D-Link DPR-2000 Manuel utilisateur
WIRELESS G
USB MULTIFUNCTION PRINT SERVER
Quick Install Guide+
Руководство по быстрой установке+
Guía de instalación rápida+
Guia de instalação rápida+
快速安裝手冊+
Petunjuk Pemasangan Cepat+
DPR-2000
2
This product can be set up using
any current web browser, i.e.,
Internet Explorer 6 or Netscape
Navigator 7.0
5V DC, 3A Power
Adapter
Before You Begin
Check Your Package Contents
DPR-2000 USB Multi-Function Print Server
CD-ROM (Software, Manual and Warranty)
Ethernet (CAT5 UTP) Cable
If any of the above items are missing, please contact your reseller.
This Quick Installation Guide provides you with step-by-step instructions to set up
your MFP Server and start your printing tasks. The model you have purchased may
be slightly different from those seen in the illustrations. For more detailed information
regarding the Print Server, please refer to the User’s Manual that is included in your
installation CD.
NOTE: The images and setting values in this manual are FOR YOUR REFERENCE ONLY.
The actual settings and values depend on your Print Server, system and network.
Using a power supply
with a differe n t
voltage rating will damage
this product and void its
warranty.
DPR-2000
Wireless G USB
Multifunction Print Server
©2008 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective
holders. Software and specications subject to change without notice.
3
EXTERNAL FEATURES
Physical Interfaces
USB Ports
Ethernet Port (LAN)
DC Power Connector
Reset Button (Bottom Panel)
The DPR-2000’s USB ports are located on the rear panel. The port can be congured
using the web congurator which allows users to congure settings through their
web browser.
The default IP address of the DPR-2000 is automatically acquired from a DHCP
server on the network. If a DHCP server cannot be found the default IP address for
the DPR-2000 will be 192.168.0.10.
NOTE : The PC’s IP address must be in the same subnet as the Print Server’s IP
address for the two devices to communicate. (For example, if the Print
server’s IP address is 192.168.0.10, with a subnet mask of 255.255.255.0,
then your computer’s IP address should be 192.168.0.x, where x is a value
between 1-254, excluding 10.)
The Print Server’s rear panel features an RJ-45 port for the connection of a
10/100Mbps CAT 5 Ethernet cable. The port supports the NWay protocol, allowing
the Print Server to automatically detect or negotiate the transmission speed of the
network.
The DC power input connector is located on the Print Server’s rear panel and is
labeled DC 5V.
Press and release this button to reset the MFP Server. To restore the device to
factory default settings , press and hold the button for three seconds until the USB
LED on the front panel lights up and then release the button.
USB Ports
DC Power Connector
LAN Ethernet Port
4
LED INDICATORS
Power
USB
Link/Act
The top panel of the Print Server features four LED indicators:
A steady blue light conrms that the Print Server is turned ON.
A steady blue light indicates the printer is online and successfully connected to
the print server. This light will also blink to indicate that data is being transferred
between the print server and printer.
A steady blue light conrms that the Print Server has a connection to an Ethernet
network. This light will also blink when receiving or transmitting data on the
network.
These four LED indicators are also used during the device’s power-on self test to
indicate any hardware failures. Please refer to the User Manual for more information
about this test.
A steady blue light conrms that the Print Server has a connection to a wireless
network. This light will also blink when receiving or transmitting data on the
network.
Wireless Link/Act
5
HARDWARE INSTALLATION
WARNING: There may be conguration problems if the Print Server is turned on
without rst establishing a network connection.
Follow the steps below to avoid any complications during the hardware
installation:
1. Conrm that the printer you will use to connect to the DPR-2000 is operating
correctly.
2. When you have conrmed that the printer is operating correctly, switch its power
OFF.
3. Conrm that your network is operating normally.
4. Using a CAT 5 Ethernet cable, connect the DPR-2000 Ethernet Port (labelled
LAN) to the network.
5. While the printer is turned OFF, connect the USB printer cable to the printer and
then to the USB port on the Print Server.
6. Switch on the printer.
7. Insert the power adapter’s output plug into the DC 5V power socket on the rear
panel of the Print Server.
8. Connect the other end of the power adapter into an AC power outlet. This will
supply power to the DPR-2000. The blue LED on the DPR-2000’s front panel
should turn ON and this Print Server’s self-test will proceed.
