DKVM-222

User Manual

2-Port USB KVM Switch with Audio Support

2D-Link DKVM-222 User Manual

Table of Contents

Preface................................................................................ 3

Manual Revisions.......................................................................... 3

Trademarks ..................................................................................... 3

Product Overview.............................................................. 4

Package Contents......................................................................... 4

System Requirements................................................................. 4

Features............................................................................................ 4

Product Overview......................................................................... 5

KVM Installation ................................................................ 6

Hardware Installation.................................................................. 6

Software Installation ................................................................... 7

Windows® ................................................................................ 7

Mac ............................................................................................ 8

KVM Operation .................................................................. 9

Accessing the KVM....................................................................... 9

Windows® ................................................................................ 9

Mac ..........................................................................................10

Linux........................................................................................11

Troubleshooting ..............................................................12

Technical Specications..................................................14

3D-Link DKVM-222 User Manual

Preface

D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify

any person or organization of such revisions or changes.

Manual Revisions

Trademarks

D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United

States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks

of their respective companies.

from D-Link Systems, Inc.

Revision Date Description

1.0 April 4, 2014 • DKVM-222 Revision A1

Preface

4D-Link DKVM-222 User Manual

Product OverviewProduct Overview

If any of the above items are missing, please contact your reseller.

Package Contents

System Requirements

• 2-Port USB KVM Switch with Audio Support

• Remote

• CD-ROM (includes software and manual)

• Quick Install Guide

• USB Keyboard

• USB Mouse

• VGA Monitor

• Speakers (optional)

• Two Computers with available USB Ports

• Windows® 8, Windows® 7, Windows Vista®, Windows® XP (SP 2 or higher),Windows® 2000, and Mac OS (10.5 and

above)

Features

• Control two computers with one monitor, USB keyboard and USB mouse

• Switch audio between two computers

• Supports DDC, DDC2, and DDC2B

• Compact and portable design

• Remote switch toggles between PCs

• Supports up to 2048 x 1536 monitor resolution

• Compatible with VGA, SVGA and MultiSync monitors

5D-Link DKVM-222 User Manual

Product Overview

Audio Connector

Connects to PC audio port

Audio Port

Connects to speakers

VGA Connector

Connects to monitor cable

USB Connector

Connects to PC USB Port

USB Ports

Connect to keyboard and mouse

Remote Button

Toggles between PCs

6D-Link DKVM-222 User Manual

KVM InstallationKVM Installation

Hardware Installation

Note:

This KVM Switch will not detect whether a computer is on or o if the “Power On” function is

set in the BIOS. If you switch to a computer that is turned o, nothing will be displayed on the

monitor.

Please follow the diagram below to connect the KVM switch to your workstation computers. Speakers are optional.

Speakers Monitor Keyboard Mouse Remote

7D-Link DKVM-222 User Manual

KVM Installation

1. Please insert the installation CD-ROM into your computer's

CD drive. When the autorun screen appears, click Install.

2. When the Setup Wizard appears, click Next.

3. Please follow the installation steps on the screen.

4. Click Finish to complete the installation and launch the KVM

software.

5. When the installation is completed, a D-Link icon will appear in

the taskbar area indicating the ready status of the connected

computer.

Task bar area:

Software Installation

Windows®

8D-Link DKVM-222 User Manual

KVM Installation

1. Please insert the installation CD-ROM into your computer's

CD drive.

2. From a Finder window, click on your CD drive and then open

the Utility folder.

3. Double-click DKVM-222_MAC_Utility.DMG and then

double-click on DKVM-222 package installer to install the

software.

4. Please follow the installation steps on the screen.

5. Click Close to complete the installation and launch the KVM

software.

6. When the installation is completed, a D-Link icon will appear

in the doc area indicating the ready status

of the connected computer.

Mac (10.5 and higher)

9D-Link DKVM-222 User Manual

KVM OperationKVM Operation

Software Settings

Right-click on the D-Link icon and select Setting.

The following options are available:

a. KVM Switch: This hotkey will switch between PCs but maintain the audio feed of

the original computer.

b. Audio Switch: This hotkey will switch the audio to the other PC, but maintain

control of the original computer.

c. All Switch: This hotkey will switch between PCs, including audio.

You may choose a number for each hotkey. Please choose dierent numbers for each

setting.

Remote Switching

Push the remote button to switch between computers.

The green and orange LEDs indicate the selected PC.

Hot key Switching

Press the Scroll Lock key two times to switch between PCs, including audio.

Press the Caps Lock key two times to switch between PCs but maintain the audio feed of the original computer.

Software Switching

a. Left-click on the D-Link icon to switch between PCs.

b. You may also use a specied keyboard hotkey to switch between PCs. See the instructions below.

Accessing the KVM

Windows®

10D-Link DKVM-222 User Manual

KVM Operation

Remote Switching

Push the remote button to switch between computers.

The green and orange LEDs indicate the selected PC.

Software Switching

a. Click on the D-Link icon to switch between PCs.

b. You may also use a specied keyboard hotkey to switch between PCs. See the

instructions below.

Software Settings

Click and hold on the D-Link icon located in the doc area for 3 seconds and select

Setting.

The following options are available:

a. KVM Switch: This hotkey will switch between PCs but maintain the audio

feed of the original computer.

b. Audio Switch: This hotkey will switch the audio to the other PC, but maintain

control of the original computer.

c. All Switch: This hotkey will switch between PCs, including audio.

You may choose a number for each hotkey. Please choose dierent numbers for

each setting.

Mac
