D-Link DP-100+ Manuel utilisateur

Tableof Contents

DP-100+

Multi-protocol Ethernet

Print Server

User’s Manual

Rev. 01 (Nov, 2001)

Made In Taiwan

RECYCLABLE

Tableof Contents

0 TABLE OF CONTENTS

0ABOUT THIS GUIDE..................................................................V

1INTRODUCTION..........................................................................6

DP-100+ Print Server Features..................................................7

External Features.....................................................................8

Port Connectors......................................................................9

Network Cable Connectors .................................................... 10

DC Power Connector............................................................. 10

LED Indicators...................................................................... 10

Use of Stacking Brackets....................................................... 11

2UNPACKING AND INSTALLATION.........................................13

Unpacking and Inspecting the Print Server..............................13

Installing the DP-100+............................................................14

Power On Self-Test.................................................................15

Testing Your DP-100+.............................................................17

3PRODUCT SPECIFICATIONS ..................................................18

Printer Connection ..................................................................18

Network Connection................................................................18

Network Protocols...................................................................19

Tableof Contents

Management and Diagnostics.................................................19

Environmental and Physical ...................................................19

4PORT PINOUTS......................................................................21

Parallel Ports..........................................................................21

Serial Port...............................................................................22

5INDEX .....................................................................................23

About ThisGuide

1 ABOUT THIS GUIDE

This manual describes the DP-100+ Ethernet Multiprotocol

Print Server, including a description of the print server’s

features, as well as the print server installation procedures

and troubleshooting self-test results.

For information about software configuration of the DP-100+ to

allow it to be used with your network, consult the Print Server

Administration User’s Guide included with your DP-100+.

Introduction

2 INTRODUCTION

The DP-100+ Print Server is a compact print server which

connects to your Ethernet network anywhere you wish to

locate printer services. It manages the flow of print files from

your workstations or file servers to its connected printers,

delivering print jobs to high-performance printers much faster

than a file server or a PC acting as a print server can.

Figure 2 -1DP-100+ Print Server

DP-100+ Multiprotocol Ethernet Print Server User’s Guide

Introduction

DP-100+ Print Server Features

DP-100+ print servers improve network printing services in

three ways:

♦The DP-100+ picks up the workload of managing print file

traffic to its connected printers. This provides workload

relief to your file servers, and allows the file servers' full

capacity to be used for file access or other direct services

to network users. On peer-to-peer networks,

workstations can print directly to the DP-100+ without

increasing the load of another workstation or server.

♦The DP-100+'s parallel printer ports are IEEE 1284

compliant high-speed bidirectional ports, which can

transmit to high-speed laser printers much faster than a

PC's parallel printer port. High-speed laser printers

connected to the DP-100+'s parallel ports can be operated

at full their capacity.

♦Because the DP-100+ is very portable and inexpensive

compared to a PC-based print server, and because the

DP-100+ connects to your file-servers through the

network, printers can be deployed to locations of

maximum convenience to users.

The DP-100+ offers extraordinary flexibility, operating with all

major network operating systems and protocols:

♦TCP/IP

Introduction

Unix lpr/lpd (HP-UX, SunOS, Solaris, SCO, UnixWare, IBM

AIX)

Windows NT/2000/XP

LPR for Windows 95/98/Me

NetWare 5.x NDPS LPR remote printing

♦NetBEUI

Windows NT/2000, Windows 95/98/Me, Windows for

Workgroups, Microsoft LAN Manager, IBM LAN Server

♦AppleTalk

MacOS EtherTalk

Windows-based setup and administration software, PS Admin,

is supplied with the DP-100+, making configuration and

management quick and easy. The DP-100+ also supports

configuration and management via the telnet protocol for

networks without Windows-compatible machines.

External Features

This section describes the externally visible features of the

DP-100+ print server.

DP-100+ Multiprotocol Ethernet Print Server User’s Guide

Introduction

Port Connectors

The DP-100+’s three printer ports are located on its rear panel.

Two identical parallel ports are labeled LPT1 and LPT2; the

single serial port is labeled COM. These printer ports are

independently configurable using the PS Admin program or the

print server’s telnet interface. (See the Print Server

Administration User’s Guide for information about configuring

the print server’s ports.)

The print server also supports web configuration permitting

users to configure settings through the web browser. DP-100+

default IP address as follows:

♦Default IP address –192.168.0.10

♦Subnet Mask –255.255.255.0

Note:-

The PC’s IP address must correspond with the print server’s IP

address in the same segment for the two devices to

communicate.

Figure 2 -2Port Connectors

Introduction

Network Cable Connectors

The DP-100+ features two alternative network cable

connectors for either twisted-pair 10Base-Tcabling (using an

RJ-45 connector) or thin coaxial 10Base2 cabling (using a BNC

connector). Both of these network cable connectors are

located on the DP-100+’s right side panel.

DC Power Connector

The DC power input connector is located on the DP-100+’s

right side panel and is labeled DC 5V.

Figure 2 -3Print Server Right Side Panel

LED Indicators

The front panel of the DP-100+ features five LED indicators:

Figure 2 -4Front Panel LED Indicators

♦Power/Tx
