D-Link DES-1018MP Manuel utilisateur

D E S -10 18M P 1

ENGLISH

CONTENTS OF

PACKAGING

CONTENTS

INTRODUCTION

The D-Link DES-1018MP is a PoE unmanaged switch capable of feeding power to Power over

Ethernet (PoE) devices such as network cameras. The DES-1018MP has 16 ports operating

at 10/100 Mbps ports with 16 PoE ports (Ports 1 to 16). It also has 2 10/100/1000Base-T/SFP

Combo ports ideal for upgrading home and small ofce businesses with limited budgets.

POWER CORD

If any of these items are missing from your packaging, contact

your reseller.

Warning: Using a power adapter with a different voltage rating

will damage and void the warranty of this product.

16 Ports 10/100Mbps PoE + 2 10/100/1000Base-T/SFP

Combo Ports Unmanaged Switch

DES-1018MP

POWER CORD RETAINER

RACK-MOUNT KIT AND RUBBER FEET

QUICK INSTALLATION GUIDE

D E S -10 18M P

ENGLISH

PRODUCT

SETUP

BEFORE SETTING UP THE DES-1018MP

Please follow the steps below to set up the switch:

1. Install the DES-1018MP in a cool and dry place. Refer to the Technical Specications for the

acceptable operating temperature and humidity ranges.

2. Install the switch in a site free from strong electromagnetic source, vibration, dust, and direct

sunlight.

3. Leave at least 10 cm of space at the left and right-hand side of the switch for ventilation.

4. Visually inspect the power jack and make sure that it is fully secured to the power adapter.

Do not stack any device on top of the switch.

INSTALL THE POWER CORD RETAINER

To prevent accidental removal of the power cord, it is recommended to install the power cord

retainer together with the power cord.

2. Plug the power cord into the power socket of the

switch.

1. With the rough side facing down, insert the tie into the

hole below the power socket.

D E S -10 18M P 3

ENGLISH

CONNECTING THE DES-1018MP TO YOUR NETWORK

A. POWER

Plug the AC power cord into a free wall socket, then plug the other end into the power outlet

of the DES-1018MP. The Power LED will illuminate conrming that the device has powered

up successfully.

B. PoE PORTS (PORTS 1 - 16)

The PoE ports can supply up to a total PoE budget of 246.4 watts, allowing users to attach

an IEEE 802.3af compliant device to the DES-1018MP.

16 PoE Ports

3. Slide the retainer through the tie until it reaches the

end of the cord.

INSTALL THE POWER CORD RETAINER

4. Wrap the tie of the retainer around the power cord

and back into the retainer to lock it.

Fasten the tie until the power cord is secured.

D E S -10 18M P

ENGLISH

LED INDICATORS

The LED indicators allow you to monitor, diagnose, and troubleshoot any potential problem within the

switch, connection, or attached devices.

LED Color Status Description

Power Green Solid light Power on

Off Power off

Link/Act/Speed

10/100/1000Base-T/

SFP Ports (17 to 18)

Green Solid light Secure connection to a 1000 Mbps

Ethernet device is established.

Blinking The port is receiving or transmitting

data.

Amber Solid light Secure connection to a 10/100 Mbps

Ethernet device.

Blinking The port is receiving or transmitting

data.

Off Light off No link

Link/Act/Speed

10/100 Mbps

Ports (1 to 16)

Green Solid light When there is a secure connection (or

link) to 10/100Mbps Ethernet device at

any of the ports.

Blinking When there is reception or transmission

of data occurring at 10/100Mbps.

Off Off No link

PoE

(Ports1 to 16)

Green Solid light The port is successfully connected to a

PoE device and is powering the device

properly.

Red Solid light The PoE port has failed, possibly due

to:

1. PoE total power budget shortage

2. Over current: Exceeds the

power current of powered device's

classication.

3. Short circuit: An intentional short

circuit has been performed on a

powered device.

Off Light off No connection to a PoE device

D E S -10 18M P 5

ENGLISH

TROUBLESHOOTING

SETUP AND CONFIGURATION PROBLEMS

1. WHAT SHOULD I DO IF THE POWER LED DOES NOT LIGHT UP?

- Try unplugging the power cord and plugging it back into the socket.

2. WHAT SHOULD I DO IF A CONNECTED DEVICE IS NOT DETECTED?

- Ensure the Port LED is illuminated or ashing. If not, try using a new LAN cable.

3. WHAT SHOULD I DO IF A POE DEVICE IS NOT POWERED BY THE DES-1018MP?

- Ensure that the PoE device is connected to one of the four PoE enabled ports (1 to 16) and the

connected PoE devices do not exceed the maximum power budget of 246 W.
