CYP CMSI-1616 Manuel utilisateur
CMSI-1616
16 by 16 Modular Matrix
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 05/07/13 Preliminary Release
RDV2 31/10/13 Panel's Printing
RDV3 21/04/14 Package Contents Add IR Cables
RDV4 30/06/14 RS-232 Command & CIN-8DS model
RDV5 21/01/15 UART Command
RDV6 05/03/15 Add IR Command
RDV7 23/04/15 Add IR Pin Assignment
VS0 27/04/15 Updated Text/Diagrams
CONTENTS
1. Introduction................................................................................1
2. Applications...............................................................................1
3. Package Contents ....................................................................1
4. System Requirements................................................................2
5. Features......................................................................................2
6. Operation Controls and Functions...........................................3
6.1 Front Panel ............................................................................ 3
6.2 Rear Panel.............................................................................5
6.3 Remote Control....................................................................6
6.4 IR Cable Pin Assignments ....................................................7
6.5 RS-232 Protocols ...................................................................7
6.6 RS-232 and Telnet Commands ........................................... 8
6.7 Telnet Control .....................................................................11
6.8 Web GUI Control ................................................................ 13
7. Connection Diagram ..............................................................14
7.1 Example Installation (16×16 HDMI Matrix) .......................14
7.2 Input and Output Modules ...............................................15
8. Specications ..........................................................................16
8.1 Technical Specications (Enclosure) ...............................16
8.2 Technical Specications (Input Modules) .......................17
8.3 Technical Specications (Output Modules)....................18
8.4 CAT5e/6/7 Cable Specications...................................... 21
9. Acronyms .................................................................................22
1
1. INTRODUCTION
The 16 by 16 Modular Matrix is designed to allow the switching and
distribution of up to 16 source devices to up to 16 connected displays,
either directly via HDMI, DVI or via CAT5e/6/7 outputs to compatible
receivers, providing control options (dependent on module
conguration).
Providing unparalleled levels of exibility, with an advanced modular
design these models can be setup in a wide variety of combinations
allowing users the ability to tailor the Matrix to their requirements by
simply adding or removing the input or output modules as required.
The Modular Matrix is supplied with dual removable internal PSU's
which allow for easy inspection and maintenance with zero down
time. Also included is a DVI output for local monitoring of the output
allowing installers to easily monitor, test, and congure the Inputs and
Outputs on installation.
In addition, this matrix also features IP control allowing users to access
and control the matrix remotely and also allow additional options for
integration of third-party control systems.
2. APPLICATIONS
• Public information display
• Educational demo
• Professional presentation
• Advertising display
3. PACKAGE CONTENTS
• 1×16 by 16 Modular Matrix Enclosure (including CPU Control Board
and Removeable Dual Power Supplies)
• 2×Input Module Boards - HDMI, DVI, CAT5e/6/7 or VGA (Optional)
• 2×Output Module Boards - HDMI, DVI or CAT5e/6/7 (Optional)
• 1×IR Extender
• 1×IR Blaster
• 1×Remote Control (with Battery)
• 2×Power Cords
• 1×Operation Manual
2
4. SYSTEM REQUIREMENTS
• Up to 16 HDMI, DVI, CAT5e/6/7 or VGA source devices (dependent
on module conguration) connected with appropriate cables.
