D-Link GO-SW-5E Manuel d'installation et d'exploitation

GO-SW-5E & GO-SW-8E

• Five or Eight 10/100 Mbps Ports

• Up to 100Mbps of Dedicated Bandwidth per Port and up

to 200Mbps Bandwidth in Full-Duplex mode

• Compatible with All Popular Operating Systems

• Plug & Play Installation

• Conserves energy with D-Link Green Technology

• Supports MAC address learning

Product Highlights Think Green

The GO-SW-5E/GO-SW-8E 5-Port and 8-Port 10/100 Desktop Switch is part of D-Link’s

new series of SOHO devices that make use of D-Link’s Green Technology, providing

energy savings, reduced heat, and a longer product life without sacricing performance

or functionality. An energy-ecient power adapter (EnergyStar Level V qualied),

minimized use of harmful substances (RoHS compliant), and recyclable packaging

make this switch truly environmentally friendly.

Conserves Energy

The GO-SW-5E/GO-SW-8E 5-Port and 8-Port 10/100 Desktop Switch helps you conserve

energy automatically. The switch saves substantial amounts of power by cutting power

usage for unused ports or ports connected to computers that have been shut down.

• Economical yet innovative fanless design runs

cool and quiet

• 10/100 ports allow you to connect all your

devices for fast file transfers and smooth

media streaming

• EEE compliance reduces energy consumption

without sacriaficing performcance

5/8 Port 10/100 Desktop Switch

GO-SW-5E & GO-SW-8E 5/8 Port 10/100 Desktop Switch

Environmentally Friendly

The GO-SW-5E/GO-SW-8E ve and eight port 10/100 Desktop Switch was designed with the

environment in mind, and is compliant with Energy Star Level V, as well as with the stringent

CEC and MEPS regulations that require the use of energy ecient power adapters. The switch is

also built to follow RoHS standards to minimize use of hazardous materials, and uses recyclable

packaging that helps reduce waste, complying with the WEEE directive.

Package Contents

• 5/8 port 10/100 Desktop Switch

(GO-SW-5E/GO-SW-8E)

• Power Adapter

• Quick Install Guide

Minimum System Requirements

• Devices Supporting 802.3 Ethernet, 802.u

Faster Ethernet, Cat5 or better Ethernet Cable

• Network Interface Card for each computer

Features

• Built-in D-Link Green Technology

• Inexpensive 10/100 solution for Home/SOHO

• 5/8 10/100 Mbps ports

• 1/1.6 Gbps switching fabric

• Auto MDI/MDIX crossover for all ports

• Store-and-forward switching scheme

• Full/half-duplex for Ethernet/Fast Ethernet speeds

• IEEE 802.3x Flow Control

• RoHS compliant

• Plug-and-play installation

Technical Specications

GO-SW-5E GO-SW-8E

Switching Fabric • 1Gbps • 1.6Gbps

Standards • IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)

• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair

copper)

• ANSI/IEEE 802.3 NWay auto-negotiation

• IEEE 802.3x Flow Control

• IEEE 802.3az Energy-Efficient Ethernet (EEE)

Data Transfer Rates • Ethernet:

- 10 Mbps (half duplex), 20 Mbps (full duplex)

• Fast Ethernet:

- 100 Mbps (half duplex), 200 Mbps (full duplex)

Network Cables • 10BASE-T:

- UTP CAT 3, 4, 5/5e (100 m max.)

- EIA/TIA-586 100-ohm STP (100 m max.)

• 100BASE-TX:

- UTP CAT 5/5e (100 m max.)

- EIA/TIA-568 100-ohm STP (100 m max.)

MDI/MDIX • Auto MDI/MDIX adjustment for all ports

LED Indicators • Per port: Link/Activity/Speed • Per device: Power

Transmission Method • Store-and-forward

MAC Address Table • 2K • 2K

Packet Filtering/Forwarding Rates • Ethernet: 14,880 pps per port • Fast Ethernet: 148,800 pps per port

RAM Buffer • 128KB per device

General Specications

DC Input • External 5 V/1 A Level “V” Power Adapter

Power Consumption • DC input: 0.9 watts

• AC input: 1.6 watts

• DC input: 1.78 watts

• AC input: 2.19 watts

MTBF • 1,623,329 hours • 2,137,319 hours

Operating Temperature • 14 ˚ to 158 ˚F (0 to 50 ˚C)

Storage Temperature • 14 ˚ to 158 ˚F (-10 to 70 ˚C)

Operating Humidity • 10% to 90% RH non-condensing

Storage Humidity • 5% to 90% RH non-condensing

Dimensions • 3.43 x 1.85 x 0.85 inches (87 x 47.85 x 21.7 mm) • 5.57 x 3.09 x 0.94 inches (141.5 x 78.5 x 23.8 mm)

Weight • 3.69 ounces (105 grams) • 6.88 ounces (195 grams)

Certifications • FCC Class B

• ICES-003 Class B

• CE Class B

• C-Tick Class B

• VCCI Class B

• cUL/UL

• CCC

• Anatel

• LVD

Warranty

Warranty • 3-Year Limited1

Order Information

Part Number Description

GO-SW-5E 5-Port 10/100 Desktop Switch

GO-SW-8E 8-Port 10/100 Desktop Switch

13 Year Limited Warranty available only in the USA and Canada. All references to speed are for comparison purposes only. Product specications, size and shape are subject to change without notice, and actual product appearance may dier from

that depicted herein.

All references to speed and range are for comparison purposes only. Product specications, size, and shape are subject to change without notice,

and actual product appearance may dier from that depicted herein.

trademarks of D-Link Corporation or its subsidiaries in the United States and/or other countries. Other trademarks or registered trademarks are the

property of their respective owners.

Updated 05/13

For more information

GO-SW-5E & GO-SW-8E 5/8 Port 10/100 Desktop Switch
