D-Link DSL-2740U Manuel utilisateur

Quick Installation Guide

DSL-2740U

Wireless N ADSL2+ Modem Router

DSL-2740U Quick Installation Guide

BEFORE YOU BEGI

Delivery Package

•Router DSL-2740U

•Power adapter DC 12V/0.5A

•RJ-11 telepho e cable

•Ether et cable (CAT 5E)

•Splitter

•“Quick Installation Guide” (brochure).

If a y of the items are missi g, please co tact your reseller.

The “User Manual” a d “Quick Installation Guide” docume ts i Russia

a d E glish are available o D-Li k website (see ftp.dli k.ru/pub/ADSL/DSL-

2740U_B1A_T1A/Descriptio /).

!Using a power supply with a different voltage rating than the one

included will cause damage and void the warranty for this product.

Default Settings

IP address of router 192.168.1.1

Username (login) admin

Password admin

ame of wireless network (SSID) DSL-2740U

DSL-2740U Quick Installation Guide

System Requirements and Equipment

•A computer with a y operati g system that supports a web browser.

•A web browser to access the web-based i terface of the router:

◦Apple Safari 5 a d later

◦Google Chrome 5 a d later

◦Microsoft I ter et Explorer 7 a d later

◦Mozilla Firefox 5 a d later

◦Opera 10 a d later.

•A NIC (Ether et or Wi-Fi adapter) to co ect to the router.

•A 802.11b, g, or Wi-Fi adapter to create a wireless etwork.

DSL-2740U Quick Installation Guide

CO ECTI G TO PC

PC with Ethernet Adapter

1. Make sure that your PC is powered off.

2. Co ect a Ether et cable betwee a y of four Ether et ports located o

the back pa el of the router a d the Ether et port of your PC.

3. To connect the router to a DSL line: co ect a pho e cable betwee the

DSL port of the router a d the ADSL OUT port of the splitter. Co ect

your pho e to the PHO E port of the splitter. The co ect a other

pho e cable betwee a pho e jack a d the ADSL I port of the splitter.

4. To connect the router to an Ethernet line: co ect the Ether et cable

betwee a y of four Ether et ports located o the back pa el of the router

a d the Ether et li e.

5. Co ect the power cord to the power co ector port o the back pa el of

the router, the plug the power adapter i to a electrical outlet or power

strip.

6. Tur o the router by pressi g the O /OFF butto o its back pa el.

7. Tur o your PC a d wait u til your operati g system is completely

loaded.

Now you should co figure your PC to obtai a IP address automatically (as

DHCP clie t).

DSL-2740U Quick Installation Guide

Obtaining P Address Automatically

in OS Windows XP

1. Click the Start butto a d proceed to the Control Panel > etwork

and Internet Connections > etwork Connections wi dow.

2. I the etwork Connections wi dow, right-click the releva t Local

Area Connection ico a d select the Properties li e i the me u

displayed.

3. I the Local Area Connection Properties wi dow, o the General

tab, select the Internet Protocol (TCP/IP) li e. Click the Properties

butto .

DSL-2740U Quick Installation Guide

4. Select the Obtain an IP address automatically a d Obtain D S

server address automatically radio butto s. Click the OK butto .

5. Click the ОК butto i the co ectio properties wi dow.

Now your computer is co figured to obtai a IP address automatically.

DSL-2740U Quick Installation Guide

Obtaining P Address Automatically

in OS Windows 7

1. Click the Start butto a d proceed to the Control Panel wi dow.

2. Select the etwork and Sharing Center sectio . (If the Co trol Pa el

has the category view (the Category value is selected from the View by

drop-dow list i the top right cor er of the wi dow), choose the View

network status and tasks li e u der the etwork and Internet

sectio .)

3. I the me u located o the left part of the wi dow, select the Change

adapter settings li e.

4. I the ope ed wi dow, right-click the releva t Local Area Connection

ico a d select the Properties li e i the me u displayed.

5. I the Local Area Connection Properties wi dow, o the

etworking tab, select the Internet Protocol Version 4 (TCP/IPv4)

li e. Click the Properties butto .

DSL-2740U Quick Installation Guide

6. Select the Obtain an IP address automatically a d Obtain D S

server address automatically radio butto s. Click the OK butto .

7. Click the OK butto i the co ectio properties wi dow.

Now your computer is co figured to obtai a IP address automatically.

DSL-2740U Quick Installation Guide

PC with Wi-Fi Adapter

1. To connect the router to a DSL line: co ect a pho e cable betwee the

DSL port of the router a d the ADSL OUT port of the splitter. Co ect

your pho e to the PHO E port of the splitter. The co ect a other

pho e cable betwee a pho e jack a d the ADSL I port of the splitter.

2. To connect the router to an Ethernet line: co ect the Ether et cable

betwee a y of four Ether et ports located o the back pa el of the router

a d the Ether et li e.

3. Co ect the power cord to the power co ector port o the back pa el of

the router, the plug the power adapter i to a electrical outlet or power

strip.

4. Tur o the router by pressi g the O /OFF butto o its back pa el.

5. Tur o your PC a d wait u til your operati g system is completely

loaded.

6. Tur o your Wi-Fi adapter. As a rule, moder otebooks with built-i

wireless NICs are equipped with a butto or switch that tur s o /off the

wireless adapter (refer to your PC docume ts). If your PC is equipped

with a pluggable wireless NIC, i stall the software provided with your

Wi-Fi adapter.

Now you should co figure your Wi-Fi adapter.

DSL-2740U Quick Installation Guide

Configuring Wi-Fi Adapter in OS Windows XP

1. Click the Start butto a d proceed to the Control Panel > etwork

and Internet Connections > etwork Connections wi dow.

2. Select the ico of the wireless etwork co ectio a d make sure that

your Wi-Fi adapter is o .

3. Search for available wireless etworks.

4. I the ope ed Wireless etwork Connection wi dow, select the

wireless etwork DSL-2740U a d click the Connect butto .

After that the Wireless etwork Connection Status wi dow appears.

If you perform i itial co figuratio of the router via Wi-Fi co ectio ,

ote that immediately after cha gi g the wireless default setti gs of the

router you will eed to reco figure the wireless co ectio usi g the

ewly specified setti gs.
