D-Link DWR-922 Manuel utilisateur

4G LTE ROUTER

DWR-922

QUICK

INSTALLATION

GUIDE

DWR-922

PACKAGE CONTENTS

CONTENTS

4G LTE ROUTER + PREINSTALLED SIM/UICC CARD

DWR-922

12V 1A POWER ADAPTER

ADAPTER

If any of these items are missing from your packaging contact

your reseller

CAT5 ETHERNET CABLE

2X 3G/4G BLADE ANTENNAS

DWR-922 3

PRODUCT

SETUP

BASIC SETUP

OPTIONAL ADVANCED SETUP (ACCESS VIA IP ADDRESS)

1. Once connected to your router, open a web browser and enter the IP address below into the

browser address eld. Log in using the username and password below.

IP ADDRESS: http://192.168.0.1

USERNAME: admin

PASSWORD: [leave this blank]

Ensure that your DWR-922 Mobile Router is powered off before performing the steps below.

1. Verify that your SIM/UICC card is installed and has been activated by your carrier.

2. Attach the included antennas to the back of the router, screwing them in clockwise.

Arrange them so that they point upward.

3. Connect the power adapter to the socket on the back panel of your DWR-922

Mobile Router. Plug the other end of the power adapter into a wall outlet or power strip. Make

sure the power button is in the "On" position

a. The Power LED will light up to indicate that power is being supplied to the router and the

router is turned on.

b. The LEDs on the front panel will ash on and off as the DWR-922 Mobile Router performs

initialization and Internet connection processes.

c. After a few moments, if a connection has been established, the following LEDs will turn solid

green: Power, Signal Strength, WLAN, LAN (if connected), and either 2G/3G or 4G.

Note: By default, the DWR-922 uses the mobile network as the sole Internet connection. If you

wish to use your mobile connection as a backup to a wired connection, or you wish to use a

wired connection exclusively, you must use the Optional Advanced Setup procedure.

4. Connect via Wi-Fi using the SSID and password printed on the bottom of the router, or through

Ethernet via one of the LAN ports on the back of your DWR-922.

SIM card

2. After logging in, you can access the setup wizard which will guide you through the rest of the

setup process. To reach the wizard, click the Internet tab on the bar along the top, then click

Wizard on the left hand side. Follow the on-screen instructions.

For additional information, see the user manual.

DWR-922

TROUBLESHOOTING

SETUP AND CONFIGURATION PROBLEMS

1. HOW DO I CONFIGURE MY DWR-922 ROUTER OR CHECK MY WIRELESS NETWORK

NAME (SSID) AND WIRELESS ENCRYPTION KEY?

- Connect your PC to the router using an Ethernet cable.

- Open a web browser and enter the router's IP address: http://192.168.0.1 into the address bar.

- Log into the router using the default username admin. By default, the password is left blank.

- Once logged in, you can use the wizard to congure the router, or make changes manually.

Note: If you have changed the password and cannot remember it, you will need to reset the

router to factory defaults. The default SSID and password are printed on the bottom of your

router.

2. HOW DO I RESET MY DWR-922 ROUTER TO FACTORY DEFAULT SETTINGS?

- If you cannot remember your router administrator password, you may use an implement such as

a straightened paperclip to press and hold the reset button on the front of the router for about

10 seconds.

Note: Resetting the router to factory default settings will erase the current conguration. To

recongure your router, log in as outlined in question 1, then run the Setup Wizard.

3. HOW DO I ADD A NEW WIRELESS CLIENT OR PC IF I HAVE FORGOTTEN MY

WIRELESS NETWORK NAME (SSID) OR WIRELESS ENCRYPTION KEY?

- For every PC that needs to connect to the router wirelessly, you will need to ensure you use the

correct Wireless Network Name (SSID) and encryption key.

- Use the web-based user interface (as described in question 1 above) to check or choose your

wireless settings.

- Make sure you write down the SSID and password so that you can enter them into each

wirelessly connected PC. You will nd a dedicated area on the back of this document to record

this important information for future use.

4. WHY AM I UNABLE TO ESTABLISH AN INTERNET CONNECTION?

- If connecting using a 4G mobile connection, make sure that you are within range of the mobile

service provider, and that the service has been correctly congured.

- If connecting using the WAN via ADSL/Cable service, make sure the modem has been enabled,

connected, and is operational, and that the service is correctly congured.

Note: For the product manual, please visit http://support.dlink.com/

DWR-922 5

NOTES

DWR-922

NOTES

DWR-922 7

NOTES

DWR-922

Technical Support

This guide is for rst time conguration. Please refer to the user manual to learn more.

U.S. and Canadian customers can contact D-Link Technical Support through our website.

USA

http://support.dlink.com/DAP-1860

Canada

http://support.dlink.ca/DAP-1860

Version 1.00(USCC)_130X183

September 14, 2016

trademarks of D-Link Corporation or its subsidiaries. All other third-party marks mentioned

herein may be trademarks of their respective owners. This publication may not be

reproduced, in whole or in part, without prior express written permission from D-Link

Systems, Inc.