• Up to 16 displays (TV or monitor) or AV receivers, equipped
with HDMI, DVI, CAT5e/6/7 connection (dependent on module
conguration) connected with appropriate cables
• Industry standard CAT5e/6/7 cable (for CAT5e/6/7 inputs/outputs)
• Compatible PoC HDBaseT™ Transmitters/Receivers for CAT5e/6/7
Input/Output modules
5. FEATURES
• HDMI, HDCP 1.1 and DVI 1.0 compliant
• Interchangeable input and output modules
• Input and output module types can be mixed and added in
multiples of 8 from 8×8 (1 Input module, 1 Output module) up
to 16×16 (2 Input modules, 2 Output modules) with HDMI, DVI,
CAT5e/6/7 and VGA (Input only) connection types
• Supports a wide range of PC and HDTV resolutions from VGA to
WUXGA and 480i to 1080p and 4K2K@24/25/30
• Supports pass-through of LPCM 7.1CH, Dolby TrueHD, Dolby Digital
Plus and DTS-HD Master Audio
• Supports control of the matrix via RS-232, Telnet and Web GUI
controls
• Supports 10 available preset settings
• Support 3 EDID modes: Standard, Dynamic and Manual (see
Section 6.1 for details)
• Dual removal power supply units
• Supports HDMI cable input and output lengths of up to 15m each
way (1080p@8-bit resolution), 10m (1080p@12-bit resolution) or 5m
(4K2K@30 resolution)
• Supports CAT5e/6/7 cable input and output lengths of up to
100m (1080p@8-bit/12-bit resolution) or 70m (4K2K@30 resolution)
dependent on board capabilities
• HDBaseT 5Play™ convergence supports HD Video, HD Audio, PoC,
Ethernet and IR/RS-232 Control
• HDBaseT 4Play convergence supports HD Video, HD Audio, PoC
and IR/RS-232 Control
• HDBaseT 3Play convergence supports HD Video, HD Audio and IR/
RS-232 Control
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER RETURN 789LOCK
MENU
PAGE 6
5
4SAVE
3
2
1RECALL
ALL
PAGE +
0
OUT/IN ENTER
LOCK
STANDBY
1
11
12
13
14
7 8 9 10
2
3
6
4
5
1
LCM: Displays the setting information of each input/output and
other setting information according to the selected mode.
2
IR WINDOW: Accepts the IR remote control signal for the matrix
only.
3
POWER: Press this button to turn the matrix on or press it again to
put the matrix into standby mode. The LED will illuminate when the
unit is in standby mode.
Note:IftheLEDisashingitmeansthetemperatureinsideistoo
highandaircirculationmayhavebeenrestricted.
4
PAGE (▲/▼/◄/►): Use these buttons to cycle through the LCM’s
pages for displaying the current I/O status or when entering into
the settings menu.
5
RETURN: Press this button to return back or exit the current selection.
6
MENU: Press this button to enter the menu to change the following
settings:
• EDID: Support 3 EDID modes.
4
1.StandardMode: Uses the built-in EDID settings that support
video up to 1080p@60 or WUXGA@60 (RB) video and LPCM
2CH audio.
2.DynamicMode: Reads the EDID settings from the display
connected to the lowest numbered output port.
3.ManualMode:Supports independent EDID settings by
selecting the input and output ports.
• IP: Displays the setting information of IP address, IP Netmask
and IP Gateway.
• Temperature: These gures show the internal temperature of
the matrix.
• LCM: Supports LCM contrast range from 1 to 4.
7
ALL: Press this button to assign the same input to all outputs.
8
OUT/IN: Press to assign the source to be displayed on the required
output. The sequence should be OUT/IN→Select the Input→OUT/
IN→a Select the output→Enter.
9
NUMBERS (0~9): Use to select the appropriate numbered input or
output.
10
PLUS (+): Press this button when multiple outputs are required for a
selected input. This button only works in conjunction with the OUT/
IN button.
11
LOCK: Press this button to lock all the function buttons on panel.
The LED will illuminate, to unlock press it again.
12
SAVE: Press this button to store the present Input/Output
conguration to one of the 10 available preset settings.
13
RECALL: Press this button to recall a previously stored preset setting.
14
ENTER: Press this button to conrm a setting or selection in the
menu.
5
6.2 Rear Panel
OUTPUT
MODULE
OUTPUT
MODULE
INPUT
MODULE
INPUT
MODULE
RS232 CONTROL IR ALL
OUTIN
SERVICE OUTPUT 0IR IN
2
45
1
3
1
OUTPUTS 1~16: Install up to 2 Output modules as required for up to
16 displays (TV or monitor) or CAT5e/6/7 outputs for compatible
HDBaseT receivers (dependent on module conguration).
