D-Link DSL-2750U Manuel utilisateur

Quick Installation Guide

DSL-2750U

Wireless ADSL2+ Router with

3G/LTE/Ethernet WAN Su ort

and USB Port

DSL-2750U Quick Installation Guide

BEFORE YOU BEGI

Delivery Package

•Router DSL-2750U

•Power adapter DC 12V/1A

•RJ-11 telephone ca le

•Ethernet ca le (CAT 5E)

•Splitter

•“Quick Installation Guide” ( rochure).

If any of the items are missing, please contact your reseller.

The “User Manual” and “Quick Installation Guide” documents are availa le

on D-Link we site (see www.dlink.ru).

!Using a power supply with a different voltage rating than the one

included will cause damage and void the warranty for this product.

Default Settings

IP address of wireless router 192.168.1.1

Username (login) admin

Password admin

ame of wireless network (SSID) DSL-2750U

etwork key (PSK)

see WPS PIN on the

arcode la el on the

ottom panel of the

device

DSL-2750U Quick Installation Guide

System Requirements and Equipment

•A computer with any operating system that supports a we rowser.

•A we rowser to access the we - ased interface of the router:

◦Apple Safari 5 and later

◦Google Chrome 5 and later

◦Microsoft Internet Explorer 8 and later

◦Mozilla Firefox 5 and later

◦Opera 10 and later.

•A NIC (Ethernet or Wi-Fi adapter) to connect to the router.

•An 802.11 , g, or n Wi-Fi adapter to create a wireless network.

•A USB modem to connect to the Internet1.

Your USB modem should e equipped with an active identification

card (SIM or R-UIM) of your operator.

Some operators require su scri ers to activate their USB modems prior

to using them. Please, refer to connection guidelines provided y your

operator when concluding the agreement or placed on its we site.

For LTE and CDMA USB modems, it is required to disa le the PIN

code check on the identification card prior to connecting the USB

modem to the router.

1 Contact your operator to get information on the service coverage and fees.

DSL-2750U Quick Installation Guide

Supported USB Modems

GSM modems

•Alcatel X500

•D-Link DWM-152C1

•D-Link DWM-156A6

•D-Link DWM-156A7

•D-Link DWM-156C1

•D-Link DWM-157B1

•D-Link DWM-157B1 (Velcom)

•D-Link DWM-158D1

•Huawei E150

•Huawei E1550

•Huawei E156G

•Huawei E160G

•Huawei E169G

•Huawei E171

•Huawei E173 (Megafon)

•Huawei E220

•Huawei E352 (Megafon)

•Huawei E367 (3G mode)

•Huawei E392 (3G mode)

•ZTE MF112

•ZTE MF192

•ZTE MF626

•ZTE MF627

•ZTE MF652

•ZTE MF667

•ZTE MF668

•ZTE MF752

DSL-2750U Quick Installation Guide

CDMA modems2

•Airplus MCD-650

•Airplus MCD-800

•AnyDATA ADU-300A

•AnyDATA ADU-500A

•AnyDATA ADU-510A

•Huawei EC306

•ZTE AC5710

•ZTE AC5730

L E modems

•Huawei E3131

•Huawei E3272

•Huawei E367

•Huawei E392

•Megafon M100-1

•Megafon M100-3

•Megafon M100-4

•Megafon M150-1

•MTS 824F

•Yota LU-150

•Yota WLTUBA-107

•ZTE MF823

•ZTE MF827

!The manufacturer does not guarantee proper operation of the router

with every modification of the firmware of USB modems.

2 Performance of CDMA USB modems is not tested for the current firmware version.

DSL-2750U Quick Installation Guide

CO ECTI G TO PC

PC wit Et ernet Adapter

1. Make sure that your PC is powered off.

2. Connect an Ethernet ca le etween any of four Ethernet ports located on

the ack panel of the router and the Ethernet port of your PC.

3. To connect via USB modem: connect your USB modem to the USB port3

located on the left side panel of the router.

!If you need to connect or change a USB modem to another one when

the router is powered on, power off the router, connect the modem to

the USB port, and power on the router.

4. To connect the router to a DSL line: connect a phone ca le etween the

DSL port of the router and the ADSL OU port of the splitter. Connect

your phone to the PHONE port of the splitter. Then connect another

phone ca le etween a phone jack and the ADSL IN port of the splitter.

5. To connect the router to an Ethernet line: in the we - ased interface of

the router, select the router's LAN port that will e used as the WAN port

and create an Ethernet WAN connection. Then connect the Ethernet ca le

etween the selected Ethernet port located on the ack panel of the router

and the Ethernet line.

6. Connect the power cord to the power connector port on the ack panel of

the router, then plug the power adapter into an electrical outlet or power

strip.

7. Turn on the router y pressing the ON/OFF utton on its ack panel.

8. Turn on your PC and wait until your operating system is completely

loaded.

Now you should configure your PC to o tain an IP address automatically (as

DHCP client).

3 It is recommended to use a USB extension ca le to connect a USB modem to the

router.

DSL-2750U Quick Installation Guide

Obtaining IP Address Automatically

in OS Windows XP

1. Click the Start utton and proceed to the Control Panel > etwork

and Internet Connections > etwork Connections window.

2. In the etwork Connections window, right-click the relevant Local

Area Connection icon and select the Properties line in the menu

displayed.

3. In the Local Area Connection Properties window, on the General

ta , select the Internet Protocol (TCP/IP) line. Click the Properties

utton.

DSL-2750U Quick Installation Guide

4. Select the Obtain an IP address automatically and Obtain D S

server address automatically radio uttons. Click the OK utton.

5. Click the ОК utton in the connection properties window.

Now your computer is configured to o tain an IP address automatically.

DSL-2750U Quick Installation Guide

Obtaining IP Address Automatically

in OS Windows 7

1. Click the Start utton and proceed to the Control Panel window.

2. Select the etwork and Sharing Center section. (If the Control Panel

has the category view (the Category value is selected from the View by

drop-down list in the top right corner of the window), choose the View

network status and tasks line under the etwork and Internet

section.)

3. In the menu located on the left part of the window, select the Change

adapter settings line.

4. In the opened window, right-click the relevant Local Area Connection

icon and select the Properties line in the menu displayed.

5. In the Local Area Connection Properties window, on the

etworking ta , select the Internet Protocol Version 4 (TCP/IPv4)

line. Click the Properties utton.

DSL-2750U Quick Installation Guide

6. Select the Obtain an IP address automatically and Obtain D S

server address automatically radio uttons. Click the OK utton.

7. Click the OK utton in the connection properties window.

Now your computer is configured to o tain an IP address automatically.
