CYP CDPS-U10H2HFS Manuel utilisateur

DRAFT

CDPS-U10H2HFS

10 By 2 HDMI Matrix Fast Switch

Operation Manual

DRAFT

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means

- electronic, mechanical, magnetic, optical, chemical, manual,

or otherwise - without express written permission and consent from

Cypress Technology.

Version 1.0 November 2014

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

DRAFT

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack or install or

operate this equipment, and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through

module openings or empty slots, as you may damage parts.

• Do not attach the power supply cabling to building surfaces.

• Do not allow anything to rest on the power cabling or allow it to

be abused by persons walking on it.

• To protect the equipment from overheating, do not block the slots

and openings in the module housing that provide ventilation.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

RDV1 05/11/14 Preliminary Release

RDV2 09/12/14 Add Power Supply

RDV3 17/12/14 Add IR Frequency

DRAFT

CONTENTS

1. Introduction............................................1

2. Applications...........................................1

3. Package Contents ................................1

4. System Requirements............................1

5. Features..................................................2

6. Operation Controls and Functions.......3

6.1 Front Panel........................................3

6.2 Rear Panel.........................................5

6.3 Remote Control................................6

6.4 OSD Menu.........................................8

6.5 RS-232 Protocols .............................13

6.6 IR Pin Denitions..............................14

6.7 Telnet & RS-232 Commands..........14

6.8 Telnet Control.................................17

6.9 Web GUI Control............................18

8. Specications ......................................23

9. Acronyms.............................................25

DRAFT

1. INTRODUCTION

This 10 by 2 HDMI UHD Matrix is an advanced solution for switching up

to 10 HDMI inputs to two HDMI outputs. It provides high performance

pass-through of video/audio and is capable of receiving and

transmitting 340MHz/10.2Gbps bandwidth rate with no data loss.

It’s Fast Switching technology can greatly reduce the time required

to swap between inputs. Supporting the latest features you can be

assured of reliable and high quality HDMI distribution.

2. APPLICATIONS

• Showroom display & control

• Educational demo

• Installation usage

• Advertising display

3. PACKAGE CONTENTS

• 10 By 2 HDMI Matrix Fast Switch

• 1 x IR Extender

• 1 x Remote Control

• 1 x 5V/2.6A Power Adaptor

• Operational Manual

4. SYSTEM REQUIREMENTS

Input source equipment such as DVD/Blu-ray player and output HD

display/Monitor with HDMI cables.

DRAFT

5. FEATURES

• Supports UHD resolutions up to 4K2K@24/25/30Hz & 4K2K

YUV420@60Hz

• Supports HDTV resolutions up to 1080@60Hz, ‘Deep Color’ 36/30/24-

bit and PC resolutions up to WUXGA@60Hz(RB)

• Supports 3D

• Supports pass-through of audio formats: LPCM 2/5.1/7.1CH, Dolby

Digital 2~5.1CH, DTS 2~5.1CH, Dolby Digital Plus, Dolby TrueHD and

DTS-HD Master Audio

• Supports EDID selection function

• Supports control via IR, RS-232, Telnet and Web GUI controls

• Input port HDCP support Standard and Apple mode. The Apple

mode selection to guarantees the use of Apple devices.

• Compliant with DVI source

Note: Supporting HDMI to DVI conversion that HDMI sources is non-

deep color and color space RGB.

Not supporting HDMI to DVI conversion when that HDMI

source is deep color and color space YCbCr 444/422

DRAFT

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

POWER

10X2 HDMI MATRIX FAST SWITCH

IN 6 IN 7IN 8IN 9IN 10 OUT BTAKE

IN 1 IN 2IN 3IN 4IN 5OUTACANCEL

ENTER

PRESET

ALL

MUTE

LOCK

4K UHD

10 1554321

1POWER Button

Press this button to switch On or set the device to standby mode.

2POWER LED

This LED will illuminate in green when the device is power On and if

it is switched to standby mode the LED will turn red.

3IR Window

This IR Receiver receives the remote control signal from the

package included remote control only.

4IN 1~10

Press these IN buttons to select an input from the 10 input sources.

5OUT A/B

Press these buttons once a time along with an IN buttons to select

an input source for an output display. i.e. OUTA → IN1 → TAKE or

OUTB → IN10 → TAKE.

6CANCLE

Press this button to cancel the IN/OUT selection and during any

selection under MENU.

7TAKE

Press this button to conrm the selection of an IN and an OUT

button. If this button is not pressed the IN & OUT selection will not

be executed.

8MENU

Press to enter into the menu selection.

DRAFT

9ENTER

Press to conrm the selection.

10 +/-

Press these buttons to move up/down under menu selection.

11 PRESET

Press this button to recall the preset setting from 1~10. Press and

select from IN1~10 then press TAKE to conrm the recall selection or

press CANCEL to exit the selection. To reset the Preset setting, enter

into menu and select Preset setting from IN1~10 then press OUTA

and select an input from IN1~10 then press OUTB and select an

input from IN1~10 again and press ENTER to conrm the selection.

eg. To preset 2’s gure, MENU → ENTER → Matrix Preset → Enter→

Preset2 → IN2 → OUTA → IN8 → OUTB → IN7 → ENTER

12 ALL

Press this button to select all outputs to display with an input

source. e.g. To select all output with input source 3. ALL → IN3

13 MUTE

Press this button to mute video and audio on OUT A or B or on all

output. e.g. To mute output A OUTA → MUTE

14 LOCK

Press this button to lock all button functions on the panel to unlock,

press the button and hold for 3 seconds.

15 LCM

Displaying Input and Outputs selection and menu selection.

DRAFT

6.2 Rear Panel

CONTROLSERV.

HDMI IN HDMI OUT

12345678910ABRS232 IR IN DC 5V

7654321

1HDMI IN

Connect from source equipment such as Blu-ray/DVD/PS3 players,

Set-Top-Box or any HDMI equipped source device for input signal

sending.

2HDMI OUT

Connect to HDMI TV/display or HD Amplier for output image and

or audio display.

3SERV.

This slot is reserved for rmware update use only.

4CONTROL

Connect from PC/Laptop with active internet service for Telnet or

Web GUI control with RJ-45 terminated cable.

5RS-232

Connect from PC/Laptop for RS-232 command sending to control

the device.

6IR IN

Connect the IR Receiver included in the package for IR signal

receive from the included remote control.

7DC 5V

Connect the adaptor included in the package and connect to

AC wall outlet for power supply.

DRAFT

6.3 Remote Control

1POWER

Press this button to switch On or

set the device to standby mode.

2MUTE

Press this button to mute video

and audio on OUT A or B or on

all output. e.g. To mute output A

OUTA → MUTE

3OUT A/B

Press these buttons once a time

along with an IN buttons to select

an input source for an output

display. i.e. OUTA → IN1 → TAKE or

OUTB → IN10 → TAKE.

4IN 1~10

Press these IN buttons to select an

input from the 10 input sources.

5+/-

Press these buttons to move up/

down under menu selection.

6OK

Press to conrm the selection.

7CANCEL

Press this button to cancel the IN/OUT selection and during any

selection under MENU.

8MENU

Press to enter into the menu selection.

9TAKE

Press this button to conrm the selection of an IN and an OUT

button. If this button is not pressed the IN & OUT selection will not

be executed.

OUT

POWER MUTE

CANCEL MENU

TAKE PRESET

LOCK ALL

CR-151

234

567

8910
