CYP CMSI-8H8HS Manuel utilisateur
CMSI-8H8HS
8×8 HDMI Matrix
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 11/11/11 Preliminary Release
RDV2 13/12/11 Power Supply Change
RDV3 15/02/12 LAN Function
VS0 29/03/12 Updated format, diagrams, and
statements
RDV4 04/07/12 Control's Function
VS0 24/07/12 Telnet and Web GUI sections
updated
RDV5 04/10/12 Add Web GUI page
VS0 14/06/13 Updated screenshots.
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 Side Panel .........................................5
6.4 Remote Control................................5
6.5 RS-232 Pin Assignment .....................6
6.6 RS-232 and Telnet Commands .......7
6.7 Telnet Control ...................................8
6.8 Web GUI Control ............................10
7. Connection Diagram .......................... 11
8. Specications ...................................... 12
9. Acronyms ............................................. 13
1
1. INTRODUCTION
The 8×8 HDMI Matrix supports the transmission of video signal (up to
1080p Full HD/1920×1200@60 Hz) with multichannel digital audio from
up to eight high denition sources to up to eight HDMI outputs, and
allowing any source to be independently displayed on any monitor.
Also, the unit can be controlled via IR, RS-232, Telnet, Web GUI or the
front panel buttons.
2. APPLICATIONS
• Video/TV wall display
• Commercial advertising and display
• Lecture room display and control
• Hyper market demonstration and control
3. PACKAGE CONTENTS
• 8×8 HDMI Matrix
• 1×24 V/6.25 A DC Adaptor
• 1×Remote Control
• 1xIR Extender
• Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI equipped input source devices with HDMI cables
• HDMI equipped output displays (TVs or monitors) or HDMI equipped
AV receivers with HDMI cables
2
5. FEATURES
• HDMI, HDCP 1.1 and DVI compliant
• Supports HDMI features including 3D
• Supports audio sampling rate up to 192 kHz
• Supports resolutions VGA~WUXGA and 480i~1080p dependent upon
the output display’s EDID settings
• Supports 3D signal display dependent upon the output display's
EDID settings
• Supports HDMI input up to 15 meters at 8-bit resolution or 10 meters
at 12-bit resolution and HDMI output up to 15 meters at 8-bit/12-bit
• Supports IR extension
• Supports RS-232, remote control, on-panel control and IP Control
(Telnet and Web GUI )
• 2U size design
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER LOCK
MENU OUTA 1B2C3D4
IN
E5F6G7H8
8X8 HDMI MATRIX CMSI-8H8HS
2 3 4 5 61
1
LCM:Displays the setting information of each input and output
setting.
2
POWER: Press this button to power the device on/off. The LED will
illuminate green when the power is on, red when it is in 'Standby'
mode.
3
LOCK: Press this button to lock all the buttons on the panel; press
again to unlock. The LED will illuminate green when locked.
4
IR: IR Receiver window (accepts the remote control signal of this
device only).
5
MENU: Press this button to access the LCM menu system, from
here EDID settings can be managed and IP system settings are
displayed.
Note: For the 'TV' EDID setting, the unit will read and store the
EDID information of the display connected to HDMI output A. For
the 'STD' EDID setting the unit's built-in EDID setting will be used
(1080p@60/12-bit for video and LPCM 2CH for audio).
6
1~8/A~H and OUT/IN: Press the OUT button and then the number
buttons to select the required output ports, and press IN button
and then a single number button to select the required input
source, nally press the MENU button to conrm the selection.
For example, if outputs A~D need to be set to input 1 and outputs
E~H need to be set to input 2 then the following sequence of
button presses need to be performed:
Press: OUTABCDIN1MENU,
and then press: OUTEFGHIN2MENU.
Note: If the MENU button is not pressed the selection will not be
changed.
4
6.2 Rear Panel
CONTROL
DC 24V
IR-In
RS-232 Service
A
HDMI Out
1
HDMI In
B
HDMI Out
2
HDMI In
C
HDMI Out
3
HDMI In
D
HDMI Out
4
HDMI In
E
HDMI Out
5
HDMI In
F
HDMI Out
6
HDMI In
G
HDMI Out
7
HDMI In
H
HDMI Out
8
HDMI In
12
34
V+
GND
GND
GND
V+
12
34
V+
GND
GND
GND
V+
2 3
3
4 71 6
5
1
CONTROL: This port is the link for Telnet and Web GUI controls,
connect to an active Ethernet link with an RJ45 terminated cable (for
further details, please refer to section 6.7 & 6.8).
Warning: Please do not connect this port directly to the PC/Laptop
as the Telnet function will not work.
2
RS-232: Connect to a PC or control system with D-Sub 9-pin cable
for the transmission of RS-232 commands.
3
IR IN: Connect to the supplied IR extenders for IR signal reception
from the remote control of the Matrix. Ensure that the remote is
within the direct line-of-sight of the IR extender when used.
4
SERVICE: Manufacturer use only.
5
HDMI OUT A~H: Connect to HDMI equipped TVs or monitors for
display of the HDMI input source signal.
6
HDMI IN 1~8: Connect to the HDMI input source devices such as a
DVD player or a Set-top Box with HDMI cable or DVI to HDMI cable..
7
DC 24V: Plug the 24 V DC power supply into the unit and connect
the adaptor to an AC outlet.
5
6.3 Side Panel
1
1
Fan Ventilator: These are air ventilation areas, DO NOT block these
areas or cover it with any object. Please allow adequate space
around the unit for air circulation.
6.4 Remote Control
1
POWER: Press this button to
switch on the device or set it to
standby mode.
2
IN: Input ports selection 1~8.
3
OUT: Output ports selection A~H.
1
23