6
PS SOFTWARE INSTALLATION
PS Software (Windows Vista/XP/2003/2000) includes both PS-Link and PS-
Wizard. PSLink can help you set up your printer for multi-function printing using
your manufacturer’s drivers. PS-Wizard is a utility that enables you to easily add a
printer to your computer.
These utilities can also congure additional Print Server settings. Please refer to the
user’s manual for more information.
To install PS Software, insert the included installation CD into your computer’s CD-
ROM drive to initiate the auto-run program.
NOTE: If auto-run does not start you can access the CD-ROM contents in Windows
by clicking My Computer > [CD-ROM Drive Letter].
Installation
The content of the Installation CD-ROM includes:
• Install PS Software – click this to install the PS Software, which contains PS-Link
and PS-Wizard.
• View QIG – click this to see the Quick Installation Guide in PDF format for step-
by-step instructions of the print server Installation.
• View Manual – click this to see the User Manual in PDF format for more detailed
information regarding the print server.
• Adobe Reader – click this to install Acrobat Reader onto your computer. This
enables you to view the manual and Quick Installation Guide in PDF format.
• Exit – click to close the Auto-Run program.
7
PS SOFTWARE INSTALLATION
After clicking Install PS Software
the following screen will appear.
To change the default installation
location, click Browse.
In this screen you can change the
name of the installation folder. The
default name is PS Software.
Click Next
Click Next
Click Next
8
PS SOFTWARE INSTALLATION
To nish the installation of the PS
Software, click Finish.
To access the utilities, click Start >
Programs > PS Software and select
the utility you wish to use.
Click Finish
9
Technical Support
You can nd software updates and user documentation on the D-Link website.
Tech Support for customers in
Australia:
Tel: 1300-766-868
24/7(24Hrs, 7days a week) technical support
http://www.dlink.com.au
e-mail: [email protected]
India:
Customer Support: - 1800-233-0000 (MTNL & BSNL Toll Free) or
+91-832-2885700 (GSM, CDMS & Others)
Website: - www.dlink.co.in
Indonesia, Malaysia, Singapore and Thailand:
Tel: +62-21-5731610 (Indonesia)
Tel: 1800-882-880 (Malaysia)
Tel: +65 6501 4200 (Singapore)
Tel: +66-2-719-8978/9 (Thailand)
24/7, for English Support Only
http://www.dlink.com.sg/support/
e-mail: [email protected]
Korea:
Tel: +82-2-2028-1815
Monday to Friday 9:00am to 6:00pm
http://www.d-link.co.kr
e-mail: [email protected]
New Zealand:
Tel: 0800-900-900
24/7(24Hrs, 7days a week) technical support
http://www.dlink.co.nz
e-mail: [email protected]
10
Technical Support
You can nd software updates and user documentation on the D-Link website.
Tech Support for customers in
Egypt:
Tel: +202-2919035 or +202-2919047
Sunday to Thursday 9:00am to 5:00pm
http://support.dlink-me.com
Email: [email protected]
Iran:
Te: +98-21-88880918,19
Saturday to Thursday 9:00am to 5:00pm
http://support.dlink-me.com
Israel:
Magshimim 20, Petach Tikva 49348
Website: www.dlink.co.il
Main Tel: 972-3-9215173
Customer Support Tel: 972-3-9212886
Pakistan:
Tel: +92-21-4548158 or +92-21-4548310
Monday to Friday 10:00am to 6:00pm
http://support.dlink-me.com
E-mail: [email protected]
South Africa and Sub Sahara Region:
Tel: +27-12-665-2165
08600 DLINK (for South Africa only)
Monday to Friday 8:30am to 9:00pm South Africa Time
http://www.d-link.co.za
Turkey:
Tel: +90-212-2895659
Monday to Friday 9:00am to 6:00pm
http://www.dlink.com.tr
e-mail: [email protected]
e-mail: [email protected]
U.A.E and North Africa:
Tel: +971-4-4278127 (U.A.E)
Sunday to Thursday 9.00AM to 6.00PM GMT+4
Web: http://www.dlink-me.com
E-mail: [email protected]
Saudi ARABIA (KSA):
Telephone : +966 01 217 0008
Facsimile : +966 01 217 0009
e-mail: [email protected]
Saturday to Wednesday 9.30AM to 6.30PM
Thursdays 9.30AM to 2.00 PM
