1650 is scanning for an available

Wi-Fi network. Click Finish.

8You will see a list of available Wi-Fi networks. Select the Wi-Fi Name of

the wireless network you wish to connect to. Click Connect.

10 DAP-1650 Install Guide

9If the existing wireless network is password protected, you must enter

the Wi-Fi Password. Click Next.

Set a password for administrator access to the Web-based conguration.

Click Next.

A summary page will be displayed showing the Wi-Fi Settings. Click Finish.

The DAP-1650 will reboot.
