D-Link DSL-2520U Manuel utilisateur

Quick Installation Guide

DSL-2520U

ADSL2/2+ Router with USB and Ethernet Ports

DSL-2520U Quick Installation Guide

BEFORE YOU BEGIN

Delivery Package

•Router DSL-2520U

•Power adapter DC 5V/1A

•RJ-11 telephone cable

•Stra ght-through Ethernet cable (CAT 5E)

•USB cable

•Spl tter

•CD-ROM w th “User Manual” and “Quick Installation Guide”

•“Quick Installation Guide” (brochure).

If any of the tems are m ss ng, please contact your reseller.

!Using a power supply with a different voltage rating than the one

included will cause damage and void the warranty for this product.

Default Settings

I address of router 192.168.1.1

Username (login) admin

assword admin

System Requirements and Equipment

•A computer w th any operat ng system that supports a web browser.

•A web browser to access the web-based nterface of the router: W ndows

Internet Explorer, Moz lla F refox, or Opera.

•A NIC (Ethernet adapter) to connect to the router.

DSL-2520U Quick Installation Guide

CONNECTING TO C (OS WINDOWS X )

PC with Ethernet Adapter

1. Make sure that your PC s powered off.

2. Connect an Ethernet cable between the Ethernet port located on the back

panel of the router and the Ethernet port of your PC.

3. Connect a phone cable between the DSL port of the router and the ADSL

OUT port of the spl tter. Connect your phone to the PHO E port of the

spl tter. Then connect another phone cable between a phone jack and the

ADSL I port of the spl tter.

4. Connect the power cord to the power connector port on the back panel of

the router, then plug the power adapter nto an electr cal outlet or power

str p.

5. Turn on your PC and wa t unt l your operat ng system s completely

loaded.

DSL-2520U Quick Installation Guide

PC with USB P rt

!Do not connect your router to your PC unt l the USB dr ver s nstalled.

1. Turn on your computer and wa t unt l the operat ng system s completely

loaded. Insert the CD from the router's del very package nto the CD

ROM dr ve. Open the d sk and go to the USBDriver folder, then run the

setup.exe f le. Wa t unt l the USB dr ver s nstalled. When the

nstallat on s completed, cl ck the Finish button.

2. Connect a phone cable between the DSL port of the router and the ADSL

OUT port of the spl tter. Connect your phone to the PHO E port of the

spl tter. Then connect another phone cable between a phone jack and the

ADSL I port of the spl tter.

3. Connect the power cord to the power connector port on the back panel of

the router, then plug the power adapter nto an electr cal outlet or power

str p.

4. Connect the USB cable between the USB port located on the back panel

of the router and the USB port of your PC.

DSL-2520U Quick Installation Guide

Now you should conf gure your PC to obta n an IP address automat cally (as

DHCP cl ent).

1. Cl ck the Start button and proceed to the Control anel > Network

and Internet Connections > Network Connections w ndow.

2. In the Network Connections w ndow, r ght-cl ck the relevant Local

Area Connection con and select the roperties l ne n the menu

d splayed.

3. In the Local Area Connection roperties w ndow, on the General

tab, n the This connection uses the following items sect on, select

the Internet rotocol (TC /I ) l ne. Cl ck the roperties button.

DSL-2520U Quick Installation Guide

4. Select the Obtain an I address automatically rad o button. Cl ck

the OK button.

Cl ck the ОК button. Now your computer s conf gured to obta n an IP address

automat cally.

DSL-2520U Quick Installation Guide

CONFIGURING ROUTER

C nnecting t Web-based Interface

1. Start a web browser.

2. In the address bar of the web browser, enter the IP address of the router

(by default, the follow ng IP address s spec f ed: 192.168.1.1). Press

the Enter key.

3. On the opened page, enter the username (log n) and password for the

adm n strator account (by default, the follow ng username and password

are spec f ed: admin, admin). Then cl ck the Enter button.

If the error “ The page cannot be displayed ” (or “ Unable to display the

page ”/“ Could not connect to remote server ”) occurs upon connect ng to

the web-based nterface of the router, make sure that you have properly

connected the router to your computer.

After successful reg strat on the system stat st cs page opens. The page

d splays general nformat on on the router and ts software.

It s strongly recommended to change the adm n strator password upon

n t al conf gurat on of the router. To do th s, go to the System /

Administrator password page.

DSL-2520U Quick Installation Guide

The web-based nterface of the router s mult l ngual. Select a needed language

from the menu d splayed when the mouse po nter s over the Language

capt on. You can change the language of the web-based nterface n any menu

tem.

C nfiguring C nnecti n t the Internet

You should conf gure your WAN connect on n accordance w th data

prov ded by your Internet serv ce prov der (ISP). Make sure that you

have obta ned all necessary nformat on pr or to conf gur ng your WAN

connect on. Otherw se contact your ISP.

1. Go to the Net / Connections page and cl ck the Add button.

2. In the General settings sect on, spec fy a name for your connect on

(any name for eas er dent f cat on) n the Name f eld and select a type

for your connect on from the Connection Type drop-down l st.

DSL-2520U Quick Installation Guide

3. In the hysical layer sect on, spec fy the VPI and VCI n the relevant

f elds, and then select a method of encapsulat on from the

Encapsulation Mode drop-down l st.

4. For the I oE and I oA connect on types, f ll n the I Address,

Netmask, and Gateway I Address f elds n the I settings sect on.

For the I oE type, you can spec fy automat c ass gnment of these

parameters (to do th s, select the Obtain an I address

automatically checkbox).

DSL-2520U Quick Installation Guide

5. For the oE and oA connect on types, enter author zat on data

prov ded by your ISP n the Settings sect on (the username (log n)

n the Username f eld and the password n the assword and

assword confirmation f elds). If these data have not been prov ded

by your ISP, select the Without authorization checkbox.

6. Deselect the NAT checkbox n the Miscellaneous sect on f your ISP

requ res you to d sable the network address translat on funct on.

7. Cl ck the Save button.