Note:Theabovepanelisanexampleof16×16HDMIconguration.
2
CPU (Control Board)
IR IN: For IR control of the matrix only. Connect to the IR Extender
for IR signal reception of the IR remote control of the matrix. Ensure
that the remote being used is within the direct line-of-sight of the IR
Extender.
RS-232: Connect to a PC/Laptop with a D-sub 9-pin cable for RS-
232 command sending and controlling over the Matrix.
CONTROL: Connect to an active network for LAN serving and
Telnet/Web GUI control. LAN serving on compatible HDBaseT
input/output modules and transmitters/receivers only.
ALL IR OUT: Connect the IR output to the IR Blaster for IR signal
transmission of the equipment to be controlled. Place the IR Blaster
in direct line-of-sight of the equipment to be controlled.
ALL IR IN: Connect the IR input to the IR Extender for IR signal
reception of the IR remote control of the equipment to be
controlled. Ensure that remote being used is within the direct line-
of-sight of the IR Extender.
Note:ForIRcontroloftheHDBaseTinput/outputmodulesand
transmitters/receiversonly.IRsignalsreceivedbyallIRExtenders
connectedtothetransmitters/receiverswillbetransmittedbyallIR
Blastersconnectedtothetransmitters/receivers.
6
SERVICE: Manufacturer use only.
OUTPUT 0: Connect to DVI equipped display or to an HDMI
equipped display (with DVI to HDMI adaptor) for local monitoring
of the output signal.
3
INPUT 1~16: Install up to 2 Input modules as required for up to
16 source devices or CAT5e/6/7 inputs for compatible HDBaseT
transmitters (dependent on module conguration).
Note:Theabovepanelisanexampleof16×16HDMIconguration.
4
POWER SUPPLY: The matrix will automatically turn on when
connected to an active power supply.
5
VENTILATION FAN: This fan will automatically operate when the
matrix is switched on. Do not block the exhaust of the fan or cover
it with any object. Please allow adequate space around the unit
for air to circulate freely.
6.3 Remote Control
1
OUTPUT: Output port selection
2
INPUT: Input port selection.
3
ENTER: Press to conrm the present
input/output selection.
4
CLEAR: Press to clear the present
input/output selection. CLEAR
1
4
23
65
798
0
3
12
6
45
9
78
0
CR-127
INPUT
ENTER
OUTPUT
1
2
3
4
Table des matières
Autres manuels CYP Commutateur matriciel
CYP
CYP EL-42M-PIP Manuel utilisateur
CYP
CYP CPLUS-1082CVEA Manuel utilisateur
CYP
CYP CDPS-UA6H2HFS Manuel utilisateur
CYP
CYP CPLUS-V4H2HP-DT Manuel utilisateur
CYP
CYP PUV-1210PL-RX Manuel utilisateur
CYP
CYP CPLUS-V4H2HPIP Manuel utilisateur
CYP
CYP OR-IR88 Manuel utilisateur
CYP
CYP OR-HD44E Manuel utilisateur
CYP
CYP OR-IR44 Manuel utilisateur
CYP
CYP OR-HD88S Manuel utilisateur
CYP
CYP CPLUS-1082VA Manuel utilisateur
CYP
CYP PUV-662PL-4K22 Manuel utilisateur
CYP
CYP PUV-1082-4K22N Manuel utilisateur
CYP
CYP CPLUS-V4H2HPIP Manuel utilisateur
CYP
CYP OR-44VWC Manuel utilisateur
CYP
CYP CPLUS-V8H8HP Manuel utilisateur
CYP
CYP Elpro Video Labs CDPS-UC4H4HFS Manuel utilisateur
CYP
CYP OR-42UHD Manuel utilisateur
CYP
CYP OR-42CD-4K22 Manuel utilisateur
CYP
CYP CPLUS-V8H8HP Manuel utilisateur
