D-Link Amplifi DIR-657 Manuel utilisateur

What it does

Stream music, videos and High Denition media to multiple

devices, at the same time, with this HD Media Router.

Experience high quality video on your TV screen and lag free

gaming via the built-in Quality of Service feature. Wireless N

technology included in the router, gives you the very best in

speed and coverage around your home.

Share ﬁles and stream your

multimedia

The DLNA ready Media Server built-in allows you to stream

media content directly onto game consoles and media players

like the Boxee Box by D-Link. Accessing or sharing photos,

music and videos is made easy via the SD card slot.1 You can

even eortlessly share any USB device (like a printer or hard

drive) courtesy of D-Link’s SharePort™ Plus technology.

HD Media Router

DIR-657

Flawless wireless HD video

streaming, gaming & Internet calls

Exceptional speed and coverage

with Wireless N

Access and share media

via the SD card slot

Technical Specications

STANDARDS

- IEEE 802.11n

- IEEE 802.11g

- IEEE 802.11b

- IEEE 802.3

- IEEE 802.3u

- IEEE 802.3ab

- USB 2.0

DEVICE INTERFACES

- Four 10/100/1000 Gigabit LAN ports

- Gigabit Internet/WAN port

- USB 2.0 port

- Built-in 802.11n wireless LAN

WIRELESS DATA RATE

- Up to 300 Mbps in wireless N mode 2

WIRELESS LAN SECURITY

- WPA and WPA2 (Wi-Fi Protected Access)

- WEP 64/128-bit

ADVANCED FIREWALL FEATURES

- Network Address Translation (NAT)

- Stateful Packet Inspection (SPI)

- VPN Pass-through/Multi-session PPTP/

L2TP/IPSec

QoS

- WMM for WLAN trac

- QoS engine for prioritizing trac

SHAREPORT™ PLUS FUNCTION

SUPPORT 3

- Allows for connection of an external

hard drive, ash memory drive, or a

multifunction printer to the USB port

- Allows sharing of hard drives, printing and

scanning functions

LEDS

- Power

- Internet

SYSTEM REQUIREMENTS

- Windows 7/Vista/XP SP3 or higher 4

- Internet Explorer 6 or higher, Mozilla

Firefox 2.0 or higher, or other Java-

enabled browser

DEVICE MANAGEMENT

- UPnP support

- DDNS support

- Integrated Wireless Security Wizard and

Wireless Protected Setup (WPS) support

- Windows Connect Now (WCN) support

- Web-based management using Internet

Explorer 6 or higher; Mozilla Firefox 2.0 or

higher; or other Java-enabled browser

- Online rmware update check

- E-mail notications for triggered events

- UPnP™ AV Server for streaming media to

compatible media players 5

- Scheduled downloads

- Multi-language le name support

- D-Link Network Monitor Yahoo! Widget

- D-Link Internet Usage Meter Yahoo!

Widget

Features

+ IEEE 802.11n and 802.11g compliant

+ Gigabit Ethernet

+ Dual active rewalls – Stateful Packet Inspection

(SPI) and Network Address Translation (NAT)

+ Enhanced security with WPA2-PSK

+ Includes Advanced Encryption Standard (AES)

+ D-Link Intelligent QoS technology for

enhancing Internet access and performance

+ Advanced parental controls

+ Supports UPnP, LLTD, DDNS and WPS PBC and

+ SharePort™ Plus technology

+ Built-in DLNA ready Media Server

+ SD Card slot

+ IPv6 ready

+ D-Link Green technology

Think Green

While this may look like your average router,

it’s not. This is a D-Link Green™ router, which

is as good for your wallet as it is for the

environment. The DIR-657 is designed to

conserve energy, protect our environment

from harmful substances and reduce waste

by using recyclable packaging. To learn

more, visit www.dlinkgreen.com

D-Link Green™ Technology

+ Power saving by link status

+ Power saving by cable length

+ Power saving by wireless LAN scheduling

DIR-657

Technical Specications (cont.)

DIMENSIONS L x W x H

- 212 x 159.93 x 32.3 mm (8.4 x 6.3 x 1.2 in)

WEIGHT

- 331.5 g (0.73 lb)

OPERATING TEMPERATURE

- 0 to 40 °C (32 to 104 °C)

OPERATING HUMIDITY

- 10% to 90% (non-condensing)

CERTIFICATIONS

- FCC Class B

- IC

- CE

- UL

- LVD

- RoHS compliant

- Wi-Fi Certied

- Wi-Fi Protected Setup (WPS)

- Windows 7 Certied

- IPv6 Ready

Package Contents

+ DIR-657 Wireless N HD Media Router

+ Easy install CD and manual

+ Quick install guide and warranty documents

+ Power adapter 12V DC / 2A

+ Ethernet cable – CAT5

System Requirements

+ Cable or ADSL Internet service

+ Cable or DSL Modem with Ethernet port

+ Microsoft Internet Explorer 6 or higher, or

FireFox 1.5 or higher

+ Network interface card

+ CD ROM drive

Optional Products

Combine the Wireless N HD Media Router

with these D-Link products for a complete

solution:

+DSM-380: The Boxee Box by D-Link

Unleash the Internet on your HD TV

+DWA-160: Wireless USB Adapter

Add a wireless connection to your computer via

USB adapter

+DNS-325: Network Storage

Add storage to your network & back up les

1 SD Card not included.

2 Maximum wireless signal rate derived from IEEE Standard 802.11 speciﬁcations. Actual data throughput will vary. Network conditions and environmental factors, including volume of network trafﬁc, building materials and construction, and

network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. Wireless range and speed rates are D-Link RELATIVE performance measurements based on the wireless range and speed

rates of a standard Wireless G product from D-Link. Maximum throughput based on D-Link’s 802.11n devices

3 Software included is not Mac-compatible.

4 Computer must adhere to Microsoft’s recommended system requirements.

5 D-Link does not guarantee full compatibility or proper playback with all codecs. Playback capability depends on the codec support of the UPnP AV media player.

DIR-657
